Nextar MA97T Manual de usuario

MA97T OPERATION MANUAL

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS : ( 1) THIS DEVICES MAY NOT

CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY

INTERFERENCE, RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

Note: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

Installed and used in accordance with the instructions, may cause harmful interference

to radio ommunications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference

to radio or television reception, which an be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

NOTE: THEMANUFACTURER IS NOT RESPONSIBLEFOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY

TO OPERATE THE EQUIPMENT.

FCC Certification

Table of Contents

1. Announcement 1

● Display synchronized lyrics (Karaoke function) 10

● Sound effect mode 9

● Simple operation 9

6. Play music 8

5. Operation 6

● Press PLAY 5

● Adjust volume 5

● Start up/shutdown 4

● Use different function modes 4

● Browse Tracks 4

● Enter a menu 4

4. Basic functions 4

● Display screen 3

3. Getting to know the player 3

2. Function summary 2

● Appearance and keystroke 3

● Music mode , Play mode 6

● Record mode 7

● FM mode 7

● Add and delete files 8

● Choose record type 11

● Record mode 11

7. Voice recorder 10

15. Definition 25

14. Important recommendation 24

● Replay separation (play submenu) 23

● Replay times (play submenu) 23

● Replay mode (play submenu) 22

● Tempo rate (play submenu) 21

● Play mode (play submenu) 21

16. Troubleshooting 26

17. Technical specifications 27

8. Transfer recorded file of ACT into WAV on your PC 12

10. System Setup 14

● Choose different directories (stop submemu) 20

13. Miscellaneous settings 20

12. Upgrade player 19

● New folder 18

11. Use USB disk 18

● Detailed operating instructions 15

● Brief introduction to every options 14

● How to enter 14

9. How to use FM 13

● Play recorded files 12

● Digital Audio for mats

MP1, MP2, MP3, WMA, WMV, ASF, WAV (Easy to work with Windows Media Player).

2. Function summar y

● Firmware upgrades (Check periodically)

www.nextar.com will provide the latest software upgrades and functions.

● Function of free-drive U disk

Manipulate files via the "mobile disk" in "My PC" without any additional programs on

your PC(drive program needs to be installed for operating systems prior to WIN2000).

● "Dream-space" disk mode

Enables you to separate the storage disk via the "mobile disk" in "My PC" into two

disks using the utilities included on the accompanying CD and encrypt one of those

disks to hide the disk space. This encrypted space can then not be read by others.

● Record/Replay

Record your voice with the microphone and save as WAV or ACT. You can then choose

to replay that all such recordings or to replay selected recordings.

Thanks for purchasing our MP3 player. Before using the unit please read this

manual carefully to obtain the best possible performance from your player and

keep it for future reference.

1. Announcement

● Seven tone equalizer

Can be set to Natural, rock, pop, classical, soft, jazz or heavy bass.

● various play modes

Can be set to Natural, cycle single song, play directories, cycle directories, cycle all,

shuffle or browse.

● Shutdown timer

Sleep mode and power-save mode to simplify and extend battery use.

● USB connection

Quick connection to USB port.

● Built-in FM radio

You may easily listen to FM stations and set your favourite stations by using Auto

Preset or Manual Preset. The player can save 40(20 for each Band) local stations

at different frequency.

3. Getting to know the player

● Appearance and keystroke

USB Earphone hole

Power switch

Volume+

Volume-

Power/Play/

Pause/Stop

Mode

Equalizer

On Off

LCD display

● Full-cartoon menu

Graphic menus with corresponding text display.

Display screen

Play state Song number

Singer/Name of song

Sound effect mode/Replay mode/Follow and contrast

Play time

Display electric quantity

Cycle mode

Work mode

Aqua Barbie girl.mp3

Star t up/shutdown

First time, you should dial the Power switch to the position of On, the player will

start up automatically. To shutdown player by press and hold PLAY or dial the

Power switch to the position of Off.

4. Basic functions

Enter a menu

Menus: Main menu (entered by momentarily holding Mode key when not playing),

Play submenu (entered by pressing Mode key while playing), and Stop submenu

(entered by pressing Mode key when not playing).

Browse Tracks

 Browse forward by sliding Mode key clockwise and backward by sliding Mode

key anti-clockwise;

 Skip track forward or backward while playing song by sliding and holding Mode

key clockwise or anti-clockwise;

 Skip to next track or back to previous track while playing song by sliding and

Mode key clockwise or anti-clockwise.

Go into different modes from main menu by sliding Mode key clockwise or

anti-clockwise then pressing Mode key:

Use different function modes

Select Music mode, display

shows something like this:

Aqua Barbie girl.mp3

Main menu:

Select Record mode, display

shows something like this: Select Play mode, display

shows something like this:

Select System setup, display

shows this:

Reco r d Ti m e

Enter USB mode by connecting with PC:

Select FM mode, display

shows something like this:

Press PLAY

Play or stop (or pause while recording); exit from submenu.

Adjust volume

Decrease volume by pressing VOL-; increase volume by pressing VOL+.

Batter y recharge

Connect MP3 player to PC via the USB cable, the battery will recharge

automatically. If the battery icon on the player screen flicker ceaselessly,

that means the battery is recharging, otherwise means it is full, not need

to recharge.

Attention:

Please dial the Power switch to the position of ON before you connect

the MP3 player to PC, otherwise the battery icon on the player screen will

not flicker anytime, so you can't see the recharge status.

5. Operation

● Music mode , Play mode

KEY Action Stop state Play state Play submenu Stop submenu

Play

Shutdown ShutdownShutdown Shutdown

Hold

Play Stop Exit from menu Exit menu

Mode

Enter main menu Enter main menu Enter main menuEnter main menu

Enter/stop

submenu

Select option or

enter next level

Enter/play

submenu

Long press

Press

Last

Vol+

Vol-

Dial Next song Next song and

play it Move submenu Move submenu

Browser forward

continuously Skip forward

Press

Last song Last song and

play it Move submenu Move submenu

Browser backward

continuously Skip backward Move backward

continuously

Increase volume

continuously

Decrease volume

continuously

Decrease volume

continuously

Press

Move forward

continuously

Increase volume

by one step

Hold Move forward

continuously

Dial

Hold Move backward

continuously

Hold

Increase volume

continuously

Increase volume

by one step

Decrease volume

by one step

Decrease volume

by one step

Select option or

enter next level
