Nextar MA555 Manual de usuario

MA555

| Digital MP3 Player

Instruction Manual

1. INTRODUCTION

Thank you for purchasing our MP3 player.

Before using the unit please read this

manual carefully to obtain the best possible

performance from your player. Keep this

manual for future reference

2. SAFETY INSTRUCTIONS

Never use the player during driving or

operating other vehicles to avoid trafﬁ c

accident, which also be written in the law in

some districts. Even in walking especially

crossing the street, please also do not

listen in extremely high volume to avoid

any dangerous. Wherever with potential

risks, please stop using the player for safety

purpose.

Please insert the earphone prior to turn

on the player, which can not only avoid

damaging the earphone but keep the player

in good condition.

Keep the player clean and never store the

player close to the heat source or dirty, humid

or rainy places and avoid direct sunlight.

If the surface is dirty, please clean with soft

cloth wet with clean water or soft abluent

and never clean the case with alcohol or

diluents.

Never use the player in extremely dry

environment to avoid static.

Never disconnect the player from PC

abruptly during downloading, uploading and

formatting to avoid program failure.

When the player is used as removable disk,

please follow the proper ﬁ le download and

upload procedures. Our company resumes

no responsibility for any ﬁ le lost due to

misuse.

3. SYSTEM REQUIREMENTS

• Microsoft Windows98/2000/Me/XP

• Pentium 200MHZ or above

• 120MB hard disk space

• USB

• Mouse installed

• CD-ROM drive

4. INSTALLATION

Installing driver for Windows 98.

(Windows ME or above without driver

required)

Connect the MP3 Player to the USB port of

PC, "Find new hardware" appears on the

screen, click "Search latest driver for this

device"

And insert the driver CD in to CD-ROM, and

then click "Next". Select "Look in" to direct

the installation directory to the "Drivers" ﬁ les

in driver CD, then click Yes.

PC will install the Win 98 driver

automatically.

Installing battery

Install one 7# 1. 5V alkaline battery properly

upon indicator on the player.

Press and hold((button to enter MP3 standby

mode.

5. CONNECTING AND DOWNLOADING

Connecting PC

Before operation, please verify the player is

turned off with one end of the included USB

cable inserted into PC and another end into

the MP3 player.

Downloading MP3 music

Download MP3 music to MP3 player.

Removing USB device

Double click the Safely Remove Hardware

icon in taskbar:

From Safely Remove Hardware screen,

highlight "USB Mass Storage Device" item,

then click "Stop" button. "Stop to Hardware

Device" window appears on the screen as

shown below.

Click "OK" button. After the "Safe to Remove

Hardware" window appears, the player can

be disconnected from PC safely.

Notice: Never unplug the USB cable during

data transmitting to avoid any failure to the

Player; after data transmitting, please do not

disconnect the player from PC until "Device

now be safely removed" appears; while

using USB function, all other buttons will

be nonfunctional. Any program lost or I/O

error and power on issues caused by these

improper operations please refer to FAQ.

6. BASIC OPERATION

Buttons and functions

1. Microphone

2. Earphone jack

3. HOLD button

4. REC /A-B play

5. next, fast forward

6. Volume up/ V+

7. last, fast backward

8. Volume down/ V–

9. MENU button

10. Play/ Pause/ Stop

11. USB port

Turning on/off

From shutdown mode, press



3 seconds

to power on .Firstly player will update the

music library then create new music play

list after ﬁ nish update. Lastly player enter

MP3 standby mode.

emo

cleW

um gn

tadpu

sil

gnita

From MP3 standby, pause and play mode,

press and hold



seconds, the system will

save the data and enter shutdown mode.

Notice: Please don’t take out the battery from

the battery cell directly to power off while in the

MP3 stand-by mode or during playing music,

otherwise, you may lose the unsaved data.

MENU function

From standby, pause or play mode, press

MENU button to enter main setting mode.

Press





or  or

button to select: Music,

Voice, Music Library, Settings, About, Exit,

and press button to enter the

appointed setting.

7. HOW TO USE THE MP3 PLAYER

Playing MP3 ﬁ les

From MP3 standby mode, you can press the



button to play MP3 music as well as

pause and resume playing.

esua

yalp

From play or pause mode, you can press

the



button for 2 seconds to return to

MP3 standby mode, and press



button

again to resume playing.

From MP3 standby or Play mode, you can

press the





or  or

button to select last or

next music.

From STOP status, you can keep holding

the





or  or

button to effectively ﬁ nd and

play your desired music.

From play mode, you can press the





button to fast backward or forward this

music.

f.From play mode, you can press V + or V-

button to adjust volume.

From MP3 standby, play or pause mode,

press



button for 3 seconds, the player

will save the data and enter shutdown

mode.

Setting voice mode

From MP3 mode or voice standby mode, you

can press the MENU button to enter the main

menu setting, and press the





or  or

button to

select Voice, and then press the



button to

enter the voice playing mode, during which you

can repress



button to pause and resume

From MP3 mode or voice standby mode, you can

keep pressing the REC button to enter the setting

while the player begin recording, repress REC

button to ﬁ nish recording and save with WAV

format into the Voice record folder of the music

library, and then press the



button to play

voice as well as pause and resume playing.

pots

dro

ceR

idrocer

Voice play mode includes: Normal, repeat

one, repeat all, shufﬂ e, shufﬂ e repeat.

��

�

roN

lla tae

uhs

per

uhs .weiverp

From voice standby or play mode, you can

press the





or  or

button to select last or

next voice ﬁ le.

From the STOP status, you can press the





or  or

button to effectively ﬁ nd and play

your desired music.

From Play mode, press and hold





button to fast backward or forward this

music.

Voice EQ mode includes: normal ,rock, jazz,

classical , pop , bass ,treble.

From Play mode, press the



button

continuous you can turn to the MP3 mode

from voice mode.

Music Library

From MP3 mode or voice standby mode,

you can press the MENU button to enter

the main menu, and push the





or  or

button to select music library, and press the



button to enter which includes: Play

all, Artist, Album, Track , Genre, Year, Voice

record and Exit, press MENU button to

return to forward menu.

Play all

Under the Music Library mode ,press the





or  or

button to select play all function ,press

the



button to select and then the player

begin playing all the songs saved in it.

Artist

Under the Music Library mode ,press the





or  or

button to select artist function ,All the

songs will be sorted according to the artist.

you can select certain artist which you love,

or select the play all then press the



button to conﬁ rm. then the system will play

automatically. You can press REC button to

enter the delete mode, when you enter the

track mode,repress the





or  or

button to

select “YES” or ”NO”, repress



button to

conﬁ rm delete. Select NO to exit.

Album

Under the Music Library mode, press the





or  or

button to select Album function, the

ﬁ les saved in it, you can select certain ﬁ le

which you love, or select the play all then

press the



button to conﬁ rm. then the

system will play automatically. You can press

REC button to enter the delete mode, when

you enter the track mode, repress the





button to select “YES” or “NO”. Repress



button to conﬁ rm delete. Select NO

to exit.

Track

Under the Music Library mode ,press the





or  or

button to select track function ,All the

songs will be sorted according to the track.

you can select certain track which you love,

or select the play all then press the



button to conﬁ rm. then the system will play

automatically. You can press REC button to

enter the delete mode when you enter the

track mode,repress the





or  or

button to

select “YES” or ”NO”, repress



button to

conﬁ rm delete. Select NO to exit.

Genre

Under the Music Library mode, press the





or  or

button to select genre function

,All the songs will be sorted according to the

genre. you can select certain genre which

you love, or select the play all then press

the



button to conﬁ rm. then the system

will play automatically. You can press REC

button to enter the delete mode when you

enter the track mode,repress the





or  or

button to conﬁ rm delete. Select NO to exit.

Year

Under the Music Library mode, press the





or  or

button to select year function ,All the

songs will be sorted according to the elapsed

time. you can select certain song which you

love, or select the play all then press the



button to conﬁ rm. then the system will play

automatically. You can press REC button to

enter the delete mode when you enter the

track mode,repress the





or  or

button to

select “YES” or ”NO”, repress



button to

conﬁ rm delete. Select NO to exit.

Voice record

Under the Music Library mode ,press the





or  or

button to select Voice record function, All

the voice ﬁ les are saved in this folder, you can

select certain ﬁ le which you love, or select the

play all then press the



button to conﬁ rm.

then the system will play automatically. You can

press REC button to enter the delete mode,

when you enter the track mode,repress the





button to select “YES” or ”NO”, repress



button to conﬁ rm delete. Select NO to exit.

Exit

Under the Music Library mode, press the





or  or

button to select exit function, press

the



button to return forward mode.

repress the



button or press the MENU

button to the play mode.

Function Setting

From MP3 mode or voice standby mode,

you can press the MENU button to enter

the main menu, and press the





or  or

button to select the setting menu. The

setting menu includes: EQ set, play mode,

contrast, display time, power set, record set,

text scroll speed ,language, load default and

exit. press



button to enter the setting

which you want.

Tabla de contenidos

Otros manuales de Reproductor de MP3 de Nextar

Nextar

Nextar MA177 Manual de usuario

Nextar

Nextar ma977 Manual de usuario

Nextar

Nextar MA566 Manual de usuario

Nextar

Nextar MA797 Manual de usuario

Nextar

Nextar MA593 Manual de usuario

Nextar

Nextar MA99T Manual de usuario

Nextar

Nextar MA852s Manual de usuario

Nextar

Nextar MA206 Manual de usuario

Nextar

Nextar MA809 Manual de usuario

Nextar

Nextar MA99T Manual de usuario

Nextar

Nextar MA201 Manual de usuario

Nextar

Nextar MA589 Manual de usuario

Nextar

Nextar MA933ASC Manual de usuario

Nextar

Nextar MA323 128MB Manual de usuario

Nextar

Nextar MA933A - 128 MB Digital Player Manual de usuario

Nextar

Nextar MA188 Manual de usuario

Nextar

Nextar MA166 Manual de usuario

Nextar

Nextar MA791 - 4GB MP3 Player Manual de usuario

Nextar

Nextar MA750 Manual de usuario

Nextar

Nextar MA933A - 128 MB Digital Player Manual de usuario

Nextar

Nextar MA828 Manual de usuario

Nextar

Nextar MA828 Manual de usuario

Nextar

Nextar MA968 Manual de usuario

Nextar

Nextar MA566 Manual de usuario

Manuales populares de Reproductor de MP3 de otras marcas

Blaupunkt

Blaupunkt Compact Drive MP3 Manual de usuario

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manual de usuario

Meizu Electronic Technology

Meizu Electronic Technology E5 Manual de usuario

Naxa

Naxa NMV-173NX Manual de usuario

Philips

Philips PSA250 Manual de usuario

Zipy

Zipy go! Waving Manual de usuario

Sylvania

Sylvania SMPK4068 Manual de usuario

Sony

Sony NW-MS7 - Memory Stick Walkman Manual de usuario

Irradio

Irradio RF-42UC Manual de usuario

NABAIJI

NABAIJI SWIM MUSIC 100 Manual de usuario

Laser

Laser MP3-A9-4GB Manual de usuario

Samsung

Samsung YP-T7F Manual de usuario

Savant

Savant SMS-1001-00 Guía de referencia rápida

Trevi

Trevi XP 71 BT Manual de usuario

AGPtek

AGPtek C2 Manual de usuario

MobiBlu

MobiBlu DAH-1500i Manual de usuario

Denver

Denver MPS-201 Manual de usuario

Steren

Steren MP3-002 Manual de usuario
