NuWaves NUPOWER 12B01A-02 Manual de usuario



USERMANUAL

NUPOWER

12B01A‐02

L‐BANDPOWERAMPLIFIER



PARTNUMBER:

NW‐PA ‐12B01A‐02



NuWavesEngineering

132EdisonDrive

Middletown,Ohio45044

PH:513‐360‐0800

www.nuwaves.com

product.sales@nuwaves.com

NuPower

12B01A‐02UserManual 



Rev1.0

1



1NUPOWER

PRODUCT LINE OVERVIEW

TheNuPowerfamilyofsolid‐stateRFpoweramplifier(PA)modulesisdesignedtomeetthedemanding

needsoftheAerospace&Defense,Industrial,andCommercialmarkets.Basedonthelatestgallium

nitride(GaN)technology,NuPower’spowerefficiencyandminiatureformfactormakeitidealforsize,

weight,andpower‐constrainedbroadbandRFtelemetryandtacticalcommunicationssystems.

1.1 NUPOWER

PRODUCT LINE HIGHLIGHTS



HighPerformance:Uniquecombinationofbroadbandcoverage,miniatureformfactors,and

highefficiency.



Enclosures:TheNuPowerfamilyofpoweramplifiersishousedinasilvernickelplatedaluminum

enclosurewithmountingholesincorporatedintothechassis.



CompletelyCharacterized:TheNuPowerfamilyofsolid‐statepoweramplifiershasbeen

completelycharacterizedovertemperature,voltage,andfrequency.Thesehigh‐performance

modulesoffersignificantvaluefortheOEMuserortheSystemsIntegrator.



UserFriendly:Reverse‐Voltage&Over‐Voltageprotectionandregulatorthermalshutdown

providedefensesagainstuserinterfaceissues.



HighReliability:NuWaves’selectionofconservativelyratedcomponentsprovideshigh

reliability.EachNuPowerisinspectedtoIPC‐A‐610ClassIIqualitystandards.NuWaves’Quality

ManagementSystemisAS9100:2016RevDandISO9001:2015certified.



Applications:UnmannedAircraftSystems(UAS)•UnmannedGroundVehicles(UGV)•

UnmannedSurfaceVehicles(USV)•BroadbandRFTelemetry•RFCommunicationSystems•

SoftwareDefinedRadios• TestLabs



AvailableOptions:



oFan‐cooledheatsinkwithAC/DCadapter

oLabeledinterfacecablewithbananajackplugs

o1Wattinputdrivelevel



NuPower

12B01A‐02UserManual 



Rev1.0

2

2NUPOWER

12B01A‐02 OVERVIEW

TheNuPower

TM

12B01A‐02solidstatepoweramplifier(SSPA)isasmall,highlyefficientPAthatprovides

over10wattsofRFpoweracrosstheL‐bandfrequenciesof1.0‐2.0GHz.



BasedonthelatestGaNtechnology,NuPower’sgreaterthan40%powerefficiencyand3.9cubicinch

formfactormakesitidealforsize,weight,andpower‐constrainedbroadbandRFtelemetryandtactical

communicationssystems.



TheNuPower12B01A‐02acceptsanominal0dBmRFinputandprovidesover40dBofgainfrom1000

to2000MHz.NuPowerPAsfeatureover‐voltageandreverse‐voltageprotectioninadditiontoasimple

controllineinterfaceallowingtheusertoeasilyplacethemoduleintotransmitorstandbymodeof

operation.Akitisavailableforpurchasewhichincludesafan‐cooledheatsinkwithAC/DCpower

adapter,andupgradedinterfacecablewithlabeledbananaplugs.

Figure 1: NuPower 12B01A‐02 Functional Diagram



2.1 NUPOWER 12B01A‐02 SPECIFICATIONS

ThesubsequenttablesinthissectionoutlinetheNuPower12B01A‐02’sperformancespecifications.



Table 1: NuPower 12B01A‐02 Electrical Specifications

Parameter Specification

FrequencyRange1.0GHzto2.0GHz

RFOutputPower10Watts(min)

RFGain40dB(min)

Harmonic

1000to1400MHz

1400to1700MHz

1700to2000MHz



≤‐6dBc

≤‐15dBc

≤‐20dBc

NuPower

12B01A‐02UserManual 



Rev1.0

3

Parameter Specification

SupplyVoltage+11to+32VDC

CurrentConsumption2.0A@+28VDC(typ)

PowerAmplifierEnableGNDOn

NominalInputDriveLevel0dBm

MaximumInputDriveLevel

(Nodamage)+10dBm

Impedance50Ω

Table 2: NuPower 12B01A‐02 Environmental Specifications

Operating Conditions Specification

OperatingTemperaturefor

ContinuousOperation

(>5minutes)

‐30to+55

C(ambient)

‐30to+60

C(baseplate)

OperatingTemperaturefor20%

DutyCycle

‐30to+60

C(ambient)

‐30to+65

C(baseplate)

StorageTemperature‐40to+85

C



Table 3: NuPower 12B01A‐02 Mean Time Between Failure (MTBF)

Conditions Hours

GroundBenign(GB)126,690

AirborneInhabitedCargo(AIC)14,800

AirborneInhabitedFighter(AIF)10,650

AirborneUninhabitedCargo(AUC)8,400

AirborneUninhabitedFighter(AUF)5,800





NuPower

12B01A‐02UserManual 



Rev1.0

4



2.2 NUPOWER 12B01A‐02 MECHANICAL SPECIFICATIONS

Figure 2: NuPower 12B01A‐02 Mechanical Outline



Table 4: NuPower 12B01A‐02 Mechanical Specifications

Parameter Specification

RFConnectorsSMA(female)

Control/PowerInterfaceConnector9PinMicro‐D(socket)

Dimensions(LxWxH)3.00”x2.00”x0.65”

Weight3.7oz.



NuPower

12B01A‐02UserManual 



Rev1.0

5



2.3 HEAT SINKING

TheNuPower12B01A‐02isofferedasastand‐alonemoduleorwithakit,whichalsoincludesafan‐

cooledheatsinkwithanAC/DCadapter,andaninterfacecable.



Figure 3: The NuPower PA Kit offers “out‐of‐the‐box” operation for the user. The fan‐cooled heatsink

with an AC/DC adapter is shown with an example PA (NuPower 12B01A‐02 not shown).



Caution:Theuseofexternalheat‐sinkingisrequiredespeciallyforthoseapplications

requiringhighdutycycleoperation(e.g.continuouswave)orforextendedon‐timetesting.

Operationwithoutaproperheatsinkundertheseconditionswillcausepermanentdamage

totheproductandwillvoidtheproductwarranty.



Theexternalheatsinkthermalresistancerequirementsare:

<0.25˚C/Wforoperationupto60˚Cambient

<0.7˚C/Wforoperationupto40˚Cambient





NuPower

12B01A‐02UserManual 



Rev1.0

6



3SETUP AND OPERATION

ThissectionprovidesspecificdetailsforproperoperationoftheNuPower12B01A‐02module.Following

theseguidelineswillpreventdamagetothepoweramplifierorexternalequipment.



3.1 POWER SUPPLY REQUIREMENTS

TooperatetheNuPower12B01A‐02,ensurethatthepowersupplyhasadequateoverheadtosource

thecurrentdemandoftheRFpoweramplifier.Thepowersupplysourcemustprovideatypicalvoltage

of+28VDCwithgreaterthan3ampscapability.



3.2 CONNECTING A PROPER LOAD TO THE ANTENNA TERMINAL

TopreventdamagetothePA,theantennaterminalmustbeterminatedintoa50Ωload.Examplesofa

properloadinclude:

Directlyconnectingtoanantennaspecifiedforthefrequencyrange(1000MHzto2000MHz).

ConnectingtoaninappropriateantennamayresultindamagetothePAmodule.

Connectingtoaproperantennathrougha50Ωtransmissionlineorcoaxialcable.Avoidusing

damagedcablesorcorrodedconnectorswhileattachingtheunittoanantenna.

Terminatingtheantennaterminalintoa50Ωpowerattenuatorwithminimum20dB

attenuation.

ConnectingtoaloadcapableofdissipatingtheRFpowerfromthePAmodule.Loadscapableof

handling20Watts(min)arerecommended.



3.3 POWERING‐UP THE 12B01A‐02

TheNuPower12B01A‐02mustbeterminatedtoaproperloadbeforepowerisapplied.RefertoSection

3.2forthespecificationsoftheproperload.AfterthePAisproperlyterminated,theinterfacecablecan

beconnectedtotheunitandpowercanbeapplied.ThePAisnowreadyforoperation.



3.4 TRANSMIT TURN‐ON TIME



Caution:DonotapplytransmitdatauntilthePAmoduleisatfullpower.Thiswillprevent

lossofdataatthebeginningofamessage.



TheNuPower12B01A‐02isatfullpowerapproximately500µSaftertheRFEnablelinegoeslow

(ground).Therefore,transmitdatacanbeappliedtotheinputafter500µSwithoutlossofdata.



NuPower

12B01A‐02UserManual 



Rev1.0

7



4HARDWARE INTERFACE

TheRFInputconnectorisSMA(female).

TheRFOutputconnectorisSMA(female).

Thepin‐outdefinitionsforthe9pinMicro‐DsocketconnectorareprovidedinTable5.Ina

typicalinstallation,thePAmoduleismatedtoahostcontrollerboardviaacableharness.



TheRFOutSMAconnectoristheantennaconnection.Thisconnectionshould

alwaysbeloadedinto50Ω,otherwisethePAcouldbedamaged.



4.1 INTERFACE CABLE HARNESS

Thecableharnessthatconnectsthehostcontrollertothe9pinMicro‐DconnectoroftheNuPower

12B01A‐02ismadeupof9wires.

Table 5: NuPower 12B01A‐02 Interface Pin‐Out Definitions

Pin No. Pin Name I/0 Description

1,2VSupplyIPrimaryPower(+11to+32VDC)

3,4GNDISignalandPowerGround

5RFEnableITransmitControl

6,7,9N.C.‐ N/A

8TempFlag0Over‐tempIndicator



Figure 4: Micro‐D Socket Locations



NuPower

12B01A‐02UserManual 



Rev1.0

8



4.2 DC POWER

ThenominalsupplyvoltagefortheNuPower12B01A‐02is+28VDC;however,theamplifiermoduleis

abletosupportoperationoverasupplyvoltagerangeof+11to+32VDC.



4.3 GROUND

ThesignalandpowergroundsaretiedtogetherinthePAmodule.



4.4 RF ENABLE

Thissignalisthelogiccontrolinputthatdesignateswhethertheunitisintransmitorstandbymode.The

RFEnablelineispulledhighinternallyplacingthePAmoduleinstandbymode.Ifthepinisleftfloating

(i.e.notconnected),theunitwilldefaulttostandbymode.

Groundingthepin(i.e.avoltagebelow+0.2VDC)placestheunitintransmitmode.Theusercaneither

connecttheRFEnablelinetopins3&4ontheCTRL/PWRinterfaceconnector,oranopendrainlogic

linecapableofsinking500µAtoplacetheunitintransmitmode.



4.5 TEMP FLAG

Thissignalisalogicleveloutputtoindicateanover‐temperatureconditionintheNuPower12B01A‐02.

Alogichigh(+5VDC)indicatesnormaloperation,whilealogiclow(0VDC)indicatesanover‐

temperaturecondition.TheNuPower12B01A‐02incorporatesinternallogiccircuitrythatturnsoffthe

DCbiastotheRFtransistors.



Caution:Theamplifiershouldbeshutdownandallowedtocooloffwhentheover‐

temperatureflagissethightoavoiddamagetothemodule.



NuPower

12B01A‐02UserManual 



Rev1.0

9



5PRODUCT DISPOSAL – END‐OF‐LIFE

SafetyisaguidingprincipleofNuWavesEngineering.Weensuresafeproductionandoperationofour

products,aswellasend‐of‐lifedisposal.Improperdisposalcanadverselyaffecttheenvironment,

wildlifeandhumanhealth.PleasefollowtheseguidelineswhendisposingofaNuWavesproduct:



Donotremovethecoveroranyhardware

Donotremovecomponentsfromthecircuitcardassembly

Donotincinerate

Donotcrushorshred

Donotdisposeofasunsortedmunicipalwaste

Donotexporte‐wasteoutsideoftheoriginaldestinationcountryforrecycling

Utilizeane‐StewardorISO14001certifiede‐wasterecycler

Considerexportcontrolsduringrecyclerselection

IfaNuWavesproductisincorporatedintoalargersystemorsub‐system,ensurethatthese

guidelinesarefollowedatsystemend‐of‐life






