Nokia HS 36W Manual de usuario

Nokia Wireless Headset

(HS-36W)

User Guide

9239356

Issue 2 EN

9239356_hs36w_1_en.fm Page 1 Saturday, August 20, 2005 3:25 PM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the product

HS-36W is in conformity with the provisions of the following Council Directive:

1999/5/EC. A copy of the Declaration of Conformity can be found at http://

www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this

document in any form without the prior written permission of Nokia is

prohibited.

Nokia and Nokia Connecting People are registered trademarks of Nokia

Corporation. Other product and company names mentioned herein may be

trademarks or tradenames of their respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of continuous development. Nokia reserves the right to

make changes and improvements to any of the products described in this

document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income

or any special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by

applicable law, no warranties of any kind, either express or implied, including, but

not limited to, the implied warranties of merchantability and fitness for a

particular purpose, are made in relation to the accuracy, reliability or contents of

this document. Nokia reserves the right to revise this document or withdraw it at

any time without prior notice.

The availability of particular products may vary by region. Please check with the

Nokia dealer nearest to you.

Unauthorized changes or modifications to this device may void the user's

authority to operate the equipment.

Export Controls

This device may contain commodities, technology or software subject to export

laws and regulations from the US and other countries. Diversion contrary to law

is prohibited.

9239356/Issue 2 EN

9239356_hs36w_1_en.fm Page 2 Saturday, August 20, 2005 3:25 PM

English

Contents

1. Introduction ....................... 4

Bluetooth wireless technology ....... 4

2. Get started.......................... 5

Chargers and batteries...................... 5

Charge the battery............................. 6

Switch the headset on or off .......... 6

Pair the headset with a compatible

phone ..................................................... 6

3. Basic use ............................ 8

Wear the headset on either ear ..... 8

Call handling........................................ 8

Store the headset properly .............. 9

Troubleshooting .................................. 9

4. Battery information ........ 10

Care and maintenance ........ 11

9239356_hs36w_1_en.fm Page 3 Saturday, August 20, 2005 3:25 PM

Introduction

1. Introduction

The Nokia Wireless Headset (HS-36W) can be used with compatible

phones that support Bluetooth wireless technology. This allows you

freedom to make and receive calls while on the move or in the office.

Read this user guide carefully before using the headset. Read also the

user guide for your phone, which provides important safety and

maintenance information. Keep the headset out of reach of small

children.

■Bluetooth wireless technology

Bluetooth wireless technology allows you to connect compatible

communication devices without cables. A Bluetooth connection does

not require that the phone and the headset be in line of sight, but both

devices should be within 10 meters (30 feet) of each other. Connections

may be subject to interference from obstructions, such as walls, or other

electronic devices.

The headset is compliant with the Bluetooth Specification 1.2

supporting the following profiles: Headset profile 1.1 and Hands-free

Profile 1.0. Check with the manufacturers of other devices to determine

their compatibility with this device.

There may be restrictions on using Bluetooth technology in some

locations. Check with your local authorities or service provider.

9239356_hs36w_1_en.fm Page 4 Saturday, August 20, 2005 3:25 PM

Get started

English

2. Get started

The headset contains the following

parts:

• Indicator light (1)

• Volume keys (2)

• Charging socket (3)

• Answer/end key (4)

• Earhook (5)

• Nokia Charger Adapter cable (CA-71) (6)

Before you can start to use the headset, you

must charge the battery, and pair a compatible

phone with the headset.

Note: Parts of the headset are magnetic. Metallic materials

may be attracted to the headset, and persons with a hearing aid

should not hold the headset to the ear with the hearing aid. Do

not place credit cards or other magnetic storage media near the

headset, because information stored on them may be erased.

■Chargers and batteries

Check the model number of any charger before using it with this device.

The Nokia Wireless Headset (HS-36W) is intended for use with the ACP-

12 and LCH-12 chargers.

Warning: Use only batteries and chargers approved by Nokia

for use with this particular enhancement. The use of any other

types may invalidate any approval or warranty, and may be

dangerous.

For availability of approved enhancements, please check with your

dealer. When you disconnect the power cord of any enhancement, grasp

and pull the plug, not the cord.

9239356_hs36w_1_en.fm Page 5 Saturday, August 20, 2005 3:25 PM

Get started

■Charge the battery

The headset has an internal, nonremovable, rechargeable battery. Do not

attempt to remove the battery from the device, as you may damage the

device.

1. Ensure that the Nokia Charger Adapter cable (CA-71) is connected to

the charger that is supplied with the headset. If this is not the case,

connect the one end of the adapter cable to the charger cable.

2. Connect the adapter cable to the

headset.

3. Connect the ACP-12 charger to a

wall outlet or the LCH-12 charger to

the accessory power outlet of your

car. The blue indicator light is

continuously displayed during charging.

The headset is switched off and cannot be used during charging.

4. When the battery is fully charged, the blue indicator light switches

off. Disconnect the charger from the wall outlet or the accessory

power outlet and the headset. When you disconnect the power cord

of the charger, grasp and pull the plug, not the cord.

The fully charged battery has power for up to 6 hours of talk-time or up

to 110 hours of standby time. (In the standby mode, the headset is

switched on but no call is in progress.)

When the battery is running out of power, the red indicator light lights

up. Charge the battery.

■Switch the headset on or off

To switch on, press the answer/end key for about 1 second. To switch off,

press and hold the answer/end key for about 5 seconds.

■Pair the headset with a compatible phone

Make sure that the headset is on, and put it in pairing mode by pressing

the answer/end key and the volume up (+) key at the same time over 5

seconds until the blue indicator light lights up. The indicator light

9239356_hs36w_1_en.fm Page 6 Saturday, August 20, 2005 3:25 PM

Get started

English

remains on for 5 minutes, during which you can pair the headset with a

compatible mobile phone.

1. Set the phone to search for Bluetooth devices. See the user guide of

your phone for instructions.

2. When your phone finds the headset, confirm the pairing from your

phone.

3. When prompted for the Bluetooth passcode of the headset, enter

0000.

If the pairing was unsuccessful, try to pair the devices again.

You only need to pair the headset with your phone once.

If the pairing was successful, the blue indicator light starts to flash. The

headset is now in the standby mode and ready for use.

9239356_hs36w_1_en.fm Page 7 Saturday, August 20, 2005 3:25 PM

Basic use

3. Basic use

■Wear the headset on either ear

The headset is ready to wear on the right ear. If you want to use it on the

left ear, gently flip (1) and rotate the earhook (2).

■Call handling

To answer a call, press the answer key on your mobile phone, or press the

answer/end key on the headset briefly. If you do not want to answer a

call, press and hold the answer/end key on the headset for about 1

second.

To make a call, dial the number with your mobile phone, and press the

answer key on your phone. The call is automatically transferred to the

headset.

To redial the last called number, press and hold the answer/end key on

your headset for about 1 second when no call is in progress.

If your phone supports voice dialing and there is no call in progress,

press the answer/end key on the headset briefly, and proceed with voice

dialing as described in the user guide of your phone. For the best result,

record the voice tag through your headset.

To increase or decrease the volume of the headset, press either volume

key until the satisfactory volume level is reached.

To end a call, press the end key on your mobile phone, or press the

answer/end key on your headset briefly.

9239356_hs36w_1_en.fm Page 8 Saturday, August 20, 2005 3:25 PM

Basic use

English

■Store the headset properly

Always store the headset with the power off and safely protected.

Avoid storage in high temperatures (above 60°C/134°F), such as in a hot

vehicle or in direct sunlight. Storage in high temperatures can degrade

performance and reduce the battery life. Low temperatures (down to

-10°C/14°F) shorten the battery life and may affect operation.

■Troubleshooting

The audio quality is poor.

For optimal performance, wear the headset and your mobile phone on

the same side of your body or in line of sight.

I have pairing problems even though my phone indicates otherwise.

You may have deleted the headset pairing in your mobile phone. Pair the

devices again.

There is no audio in the headset. Do the following:

• Increase the volume on the headset by pressing the volume up (+)

key.

• Ensure that the headset is paired with the phone.

• Make sure that the phone is connected to the headset. If not, try to

pair the devices again.

9239356_hs36w_1_en.fm Page 9 Saturday, August 20, 2005 3:25 PM

Battery information

4. Battery information

Your device is powered by a rechargeable battery. The full performance of a new

battery is achieved only after two or three complete charge and discharge cycles.

The battery can be charged and discharged hundreds of times, but it will

eventually wear out. Recharge your battery only with Nokia approved chargers

designated for this device.

Unplug the charger from the electrical plug and the device when not in use. Do

not leave a fully charged battery connected to a charger, since overcharging may

shorten its lifetime. If left unused, a fully charged battery will lose its charge over

time.

Use the battery only for its intended purpose. Never use any charger or battery

that is damaged.

Leaving the device in hot or cold places, such as in a closed car in summer or

winter conditions, will reduce the capacity and lifetime of the battery. Always try

to keep the battery between 15°C and 25°C (59°F and 77°F). A device with a hot

or cold battery may not work temporarily, even when the battery is fully charged.

Battery performance is particularly limited in temperatures well below freezing.

Do not dispose of batteries in a fire as they may explode. Batteries may also

explode if damaged. Dispose of batteries according to local regulations. Please

recycle when possible. Do not dispose as household waste.

9239356_hs36w_1_en.fm Page 10 Saturday, August 20, 2005 3:25 PM

Otros manuales para HS 36W

Tabla de contenidos

Otros manuales de Auriculares de Nokia

Nokia

Nokia HS-54W - Headset - Over-the-ear Guía de inicio rápido

Nokia

Nokia HS 3W Manual de usuario

Nokia

Nokia BH-903 - Headset - Ear-bud Manual de usuario

Nokia

Nokia BH-900 Manual de usuario

Nokia

Nokia BH-804 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH 103 - Headset - In-ear ear-bud Manual de usuario

Nokia

Nokia HS 26W - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH-302 Manual de usuario

Nokia

Nokia HDW 2 Manual de usuario

Nokia

Nokia BH 104 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia HS-54W - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH 202 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia Bluetooth Headset BH-701 Manual de usuario

Nokia

Nokia BH-215 Manual de usuario

Nokia

Nokia Comm Band Pro Manual de usuario

Nokia

Nokia N75 Manual de usuario

Nokia

Nokia BH-900 Manual de usuario

Nokia

Nokia HDE-2 - Headset - Ear-bud Manual de usuario

Nokia

Nokia BH-702 Manual de usuario

Nokia

Nokia hs-13w - Wireless Image Headset Manual de usuario

Nokia

Nokia BH105 - Bluetooth Headset Ice Manual de usuario

Nokia

Nokia HDW 3 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia HDW-1 Manual de usuario

Nokia

Nokia BH 300 - Headset - Over-the-ear Manual de usuario

Manuales populares de Auriculares de otras marcas

Sena

Sena SMH10 Manual de usuario

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manual de usuario

Sennheiser

Sennheiser EPOS ADAPT 230 Manual de usuario

Doro

Doro Flexus HS2005 Manual de usuario

GE 98971 Manual de usuario

Hama

Hama 00184070 Manual de usuario

Plantronics

Plantronics Blackwire 3200 Series Manual de usuario

Blue Tiger

Blue Tiger Advantage PLUS Manual de usuario

Jawbone

Jawbone Icon Manual de usuario

Jabra

Jabra FR 20 Manual de usuario

Roxcore

Roxcore Flow A+ Manual de usuario

Turtle Beach

Turtle Beach XP 510 Manual de usuario

Philips

Philips SHB6101 Manual de usuario

Jabra

Jabra PRO 9460 Duo Manual de usuario

HyperX

HyperX HyperX Cloud Flight Manual de usuario

Bose

Bose MIE2 Mobile Manual de usuario

Jabra

Jabra Steel Manual de usuario

HyperX

HyperX cloud ii Manual de usuario
