Nokia Bluetooth Headset BH-701 Manual de usuario

Nokia Bluetooth Headset BH-701

User Guide

9200782

Issue 1 EN

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this HS-74W product is in compliance

with the essential requirements and other relevant provisions of Directive 1999/5/

EC. A copy of the Declaration of Conformity can be found at

http://www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this document in

any form without the prior written permission of Nokia is prohibited.

Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other

product and company names mentioned herein may be trademarks or tradenames of their

respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and

improvements to any of the products described in this document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any

special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no

warranties of any kind, either express or implied, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose, are made in relation to the

accuracy, reliability or contents of this document. Nokia reserves the right to revise this

document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer

nearest to you.

Unauthorized changes or modifications to this device may void the user's authority to operate

the equipment.

Export Controls

This device may contain commodities, technology or software subject to export laws and

regulations from the US and other countries. Diversion contrary to law is prohibited.

9200782 / Issue 1 EN

Contents

1. Introduction ......................... 5

Bluetooth wireless technology........... 5

2. Get started ........................... 7

Overview................................................... 7

Chargers and batteries ......................... 7

Charge the battery ................................ 8

Switch the headset on or off.............. 9

Pair the headset ..................................... 9

Disconnect the headset ................. 10

Reconnect the headset .................. 10

Troubleshooting................................... 10

3. Basic use ............................. 12

Place the headset on the ear........... 12

Call handling ........................................ 12

Adjust the headset volume............... 13

Mute or unmute

the microphone ................................... 13

Switch the call between

headset and mobile device............... 13

Clear settings or reset........................ 13

4. Battery information ........... 15

Care and maintenance........... 16

Introduction

1. Introduction

With the Nokia Bluetooth Headset BH-701 you can make and receive calls

while on the move and use your mobile device hands free. You can use the

headset with compatible devices that support Bluetooth wireless

technology.

Read this user guide carefully before using the headset. Also read the user

guide for your mobile device, which provides important safety and

maintenance information. Keep the headset and its accessories out of

reach of small children.

■Bluetooth wireless technology

Bluetooth wireless technology allows

you to connect compatible devices

without cables. A Bluetooth connection

does not require that the mobile device

and the headset be in line of sight, but

the maximum distance between the

devices is 10 meters (30 feet). The closer

the mobile device and the headset are

to each other, the better is the

performance. The optimal operating

range is shown in dark grey in the

picture. The connection is subject to interference from distance and

obstructions (shown in light grey) or other electronic devices.

<10m

Introduction

The headset is compliant with the Bluetooth Specification 2.0 + EDR

supporting the following profiles: Headset Profile 1.1 and Hands-Free

Profile 1.5. Check with the manufacturers of other devices to determine

their compatibility with this device.

There may be restrictions on using Bluetooth technology in some

locations. Check with your local authorities or service provider.

Get started

2. Get started

■Overview

The headset contains the following parts:

• Earpiece (1)

• Indicator light (2)

• Charger connector (3)

• Volume key (4)

• Microphone (5)

• Earloop (6)

• Multifunction key (7)

Before you can start using the

headset, you must charge the battery and pair the headset with a

compatible device.

Parts of the headset are magnetic. Metallic materials may be attracted to the

headset. Do not place credit cards or other magnetic storage media near the

headset, because information stored on them may be erased.

■Chargers and batteries

Check the model number of any charger before using it with this headset. The

headset is intended for use with the AC-3, AC-4, and DC-4 chargers.

Get started

Warning: Use only batteries and chargers approved by Nokia for use

with this particular enhancement. The use of any other types may

invalidate any approval or warranty, and may be dangerous.

When you disconnect the power cord of any enhancement, grasp and pull the plug,

not the cord.

■Charge the battery

The headset has an internal, nonremovable, rechargeable battery. Do not

attempt to remove the battery from the headset, as you may damage the

headset.

1. Connect the charger to a wall outlet.

2. Connect the charger cable to the charger

connector. The indicator light is red while

charging. It may take a while before charging

starts. If charging does not start, disconnect

the charger, plug it in again, and retry.

Charging the battery fully may take up to 2 hours.

3. When the battery is fully charged, the indicator light turns green.

Disconnect the charger from the headset and the wall outlet.

The fully charged battery has power for up to 6 hours of talk time or up to

160 hours of standby time. However, the talk and standby times may vary

when used with different compatible Bluetooth devices, usage settings,

usage styles, and environments.

When battery power is low, the headset beeps at regular intervals, and the

indicator light flashes red.

Get started

■Switch the headset on or off

To switch on, press and hold the multifunction key until the headset beeps

and the indicator light turns on. When the headset tries to connect to a

paired device, the indicator light flashes green slowly. When the headset

is connected to a paired device and is ready for use, the indicator light

flashes blue slowly. If the headset has not been paired with a device, it

automatically enters the pairing mode (see “Pair the headset,” p. 9).

To switch off, press and hold the multifunction key for at least 5 seconds

until the indicator light turns red.

■Pair the headset

1. Ensure that your mobile device is switched on.

2. To pair the headset if it has not been previously paired with a device,

switch on the headset. The headset enters the pairing mode, and the

indicator light starts to flash blue quickly.

To pair the headset if it has been previously paired with another

device, ensure that the headset is switched off, and press and hold the

multifunction key until the indicator lights starts to flash blue quickly.

3. Activate the Bluetooth feature on the mobile device, and set it to

search for Bluetooth devices. See the user guide of your device for

instructions.

4. Select the headset (Nokia BH-701) from the list of found devices.

5. Enter the passcode 0000 to pair and connect the headset to your

device. In some mobile devices, you may need to make the connection

Get started

separately after pairing. See the user guide of your device for details.

You only need to pair the headset with your device once.

If the pairing is successful, the headset appears in the menu of the mobile

device where you can view the currently paired Bluetooth devices.

Disconnect the headset

To disconnect the headset from your mobile device, switch off the

headset, or disconnect the headset in the Bluetooth menu of your device.

You do not need to delete the pairing with the headset to disconnect it.

Reconnect the headset

To connect the headset to your mobile device, make the connection in the

Bluetooth menu of your device; or switch on the headset, and press and

hold the multifunction key for about 2 to 3 seconds until you hear a short

beep.

You can set your device to connect with the headset automatically when

the headset is switched on. To do this in Nokia devices, change your paired

device settings in the Bluetooth menu.

■Troubleshooting

If you cannot connect the headset to your mobile device, do as follows:

• Ensure that the headset is charged, switched on, and paired with your

device.

• Ensure that the Bluetooth feature is activated on your device.
