Nextar Digital MP3 Player Manual de usuario

Instruction Manual

Thank you for purchasing our Digital MP3 Player. This uniquely designed device

combines an MP3 Player and removable Flash Memory drive all in one unit. You can

move and store files between computers and enjoy your MP3 music collection anytime

and anywhere.

Multiple Format Support

Supports MP3 and WMA (Windows Media Audio) files

Voice recorder

Voice recording for voice notes capability

19 Preset equalizer

Built-In equalizer can be set to 19 different preset and customized settings.

Multiple Playback Modes

Unique A-B repeat function allows users to specifically select playback

USB Connection

Quick connection to high-speed USB 2.0 port.

rechargeable Battery

Li-Ion rechargeable battery with up to 15 hour playback time

Before using the unit please read this manual carefully to obtain the best

possible performance from your player. Keep this manual for future

reference

Installing driver for Windows 98. (driver is not required for Windows Me

or above)

a. Connect the MP3 Player to the USB port of PC, “Find new

hardware”

appears on the screen, click “Search latest driver for this device”.

b. Insert the driver CD in to CD-ROM, and then click “Next”.

Select “Look in” to direct the installation directory to the “Drivers” files in

driver CD, then click Yes. PC will install the Win 98 driver automatically.

We suggest the player to be charged for 12 hours for the initial

use and 2 to 3 hours next time.

Connecting a PC as USB

Before operation, plug one end of the USB cable into your PC and the other

end into the MP3 player.

downloading MP3 music

a. Writing refers to copying files from the computer and pasting

them into the device.

b. Reading refers copying files from the device and pasting them

into the computer.

Attention: The MP3 player with memory under 128MB cannot be formatted to FAT-32 in the operation system,

since the original software has the high speed flash feature.

Removing USB device

a. Double click the Safely Remove Hardware icon in taskbar:

b. From Safely Remove Hardware screen, highlight the “USB

Mass Storage Device ”item, then click the “Stop” button. “Stop to Hardware

Device” window appears on the screen as shown below.

notice: Never unplug the USB cable during data transmitting to avoid any failure to the player; after data

transmitting, please do not disconnect the player from PC until “Device can now be safely removed” appears; while

using USB function, all other buttons will be

nonfunctional. Refer to the FAQ for any lost files, I/O

Buttons and functions

1 A-B/REP

2 Play/Pause/Stop

3 M button

4 REC

5 Vol+

6 Reset

7 Next

8 Vol

9 USB port

10 Last

11 Hold

12 EQ

13 LCD display

14 Microphone

Turning on/off

ٛa. From shutdown mode, press the ►|| button to power the

player on and display the “welcome” text, then enter into MP3 standby

mode.

ٛb. From MP3 standby, pause and play mode, keep pressing ►||

button, the system will save the data and enter shutdown mode.

Power Off
