USER GUIDE

SCC-A10 Voltage Attenuator Module

The SCC-A10 voltage attenuator module accepts up to two voltage sources

of 60 V maximum amplitude and attenuates each voltage by a factor of 10.

A differential instrumentation amplifier buffers each input signal. The

SCC-A10 contains circuitry capable of protecting E/M Series DAQ

devices for input signals up to 60 VDC.

Conventions

The following conventions are used in this guide:

<> Angle brackets that contain numbers separated by an ellipsis represent

a range of values associated with a bit or signal name—for example,

AO <3..0>.

»The »symbol leads you through nested menu items and dialog box options

to a final action. The sequence File»Page Setup»Options directs you to

pull down the File menu, select the Page Setup item, and select Options

from the last dialog box.

This icon denotes a note, which alerts you to important information.

This icon denotes a caution, which advises you of precautions to take to

avoid injury, data loss, or a system crash. When this symbol is marked on

the product, refer to the Read Me First: Safety and Radio-Frequency

Interference document, shipped with the product, for precautions to take.

When symbol is marked on a product, it denotes a warning advising you to

take precautions to avoid electrical shock.

When symbol is marked on a product, it denotes a component that may be

hot. Touching this component may result in bodily injury.

bold Bold text denotes items that you must select in software, such as menu

items and dialog box options. Bold text also denotes parameter names.

SCC-A10 Voltage Attenuator Module User Guide 2 ni.com

italic Italic text denotes variables, emphasis, a cross reference, or an introduction

to a key concept. Italic text also denotes text that is a placeholder for a word

or value that you must supply.

monospace Text in this font denotes text or characters that you should enter from the

keyboard, sections of code, programming examples, and syntax examples.

This font is also used for the proper names of disk drives, paths, directories,

programs, subprograms, subroutines, device names, functions, operations,

variables, filenames, and extensions.

SC-2345 SC-2345 refers to both the SC-2345 connector block and the SC-2345

configurable connector.

SCC SCC refers to any SCC Series signal conditioning module.

What You Need to Get Started

To set up and use the SCC-A10, you need the following items:

❑Hardware

–SCC-68

– SC-2345/2350 with one of the following:

• SCC-PWR01

• SCC-PWR02 and the PS01 power supply

• SCC-PWR03 (requires a 7 to 42 VDC power supply, not

included)

– One or more SCC-A10

– 68-pin E/M Series DAQ device

– 68-pin cable

– Quick Reference Label

❑Software

– The latest version of NI-DAQmx

❑Documentation

–SCC-A10 Voltage Attenuator Module User Guide

– SCC-68 User Guide

–SC-2345/2350 User Manual

–SCC Quick Start Guide

©National Instruments Corporation 3 SCC-A10 Voltage Attenuator Module User Guide

–Read Me First: Safety and Radio-Frequency Interference

– Documentation for your hardware

– Documentation for your software

❑Tools

– 1/8 in. flathead screwdriver

– Numbers 1 and 2 Phillips screwdrivers

– Wire insulation stripper

Note Software scaling of measurements is not supported on the Macintosh operating

system. Refer to the SCC-A10 Module Pin Assignments section.

You can download NI documents from ni.com/manuals. To download

the latest version of NI-DAQmx, click Download Software at ni.com.

Device Specific Information

Note For general SCC module installation and signal connection information, and

information about the SC-2345/2350 and SC-68, refer to the SCC Quick Start Guide,

available for download at ni.com/manuals.

Installing the Module

Caution Refer to the Read Me First: Safety and Radio-Frequency Interference document

before removing equipment covers or connecting/disconnecting any signal wires.

You can plug the SCC-A10 into any analog input socket on the

SC-2345/2350 or SCC-68. The socket you choose determines which E/M

Series DAQ device channels receive the SCC-A10 signals, as explained in

the SCC Quick Start Guide.

For single-stage input conditioning, plug the SCC-A10 into any slot of the

SC-68, or any socket of the SC-2345/2350 J(X+1), where Xis 0 to 7.

Connect the input-signal wires to the module as described in the SCC Quick

Start Guide.

If you use the SCC-A10 in a dual-stage configuration in an SC-2345, the

SCC-A10 must be the first-stage module. Plug it into any socket J(X+9) and

plug the second-stage SCC into socket J(X+1), where Xis 0 to 7. Connect

the input-signal wires to the SCC-A10 as described in the SCC Quick Start

Guide. The SC-2345 connects the output signals of the SCC-A10 to the

SCC-A10 Voltage Attenuator Module User Guide 4 ni.com

inputs of the second-stage SCC. An example of dual-stage conditioning is

an SCC-A10 followed by a lowpass filter module (SCC-LPXX).

Sockets J9 to J16 of the SC-2345 are also available for digital input/output

(DIO) conditioning or control. Refer to the SC-2345/2350 User Manual for

more information about configuring, connecting, and installing SCC

modules.

Connecting the Input Signals

Note The signal names have changed. Refer to ni.com/info and enter rdtntg to

confirm the signal names.

Each screw terminal is labeled by pin number <1..4>. Pins 1 and 2 form

a differential channel routed to E/M Series DAQ device channel X+8, and

pins 3 and 4 form a second differential channel routed to E/M Series DAQ

device channel X. The value of Xis determined by the number of the

SC-2345/2350 socket where you plug in the module, J(X+1) or J(X+9) or the

slot number on the SCC-68.

The signal source can be floating or ground-referenced. Floating signal

sources do not require bias resistors to ground with the SCC-A10. Figure 1

shows the SCC-A10 signal connections.

Figure 1. SCC-A10 Signal Connections

Signal

Source

AI (X )

AI SENSE

AI (X+8)

SCC-A10 E/M Series DAQ Device

–

Overvoltage

Protection

–

Signal source may be floating or ground-referenced.

2AI GND

Overvoltage

Protection

Overvoltage

Protection

Overvoltage

Protection

–

©National Instruments Corporation 5 SCC-A10 Voltage Attenuator Module User Guide

For information about how to configure the SCC-A10 module using

NI-DAQmx, refer to the SCC Quick Start Guide.

Using the SCC-A10 when Scaling Voltage Measurements

If you configured the SCC-A10 using Measurement & Automation

Explorer (MAX) and you are using NI-DAQ, the voltage reading you get

from the E/M Series DAQ device accounts for the voltage scaling effect of

the SCC-A10. Otherwise, because the voltage measurement from the

E/M Series DAQ device is one-tenth of the voltage applied at the SCC-A10

input, you must multiply the voltage reading from the E/M Series DAQ

device by 10 to get the correct SCC-A10 input voltage.

Specifications

Note In order for the SCC-A10 to perform according to the specifications in this guide,

the ±15 V power supply you use must be accurate to within 5%.

These ratings are typical at 25 °C unless otherwise stated.

Analog Input

Number of input channels ...................... 2 DIFF

Input range......................................... ±60 VDC

Input impedance..................................... 1 MΩ(powered on or off)

Gain error .......................................... ±0.14% of reading max1

Gain-error temperature coefficient........ ±0.006% of reading/°C max

Offset error ........................................ ±6.5 mV max (referred to

input [RTI]2)

Offset-error temperature coefficient...... ±80 µV/°C max (RTI)

Nonlinearity ....................................... ±0.004% of full scale

Common-mode rejection ratio ............... 60 dB min (DC to 60 Hz)

1 Temperature range is 23 °C ±5 °C.

2 Calculated with respect to the input range

SCC-A10 Voltage Attenuator Module User Guide 6 ni.com

Dynamic Response

Bandwidth (–3 dB) .................................10 kHz

Output settling time to within

0.01% of nominal input voltage .............15 µs

Output slew rate......................................0.75 V/µs min

Power Requirement

Analog power .........................................100 mW max

+15 V ................................................3.2 mA max

–15 V ...............................................3.2 mA max

Digital power (+5 V)................................0.0 mA

Physical

Figure 2. SCC-A10 Dimensions

Weight ....................................................29 g (1.0 oz)

I/O connectors.........................................One 20-pin right-angle

male connector,

one 4-pin screw terminal

Wire gauge range....................................24 to 12 AWG

1.87 cm

(0.74 in.) 7.93 cm

(3.12 in.)

3.55 cm

(1.4 in.)

©National Instruments Corporation 7 SCC-A10 Voltage Attenuator Module User Guide

Maximum Working Voltage

(Signal + common-mode) each input should remain within 60 VDC of

ground.

Maximum working voltage refers to the signal voltage plus the CMV.

Channel-to-earth (inputs) ....................... 60 VDC,

Measurement Category I

Channel-to-channel (inputs)................... 60 VDC,

Measurement Category I

Caution This device is rated for Measurement Category I and is intended to carry signal

voltages no greater than 42.4 Vpeak or 60 VDC. Do not use this device for connection to

signals or for measurements within Categories II, III, or IV.

Environmental

Operating temperature............................ 0 to 50 °C

Storage temperature ............................... –20 to 70 °C

Humidity ................................................ 10 to 90% RH, noncondensing

Maximum altitude .................................. 2,000 m

Pollution Degree (indoor use only) ........ 2

Safety

The SCC-A10 is designed to meet the requirements of the following

standards of safety for electrical equipment for measurement, control,

and laboratory use:

• IEC 61010-1, EN 61010-1

• UL 61010-1

• CAN/CSA-C22.2 No. 61010-1

Note For UL and other safety certifications, refer to the product label, or visit

ni.com/certification, search by model number or product line, and click the

appropriate link in the Certification column.

SCC-A10 Voltage Attenuator Module User Guide 8 ni.com

Electromagnetic Compatibility

Emissions................................................EN 55011 Class A at 10 m

FCC Part 15A above 1 GHz

Immunity ................................................EN 61326:1997 + A2:2001,

Table 1

EMC/EMI ...............................................CE, C-Tick, and FCC Part 15

(Class A) Compliant

Note For EMC compliance, operate this device with shielded cabling.

CE Compliance

The SCC-A10 meets the essential requirements of applicable European

Directives, as amended for CE marking, as follows:

Low-Voltage Directive (safety)..............73/23/EEC

Electromagnetic Compatibility

Directive (EMC) .....................................89/336/EEC

Note Refer to the Declaration of Conformity (DoC) for this product for any additional

regulatory compliance information. To obtain the DoC for this product, visit

ni.com/certification, search by model number or product line, and click the

appropriate link in the Certification column.

©National Instruments Corporation 9 SCC-A10 Voltage Attenuator Module User Guide

SCC-A10 Module Pin Assignments

Figure 3 shows the I/O connector pins on the bottom of the module.

Figure 3. SCC Module Bottom View

Table 1 lists the signal corresponding to each pin. AI (X) and AI (X+8) are

the analog input signal channels of the E/M Series DAQ device. AI GND is

the analog input ground signal and is the reference for AI (X) and AI (X+8).

A GND is the reference for the ±15 V power supply. AI GND and A GND

connect to the SC-2345/2350 at the SCC-PWR connector.

1Pin1 2Pin2 3 Pin19 4Pin20

Table 1. SCC-A10 Module Pin Assignments

Pin Number Signal

1E/M Series AI (X)

2E/M Series AI GND [AI (X) REF]

3 —

4E/M Series AI (X+8)

5 —

6E/M Series AI GND

7 —

8E/M Series AI GND [AI (X+8) REF]

9 —

10 —

National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation.

Refer to the Terms of Use section on ni.com/legal for more information about National

Instruments trademarks. Other product and company names mentioned herein are trademarks or trade

names of their respective companies. For patents covering National Instruments products, refer to the

appropriate location: Help»Patents in your software, the patents.txt file on your CD, or

ni.com/patents.

11 A GND

12 —

13 +15 V

14 –15 V

15 —

16 —

17 —

18 —

19 —

20 —

Table 1. SCC-A10 Module Pin Assignments (Continued)

Pin Number Signal

Otros manuales para SCC-A10

Tabla de contenidos

Otros manuales de Unidad de control de National Instruments

National Instruments

National Instruments FIeldPoint FP-AO-200 Manual de usuario

National Instruments

National Instruments R Series Manual de usuario

National Instruments

National Instruments FieldPoint FP-1001 Manual de usuario

National Instruments

National Instruments 9235 Manual

National Instruments

National Instruments PXIe-4302 Manual de usuario

National Instruments

National Instruments 9477 Manual de usuario

National Instruments

National Instruments SLSC-12251 Manual de usuario

National Instruments

National Instruments FieldPoint FP-1001 Manual de usuario

National Instruments

National Instruments SCXI-1313 Manual de usuario

National Instruments

National Instruments NI 9234 Manual

National Instruments

National Instruments NI PXI/e-4000 Series Manual de usuario

National Instruments

National Instruments NI PXIe-4464 Manual de usuario

National Instruments

National Instruments SCXI-1521 Manual de usuario

National Instruments

National Instruments NI USB-9201 Manual de usuario

National Instruments

National Instruments NI 9881 Manual de usuario

National Instruments

National Instruments SCXI-1100 Manual de usuario

National Instruments

National Instruments Module SCXI-1503 Manual

National Instruments

National Instruments PXIe-6595 Manual de usuario

National Instruments

National Instruments PXIe-4310 Manual de usuario

National Instruments

National Instruments PXIe-4310 Manual

National Instruments

National Instruments FieldPoint cFP-DI-304 Manual de usuario

National Instruments

National Instruments NI 9425 Manual de usuario

National Instruments

National Instruments NI FlexRIO PXI-7951R Manual de usuario

National Instruments

National Instruments NI 9882 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
