PO909884 Issue 03

Software Keycode

Installation Guide

PO909884 Issue 03 Software Keycode Installation Guide

Software Keycode Installation Guide

Introduction

This document provides instructions for enabling Software Keycodes. Predefined

bundles of keycodes may be ordered as a single part although individual keycodes

must be entered to enable specific features.

Installation overview

The installer is responsible for obtaining and enabling the Software Keycode(s).

Only registered users can access the Keycode Retrieval System. Click on the

Determining the system identification number

You need the system identification number for your system, before you can obtain

a Software Keycode.

Determining the CallPilot Mini/CallPilot 150 system identification number

To determine the system identification number:

1. Log on to CallPilot Manager.

For information about how to log on to CallPilot Manager, refer to the

CallPilot Manager Set Up and Operation Guide.

2. Click the Installed Options link.

The system identification number appears in the Serial Number box.

3. Write system identification number on page 6 of this guide.

Determining the Business Communications Manager system identification

number

To determine the system identification number:

1. Log on to Unified Manager.

For information about how to log on to Unified Manager, refer to theBusiness

Communications Manager Programming Operations Guide.

2. Click the System key and then click the Licensing heading.

The system identification number appears in the System Identifier box.

3. Write system identification number on page 6 of this guide.

4Software Keycode Installation Guide

Software Keycode Installation Guide PO909884 Issue 03

Obtaining Software Keycodes

To obtain a Software Keycode:

1. Access the Nortel Networks Keycode Retrieval System at the following URL:

http://www.nortelnetworks.com/servsup/krs/.

2. Select the Login Type option that applies to you.

3. Select the Product Family option that applies to you.

4. Enter your username and password and click the OK button.

5. Select the Keycode Retrieval System option that applies to you.

6. Enter the system identification number from your system.

7. Enter the authorization number from the Feature Pack for the specific feature.

The authorization number is on page 6 of this guide.

8. Click Validate to confirm the authorization number.

9. Click Generate to retrieve the keycode.

10. The Software Keycode number consists of three eight-digit numbers.

Record the Software Keycode by writing down the number, printing the file,

or copying and pasting the information into another document.

If you are using Business Communications Manager, you can also download

the Software Keycodes file to a shared folder on your computer. You can then

use this file to copy the Software Keycodes into your Business

Communications Manager system.

Entering Software Keycodes

After you have obtained the Software Keycodes, you need to enter these codes in

your system.

Entering the Software Keycodes on a CallPilot Mini/CallPilot 150

To enter the Software Keycodes:

1. Log on to CallPilot Manager.

2. Click the Installed Options link.

3. In the Keycode boxes, type the Software Keycode.

4. Click the Add button.

The option you installed appears in the Installed Options list.

Software Keycode Installation Guide 5

PO909884 Issue 03 Software Keycode Installation Guide

Entering the Software Keycodes on a Business Communications Manager

To enter the Software Keycode:

1. Log on to Unified Manager.

2. Click the System key and then click the Licensing key.

3. On the Configuration menu, click Add a Keycode.

4. In the Keycode box, enter the 24-digit Software Keycode number.

Note: Make sure you enter a hyphen between each eight-digit segment.

5. Click the Save button.

After the Software Keycode is accepted and enabled, a confirmation box

appears.

6. Click the OK button.

Entering Software Keycode Files on a Business Communications Manager

If you have a Business Communications Manager system, you can load Software

Keycodes by loading the Software Keycode file into your system.

To load the Software Keycode file:

1. Log on to Unified Manager.

2. Click the System key and then click the Licensing key.

3. Click Keycode Files heading.

The Keycode File Location Information window appears.

4. In the Keycode File Location Information window, enter the information

required to access the computer and folder where the Software Keycode file

downloaded from the Nortel Networks Keycode Retrieval System is stored.

Note: The Software Keycode file must be stored in a shared folder.

5. On the Configuration menu, click Apply New Keycode File.

6. Click the Yes button.

After the Keycode File is accepted, a confirmation box appears.

7. Click the OK button.

6Software Keycode Upgrade Information Sheet

Software Keycode Installation Guide PO909884 Issue 03

Software Keycode Upgrade

Information Sheet

Authorization

Number

System ID Number
