Nextar MA110 Manual de usuario
MA110 | Digital MP3 Player
Instruction Manual
Contents
1. Feature summary................................1
2. Introduction.........................................2
3. Getting to know the player..................3
4. Basic functions...................................4
5. A-B repeat..........................................6
6. Menu selections.................................7
7. Settings submenu..............................8
8. Voice recording..................................9
9. Deleting les.....................................10
10. Line-in function...............................10
11. Internal memory..............................11
12. Equalizer.........................................11
13. Repeat play.....................................12
14. Backlight settings............................13
15. Auto power settings........................14
16. Bitrate settings................................14
17. Screen saver settings.....................15
18. Language settings..........................15
19. Exiting menus.................................16
20. Play folder.......................................16
21. Multimedia card..............................17
22. Setup and software.........................17
23. Troubleshooting..............................18
24. Specications..................................21
25. Precaution .....................................22
1
THANK YOU
Thank you for purchasing our Digital MP3 Player. This uniquely designed device combines
an MP3 Player, voice recorder; Removable Flash Memory drive all in one unit. You can
move and store les between computers and enjoy your MP3 music collection anytime and
anywhere.
1. FEATURE SUMMARY
Firmware Upgradable
Check our website often for the latest driver, rmware and software updates:
www.nextar.com
Removable Disk
Use this unit as a removable drive, storing les, music or anything you want (drivers required
for operating systems prior to Windows 2000)
Voice Recording
Record your voice with the built-in microphone and save in WAV or ACT formats. Playback
your recording at any time.
Six Preset Equalizer
Built-In equalizer can be set to Normal, Rock, Pop, Classical, Jazz or Bass.
Multiple Playback Modes
Unique A-B repeat function allows users to specically select playback
2
High Resolution LCD w/ Seven Color Backlight
High resolution display with graphical menus and mulitcolor backlight
USB Connection
Quick connection to USB port.
Multiple Format Support
This unit supports the popular MP3 format for the widest compatibility of digital les. It also
supports WMA (Windows Media Audio) for greater compatibility and compression options
2. INTRODUCTION
Thank you for purchasing our MP3 player. Before using the unit please read this manual
carefully to obtain the best possible performance from your player. Keep this manual for
future reference
3
3. GETTING TO KNOW THE PLAYER
Appearance and Controls
Hook
LCD
Power on
Play/Pause
Power off
Earphone
Line in
Mode
Next
Prev
Vol+
Vol-
Hold
4
4. BASIC FUNCTIONS
Start up/Shutdown
Start up or shutdown player by pressing and holding the “PLAY” button.
Entering Menu Modes
Menus: Main menu (entered by momentarily holding Mode key when not playing), Play
submenu (entered by pressing Mode key while playing), and Stop submenu (entered by
pressing Mode key when not playing).
Browsing Tracks
Browse forward (to the next track) by pressing the NEXT button, and backward (previous
song) by pressing the PREV.
Using the Different Function Modes
Press and hold the MODE button for 2 sec. This will take you to the Main Menu. From here,
use the PREV and NEXT buttons to move to the various menus options. Select the menu
option by again pressing the MODE button. To exit the menus, press the NEXT button until
the EXIT option appears. Press MODE to exit
5
Adjusting Volume
Decrease volume by pressing the “ - “ side of the - VOLUME + button. Increase volume by
pressing the “+” side of the switch.
(HOLD) Function
Move the HOLD switch to the position showing the closed lock (left).
When Hold is ON, all controls are locked out and a lock icon appears in the center top of the
LCD display. If you press any controls, you will see on the display: KEY LOCKED
Be sure to switch the HOLD button to the UNLOCK position (right) to use the unit.
6
5. A-B REPEAT
Using the A-B Repeat Function
Press the Mode button to enter the repeat function while playing. The LCD display will show
“A-”(start point). Press the Mode button again at the end of the section you want to repeat,
and it shows “A-B”(end point). Press the Mode button the third time to quit the A-B repeat
mode.
Setting start point A
Setting end point B
A-B mode off
7
6. MENU SELECTIONS
Menu operation
Press the PLAY button to power on. Press the MODE button to open the main menu, the
function menu options will be shown. The various selections are shown below:
Music
Voice
MIC Record
LINE IN
Settings
Delete
Information
Browser
Exit
Making Selections
Use the PREV or NEXT buttons to move to the desired menu selection. To access that
menu or it’s submenu, press MODE once the selection is highlighted
8
7. SETTINGS SUBMENU
Submenu operation
Press the PLAY button to power on. Press the MODE button to open the main menu, the
function menu options will be shown. Scroll through the menus with the PREV or NEXT
buttons until you reach the SETTINGS submenu.
Press MODE again to access this submenu:
EQ
Repeat
Contrast
Backlight ON
Color
Screen Save
Power off
Rec Bitrate
Language
Exit
Making Selections
Use the PREV or NEXT buttons to move to the desired submenu selection. To access
that submenu, press MODE once the selection is highlighted.
