National Instruments PXIe-6595 Manual de usuario

GETTING STARTED GUIDE

PXIe-6595

32 Gbps, 8-Channel PXI High-Speed Serial Instrument

Note Before you begin, install and configure your chassis and controller.

Note Adapter modules are not installable or interchangeable on the PXIe-6595.

Verifying the System Requirements

To use the PXIe-6595, your system must meet certain requirements. For more information

about minimum system requirements, recommended system, and supported application

development environments (ADEs), refer to the FlexRIO readme, which is available at ni.com/

manuals.

Unpacking the Kit

Notice To prevent electrostatic discharge (ESD) from damaging the module,

ground yourself using a grounding strap or by holding a grounded object, such as

your computer chassis.

1. Touch the antistatic package to a metal part of the computer chassis.

2. Remove the module from the package and inspect it for loose components or other signs

of damage.

Notice Never touch the exposed pins of connectors.

Note Do not install a module if it appears damaged in any way.

3. Unpack any other items and documentation from the kit.

Store the module in the antistatic package when the module is not in use.

PXIe-6595 Kit Contents

The following items are included in the device kit:

• PXIe-6595

•PXIe-6595 Safety, Environmental, and Regulatory Information document

Preparing the Environment

Ensure the environment in which you are using the PXIe-6595 meets the following

specifications.

Operating environment

Ambient temperature range 0 °C to 55 °C1

Relative humidity range 10% to 90%, noncondensing

Maximum altitude 2,000 m (800 mbar) (at 25 °C ambient

temperature)

Pollution Degree 2

Indoor use only.

Note For complete specifications, refer to the specifications document for your

device at ni.com/manuals.

Installing the PXIe-6595

Notice To prevent damage to the PXIe-6595 caused by ESD or contamination,

handle the module using the edges or the metal bracket.

1. Ensure the AC power source is connected to the chassis before installing the module.

The AC power cord grounds the chassis and protects it from electrical damage while you

install the module.

2. Power off the chassis.

3. Inspect the slot pins on the chassis backplane for any bends or damage prior to

installation. Do not install a module if the backplane is damaged.

4. Remove the black plastic covers from all the captive screws on the module front panel.

5. Identify a supported slot in the chassis. The following figure shows the symbols that

indicate the slot types.

1The PXIe-6595 requires a chassis with slot cooling capacity ≥58 W. Not all chassis with slot

cooling capacity ≥58 W can achieve this ambient temperature range. Refer to the PXI Chassis

Manual for specifications to determine the ambient temperature ranges your chassis can achieve.

2| ni.com | PXIe-6595 Getting Started Guide

Figure 1. Chassis Compatibility Symbols

NI PXIe-1062Q

12 3 45

1. PXI Express System Controller Slot

2. PXI Peripheral Slot

3. PXI Express Hybrid Peripheral Slot

4. PXI Express System Timing Slot

5. PXI Express Peripheral Slot

PXIe-6595 modules can be placed in PXI Express peripheral slots, PXI Express hybrid

peripheral slots, or PXI Express system timing slots.

6. Touch any metal part of the chassis to discharge static electricity.

7. Ensure that the ejector handle is in the downward (unlatched) position.

8. Place the module edges into the module guides at the top and bottom of the chassis. Slide

the module into the slot until it is fully inserted.

Figure 2. Module Installation

NI PXIe-1075

1. Chassis

2. Hardware Module

3. Ejector Handle in Downward (Unlatched) Position

9. Latch the module in place by pulling up on the ejector handle.

10. Secure the module front panel to the chassis using the front-panel mounting screws.

Note Tightening the top and bottom mounting screws increases mechanical

stability and also electrically connects the front panel to the chassis, which can

improve the signal quality and electromagnetic performance.

PXIe-6595 Getting Started Guide | © National Instruments Corporation | 3

11. Cover all empty slots using either filler panels (standard or EMC) or slot blockers with

filler panels, depending on your application.

Note For more information about installing slot blockers and filler panels, go

to ni.com/r/pxiblocker.

12. Power on the chassis.

Configuring the PXIe-6595 in MAX

Use Measurement & Automation Explorer (MAX) to configure your NI hardware. MAX

informs other programs about which NI hardware products are in the system and how they are

configured. MAX is automatically installed with FlexRIO.

1. Launch MAX.

2. In the configuration tree, expand Devices and Interfaces to see the list of installed NI

hardware.

Installed modules appear under the name of their associated chassis.

3. Expand your Chassis tree item.

MAX lists all modules installed in the chassis. Your default names may vary.

Note If you do not see your module listed, press <F5> to refresh the list of

installed modules. If the module is still not listed, power off the system, ensure

the module is correctly installed, and restart.

4. Record the identifier MAX assigns to the hardware. Use this identifier when

programming the PXIe-6595.

5. Self-test the hardware by selecting the item in the configuration tree and clicking Self-

Test in the MAX toolbar.

The MAX self-test performs a basic verification of hardware resources.

NI Services

Visit ni.com/support to find support resources including documentation, downloads, and

troubleshooting and application development self-help such as tutorials and examples.

Visit ni.com/services to learn about NI service offerings such as calibration options, repair, and

replacement.

Visit ni.com/register to register your NI product. Product registration facilitates technical

support and ensures that you receive important information updates from NI.

NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX, 78759-3504,

USA.

4| ni.com | PXIe-6595 Getting Started Guide

PXIe-6595 Getting Started Guide | © National Instruments Corporation | 5

Information is subject to change without notice. Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for

information on NI trademarks. Other product and company names mentioned herein are trademarks or trade names of their

respective companies. For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your

software, the patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find

information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer

to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade compliance policy and how

to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS

TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S.

Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable

limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.

378313A-01 September 29, 2020
