Nokia HDW 3 - Headset - Over-the-ear Manual de usuario

User’s Guide for the Wireless

Headset (HDW-3)

9234572

Issue 1

9234572_hdw3_1_en.fm Page 1 Friday, September 2, 2005 3:08 PM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the product HDW-3

is in conformity with the provisions of the following Council Directive: 1999/5/EC.

A copy of the Declaration of Conformity can be found from

http://www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this

document in any form without the prior written permission of Nokia is prohibited.

Nokia is a registered trademark of Nokia Corporation. Other product and company names

mentioned herein may be trademarks or tradenames of their respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of continuous development. Nokia reserves the right to make

changes and improvements to any of the products described in this document without

prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any

special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law,

no warranties of any kind, either express or implied, including, but not limited to, the

implied warranties of merchantability and fitness for a particular purpose, are made in

relation to the accuracy, reliability or contents of this document. Nokia reserves the right

to revise this document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia

dealer nearest to you.

9234572

Issue 1

9234572_hdw3_1_en.fm Page 2 Friday, September 2, 2005 3:08 PM

Contents

1. Introduction ......................... 4

Bluetooth wireless technology .......... 4

Chargers and batteries......................... 5

The card in the sales package ............ 5

2. Getting started..................... 6

Overview................................................... 6

Charging the battery ............................ 7

When the battery charge falls low 8

Switching the headset on or off ....... 8

Taking the headset into use for the

first time................................................... 8

Adjusting the headset to your ear .. 10

Placing the headset on the ear........ 11

Troubleshooting.................................... 11

3. Using the headset .............. 12

Connecting the paired headset to

your phone............................................. 12

Making a call ........................................ 13

Voice dialling ........................................ 13

Redialling the last dialled number. 13

Answering a call.................................. 14

Ending a call......................................... 14

Rejecting a call.................................... 14

Automatic answer............................... 14

Adjusting the earphone volume ..... 14

Switching the call between

phone and headset............................. 15

Disconnecting the headset from

the phone.............................................. 15

Reconnecting the paired

headset to your phone................... 16

Using the headset with several

phones.................................................... 16

Using the headset with several

paired phones ................................... 16

Resetting the headset........................ 17

4. Battery information ........... 18

Care and maintenance........... 20

English

9234572_hdw3_1_en.fm Page 3 Friday, September 2, 2005 3:08 PM

Introduction

1. Introduction

The Wireless Headset HDW-3 can be connected without wires to a

compatible phone that supports Bluetooth wireless technology. This gives

you complete freedom for making and receiving calls while on the move

or at the office.

Read this user’s guide carefully before using the headset. More detailed

information is provided by your phone's own user's guide. Do not use this

Wireless Headset (HDW-3) user’s guide in place of the user’s guide for

your phone, which provides important safety and maintenance

information.

■Bluetooth wireless technology

Since Bluetooth devices communicate using radio waves, your Bluetooth

phone and headset do not need to be in a line of sight. The two devices

only need to be within a maximum of 10 meters of each other, although

the connection can be subject to interference from obstructions, such as

walls, or from other electronic devices.

The headset is specially designed for Nokia phones that support Bluetooth

wireless technology. The headset can, however, be used with any

compatible Bluetooth devices that support the Handsfree or Headset

profile. (Here, "Profile" means a set of Bluetooth commands that your

phone uses for controlling the headset.)

9234572_hdw3_1_en.fm Page 4 Friday, September 2, 2005 3:08 PM

Introduction

English

The headset provides the best performance when it is used with a

compatible Nokia phone. If you use the headset with a phone produced by

another manufacturer, all the functions described in this user’s guide may

not be available.

In some countries, there may be restrictions on using Bluetooth devices.

Check with your local authorities.

■Chargers and batteries

Check the model number of any charger before use with this device. The

Wireless Headset HDW-3 is intended for use with the following chargers:

ACP-7, ACP-8, ACP-9, ACP-12 and LCH-12.

Warning! Use only batteries and chargers approved by Nokia for

use with this particular accessory. The use of any other types will

invalidate any approval or warranty, and may be dangerous.

For availability of approved batteries and chargers, please check with your

dealer.

When you disconnect the power cord of any enhancement, grasp and pull

the plug, not the cord.

■The card in the sales package

The card contains the Bluetooth passcode 0000 you need for pairing your

phone with the headset. Keep this card in a secure place.

For instructions on using the passcode, see Taking the headset into use for

the first time on page 8.

9234572_hdw3_1_en.fm Page 5 Friday, September 2, 2005 3:08 PM

Getting started

2. Getting started

■Overview

The headset contains the following parts:

1 - Power key: Switches the headset on and off.

2 - Answer/end key: Answers or ends the call. This key can also be used

for voice dialling, redialling and switching an active call between the

headset and the phone.

3 - Indicator light: Displays the current status of the headset.

4 - Volume up: Increases the earphone volume during a call.

5 - Volume down: Decreases the earphone volume during a call.

9234572_hdw3_1_en.fm Page 6 Friday, September 2, 2005 3:08 PM

Getting started

English

6 - Earphone: Relays the caller’s voice.

7 - Microphone: Picks up your voice.

8 - Charger connector

9 - Battery door

10 - Earloop

■Charging the battery

The headset has a rechargeable NiMH battery.

To charge the battery:

1. Connect the charger cable to the headset. For a list of compatible

chargers, see Chargers and batteries on page 5.

2. Connect the charger to an AC wall outlet. The red indicator light is

displayed during charging. Charging the battery fully takes between 1

and 2 hours, depending on the charger.

9234572_hdw3_1_en.fm Page 7 Friday, September 2, 2005 3:08 PM

Getting started

3. When the battery is fully charged, the green indicator light is shown.

Disconnect the charger from the AC wall outlet and the headset.

When the battery charge falls low

The fully charged battery has power for up to 5 hours of talk time and up

to 120 hours of standby time. (In standby mode, the headset is switched

on but no call is in progress.)

When the battery is running out of power, the headset beeps and the red

indicator light starts to blink. Charge the battery as described above.

■Switching the headset on or off

To switch on: Press and hold the power key for 2 seconds. The headset

beeps and the green indicator light starts blinking fast. The blinking

continues slower after the headset is connected to your phone.

To switch off: Press and hold the power key for 2 seconds. The headset

beeps and the red indicator light is displayed briefly.

■Taking the headset into use for the first time

1. Make sure that your phone is switched on.

2. Switch on the headset.

3. Enter the Bluetooth menu of your phone and make sure that the

Bluetooth feature is activated.

9234572_hdw3_1_en.fm Page 8 Friday, September 2, 2005 3:08 PM

Getting started

English

4. Enter the submenu where you can set the phone to search for

Bluetooth devices, and start the search.

The phone searches for all Bluetooth devices within about 10 meters

and displays them as a list.

5. Select the headset from the list.

6. Enter the passcode 0000 to associate ("pair") and connect the headset

to your phone. If you do not pair the headset with the phone within 5

minutes, it will power off, when pairing the headset for the first time.

Once you have entered the passcode, your phone becomes the default

phone for the headset, if the headset has not been previously paired

with another phone. See also Using the headset with several phones

on page 16.

The headset beeps and appears in the phone menu where you can view

the Bluetooth devices that are currently paired with your phone.

7. Start using the headset (see page 12).

9234572_hdw3_1_en.fm Page 9 Friday, September 2, 2005 3:08 PM

Getting started

■Adjusting the headset to your ear

The headset can be worn on either ear.

For optimal fit, choose between the different-sized earloops provided in

the sales package.

To change the orientation of the earpiece, detach the earloop from the

body part as shown in the figure below, and place it back according to the

L/R markings on the earloop. L stands for the left ear, and R stands for the

right ear. When, for example, the R marking is visible, you can wear the

headset on your right ear.

9234572_hdw3_1_en.fm Page 10 Friday, September 2, 2005 3:08 PM
