NuWaves NuPower C20R01 Manual de usuario



USERMANUAL

NUPOWER



C20R01

C‐BANDPOWERAMPLIFIER



PARTNUMBER:

NW‐PA ‐C‐20‐R01



NuWavesEngineering

132EdisonDrive

Middletown,Ohio45044

PH:513‐360‐0800

FAX:513‐539‐8782

www.nuwaves.com

product.sales@nuwaves.com

NuPower

C20R01UserManual



Rev1.0

1



1 NUPOWER

PRODUCT LINE OVERVIEW

TheNuPowerfamilyofsolidstateRFpoweramplifier(PA)modulesisdesignedtomeetthedemanding

needs of the Aerospace & Defense, Industrial, and Commercial markets. Based on the latest gallium

nitride(GaN)technology,NuPower’spowerefficiencyandminiatureformfactormakeitidealforsize,

weight,andpower‐constrainedbroadbandRFtelemetryandtacticalcommunicationssystems.

1.1 NUPOWER

PRODUCT LINE HIGHLIGHTS



 High Performance: Unique combination of broadband coverage, miniature form factors, and

highefficiency.



 Enclosures:TheNuPowerfamilyofpoweramplifiersishousedinasilvernickelplatedaluminum

enclosurewithmountingholesincorporatedintothechassis.



 Completely Characterized: The NuPower family of solid state power amplifiers has been

completely characterized over temperature, voltage, and frequency. These high‐performance

modulesoffersignificantvaluefortheOEMuserortheSystemsIntegrator.



 User Friendly: Over‐Voltage protection and regulator thermal shutdown provide defenses

againstuserinterfaceissues.



 High Reliability: NuWaves’ selection of conservatively rated components provides high

reliability.EachNuPowerisinspectedtoIPC‐A‐610ClassIIqualitystandards.NuWaves’Quality

ManagementSystemisAS9100:2016RevDandISO9001:2015certified.



 Applications: Broadband RF Telemetry •RFCommunicationSystems• Electronic Warfare •

Unmanned Aircraft Systems (UAS) • Unmanned Ground Vehicles (UGV) • Unmanned Surface

Vehicles(USV)•SoftwareDefinedRadios• TestLabs



 AvailableOptions:



o Fan‐cooledheatsinkwith28Voperatedfan

o Labeledinterfacecablewithbananajackplugs



NuPower

C20R01UserManual



Rev1.0

2



2 NUPOWER

C20R01 PA OVERVIEW

TheNuPower

TM

C20R01PAisahighlyefficient,solidstatepoweramplifierthatprovidesover20wattsof

RFpoweracross4400MHz–4900MHz.



Based on the latest gallium nitride (GaN) technology, NuPower L‐Band power efficiency and < 10 in

3



cubicinchformfactormakeitidealforsize,weight,andpower‐constrained broadband RF telemetry

andtacticalcommunicationsystems.



TheNuPower

C20R01ruggedizedchassisallowsthesystemintegratortoeasily incorporatetheunit

into a platform operating in harshenvironments with limited space, such as small Unmanned Aircraft

Systems(UAS).

Figure 1: NuPower C20R01 Functional Diagram





NuPower

C20R01UserManual



Rev1.0

3



2.1 NUPOWER C20R01 PA SPECIFICATIONS

ThesubsequenttablesinthissectionoutlinetheNuPowerC20R01’sperformancespecifications.



Table 1: NuPower C20R01 Electrical Specifications

Parameter Specification

FrequencyRange 4400MHzto4900MHz

RFOutputPower 20Watts(min)

OutputPower@1dBCompression

33dBm@4400MHz

32dBm@4650MHz

30dBm@4900MHz

RFGain 43dB

InputVSWR 2.1(typ)

OutputMismatch

(NoDamage) 10:1

NominalInputDriveLevel 0dBm

MaximumInputDriveLevel

(Nodamage) +15dBm

Harmonic

:≤‐25dBc

ThirdOrderInterceptPoint

(Twotone testat1 MHzspacing,

Pout= 20 dBm /tone)

44dBm@800MHz

SwitchingSpeed 2µS

OperatingVoltage +27to+30VDC

OperatingCurrent 3.6A@+28VDC(typ)

ModuleEfficiency 25%

PowerAmplifierEnable GNDOn

Impedance 50Ω



NuPower

C20R01UserManual



Rev1.0

4



Table 2: NuPower C20R01 Environmental Specifications

Operating Conditions Specification

OperatingTemperature ‐40to+55

C(ambient)

‐40to+60

C(baseplate)

StorageTemperature ‐55to+85

C



2.2 NUPOWER C20R01 PA MECHANICAL SPECIFICATIONS

Figure 2: NuPower C20R01 Mechanical Outline



Table 3: NuPower C20R01 Mechanical Specifications

Parameter Specification

RFConnectors SMA(female)

Control/PowerInterfaceConnector 9PinMicro‐D(socket)

Dimensions(LxWxH) 4.5”x3.5”x0.61”

Weight 9oz.

NuPower

C20R01UserManual



Rev1.0

5



2.3 HEAT SINKING

The NuPower C20R01 is offered as a stand‐alone module or with an accessory kit

(p/nNW‐PA‐ACC‐KT03),whichincludesa28VDCfan‐cooledheatsinkandrequisitepowercable.[Thekit

alsoincludesanupgradedmoduleinterfacecableassembly,labeledandterminatedwithbananaplugs.]



Figure 3: The NuPower PA Kit offers “out‐of‐the‐box” operation for the user. The 12 VDC fan‐cooled

heatsink is shown with the NuPower C20R01 mounted.



Caution: The use of external heat‐sinking is required especially for those applications

requiringhighdutycycleoperation(e.g.continuouswave)orforextendedon‐timetesting.

Operationwithoutaproperheatsinkundertheseconditionswillcausepermanentdamage

totheproductandwillvoidtheproductwarranty.



Themaxoperatingtemperatureis85˚C(baseplate).





NuPower

C20R01UserManual



Rev1.0

6



3 SETUP AND OPERATION

This section provides specific details for proper operation of the NuPower C20R01 module. Following

theseguidelineswillpreventdamagetothepoweramplifierorexternalequipment.

3.1 POWER SUPPLY REQUIREMENTS

TooperatetheNuPowerC20R01,ensurethatthe powersupplyhasadequateoverheadtosourcethe

currentdemandoftheRFpoweramplifier.Thepowersupplysourcemustprovideatypicalvoltageof

+28VDCwithgreaterthan6ampscapability.

3.2 CONNECTING A PROPER LOAD TO THE ANTENNA TERMINAL

TopreventdamagetothePA,theantennaterminalmustbeterminatedintoa50Ωload.Examplesofa

properloadinclude:



 Directlyconnectingtoanantennaspecifiedforthefrequencyrange(4400MHzto4900MHz).

ConnectingtoaninappropriateantennamayresultindamagetothePAmodule.

 Connectingtoaproperantennathrougha50Ωtransmissionlineorcoaxialcable.Avoidusing

damagedcablesorcorrodedconnectorswhileattachingtheunittoanantenna.

 Terminating the antenna terminal into a 50 Ω power attenuator with minimum 20 dB

attenuation.

 ConnectingtoaloadcapableofdissipatingtheRFpowerfromthePAmodule.Loadscapableof

handling50Watts(min)arerecommended.

3.3 POWERING‐UP THE NUPOWER C20R01

TheNuPowerC20R01mustbeterminatedtoaproperloadbeforepowerisapplied.RefertoSection3.2

forthespecificationsoftheproperload.AfterthePAisproperlyterminated,theinterfacecablecanbe

connectedtotheunitandpowercanbeapplied.ThePAisnowreadyforoperation.

3.4 TRANSMIT TURN‐ON TIME



Caution:DonotapplytransmitdatauntilthePAmoduleisatfullpower.Thiswillprevent

lossofdataatthebeginningofamessage.



The NuPower C20R01 is at full power approximately 1 µS after the RF Enable line goes low (ground).

Therefore,transmitdatacanbeappliedtotheinputafter1µSwithoutlossofdata.

3.5 RF OUTPUT POWER VS. SUPPLY VOLTAGE

TheNuPowerC20R01wasdesignedfor+28VDCoperation.



NuPower

C20R01UserManual



Rev1.0

7



4 HARDWARE INTERFACE

 TheRFInputconnectorisSMA(female).

 TheRFOutputconnectorisSMA(female).

 The pin‐out definitions for the 9 pin Micro‐D socket connector are provided in Table 4. In a

typicalinstallation,thePAmoduleismatedtoahostcontrollerboardviaacableharness.



The RF Out SMA connector is the antenna connection. This connection should

alwaysbeloadedinto50Ω,otherwisethePAcouldbedamaged.

4.1 INTERFACE CABLE HARNESS

The cable harness that connects the host controller to the 9 pin Micro‐D connector of the NuPower

C20R01ismadeupof9wires.

Table 4: NuPower C20R01 Interface Pin‐Out Definitions

Pin No. Pin Name I/0 Description

3,4,5 VSupply I PrimaryPower(+28VDC)

1,2,6,8 GND I SignalandPowerGround

7 TempFlag 0 Over‐tempIndicator

0V=temperaturefault

+5V=nofault

9 RFEnable I TransmitControl

0VorGND=RFOn

+5VorNC=RFOff



Figure 4: Micro‐D Socket Locations



NuPower

C20R01UserManual



Rev1.0

8



4.2 DC POWER

ThenominalsupplyvoltagefortheNuPowerC20R01is+28VDC;Theacceptablesupplyvoltagerangeis

+27to+30VDC.

4.3 GROUND

ThesignalandpowergroundsaretiedtogetherinthePAmodule.

4.4 RF ENABLE

Thissignalisthelogiccontrolinputthatdesignateswhethertheunitisintransmitorstandbymode.The

RFEnablelineispulledhighinternallyplacingthePAmoduleinstandbymode.Ifthepinisleftfloating

(i.e.notconnected),theunitwilldefaulttostandbymode.

Groundingthepin(i.e.avoltagebelow+0.2VDC)placestheunitintransmitmode.Theusercaneither

connecttheRFEnablelinetopins,1,2,6&8ontheCTRL/PWRinterfaceconnector,oranopendrain

logiclinecapableofsinking500µAtoplacetheunitintransmitmode.

4.5 TEMP FLAG

Thissignalisanoutputtoindicateanover‐temperatureconditionintheNuPowerC20R01.Alogichigh

(+5VDC)indicatesnormaloperation,whilealogiclow(0VDC)indicatesanover‐temperaturecondition.

TheNuPowerC20R01incorporatesinternallogiccircuitrythatturnsofftheDCbiastotheRFtransistors.



Caution: The amplifier should be shut down and allowed to cool offwhentheover‐

temperatureflagissetlowtoavoiddamagetothemodule.





NuPower

C20R01UserManual



Rev1.0

9



5 PRODUCT DISPOSAL – END‐OF‐LIFE

SafetyisaguidingprincipleofNuWavesEngineering.Weensuresafeproductionandoperationofour

products, as well as end‐of‐life disposal.  Improper disposal canadverselyaffecttheenvironment,

wildlifeandhumanhealth.PleasefollowtheseguidelineswhendisposingofaNuWavesproduct:



 Donotremovethecoveroranyhardware

 Donotremovecomponentsfromthecircuitcardassembly

 Donotincinerate

 Donotcrushorshred

 Donotdisposeofasunsortedmunicipalwaste

 Donotexporte‐wasteoutsideoftheoriginaldestinationcountryforrecycling

 Utilizeane‐StewardorISO14001certifiede‐wasterecycler

 Considerexportcontrolsduringrecyclerselection

 If a NuWaves product is incorporated into a larger system or sub‐system, ensure that these

guidelinesarefollowedatsystemend‐of‐life






