GETTING STARTED GUIDE

NI 6589

1 Gbps, 20 Channel, LVDS Digital I/O Adapter Module

Note Before you begin, complete the software and hardware installation

instructions in the getting started guide for your FlexRIO FPGA module or

Controller for FlexRIO.

The NI 6589 is a FlexRIO adapter module designed to work in conjunction with FlexRIO

FPGA modules and Controllers for FlexRIO.

The NI 6589 features 20 LVDS channels (16 data and 4 PFI), and sample rates up to 1 Gbit/s

on LVDS channels

This document explains how to install and configure the NI 6589.

Contents

Electromagnetic Compatibility Guidelines...............................................................................1

FlexRIO Documentation........................................................................................................... 2

Verifying the System Requirements..........................................................................................4

Unpacking................................................................................................................................. 4

Preparing the Environment....................................................................................................... 4

Installing the NI 6589............................................................................................................... 5

Confirming that Measurement & Automation Explorer (MAX) Recognizes the Device........ 5

Cables........................................................................................................................................5

Accessories........................................................................................................................6

Front Panel and Connector Pinouts...........................................................................................8

Block Diagrams.......................................................................................................................10

Component-Level Intellectual Property (CLIP)..................................................................... 12

NI 6589 CLIP..................................................................................................................13

Clocking.................................................................................................................................. 18

Where to Go Next................................................................................................................... 20

Worldwide Support and Services............................................................................................ 20

Electromagnetic Compatibility Guidelines

This product was tested and complies with the regulatory requirements and limits for

electromagnetic compatibility (EMC) stated in the product specifications. These requirements

and limits are designed to provide reasonable protection against harmful interference when the

product is operated in the intended operational electromagnetic environment.

This product is intended for use in industrial locations. However, harmful interference may

occur in some installations, when the product is connected to a peripheral device or test object,

or if the product is used in residential or commercial areas. To minimize interference with

radio and television reception and prevent unacceptable performance degradation, install and

use this product in strict accordance with the instructions in the product documentation.

Furthermore, any modifications to the product not expressly approved by National Instruments

could void your authority to operate it under your local regulatory rules.

Caution To ensure the specified EMC performance, operate this product only with

shielded cables and accessories.

Caution To ensure the specified EMC performance, you must attach EMI gaskets

(NI part number 746228-01) to both sides of your NI 6589 before using.

Caution To ensure the specified EMC performance, you must install PXI EMC

Filler Panels (NI part number 778700-01) in all open chassis slots.

FlexRIO Documentation

Table 1. FlexRIO Documentation Locations and Descriptions

Document Location Description

Getting started guide

for your FlexRIO

FPGA module or

Controller for

FlexRIO

Available from the Start menu

and at ni.com/manuals.

Contains installation instructions

for your FlexRIO system.

Specifications

document for your

FlexRIO FPGA

module or Controller

for FlexRIO

Available from the Start menu

and at ni.com/manuals.

Contains specifications for your

FlexRIO FPGA module or

Controller for FlexRIO.

Getting started guide

for your adapter

module

Available from the Start menu

and at ni.com/manuals.

Contains signal information,

examples, and CLIP details for

your adapter module.

Specifications

document for your

adapter module

Available from the Start menu

and at ni.com/manuals.

Contains specifications for your

adapter module.

LabVIEW FPGA

Module Help

Embedded in LabVIEW Help

and at ni.com/manuals.

Contains information about the

basic functionality of the

LabVIEW FPGA Module.

2| ni.com | NI 6589 Getting Started Guide

Table 1. FlexRIO Documentation Locations and Descriptions (Continued)

Document Location Description

Real-Time Module

Help

Embedded in LabVIEW Help

and at ni.com/manuals.

Contains information about real-

time programming concepts, step-

by-step instructions for using

LabVIEW with the Real-Time

Module, reference information

about Real-Time Module VIs and

functions, and information about

LabVIEW features on real-time

operating systems.

FlexRIO Help Available from the Start menu

and at ni.com/manuals.

Contains information about the

FPGA module front panel

connectors and I/O, controller for

FlexRIO front panel connectors

and I/O, programming

instructions, and adapter module

component-level IP (CLIP).

FlexRIO Adapter

Module Development

Kit User Manual

Available from the Start menu

at Start»All Programs»

National Instruments»NI

FlexRIO»NI FlexRIO

Adapter Module Development

Kit»Documentation.

Contains information about how

to create custom adapter modules

for use with FlexRIO FPGA

modules.

LabVIEW Examples Available in NI Example

Finder. In LabVIEW, click

Help»Find Examples»

Hardware Input and Output»

FlexRIO.

Contains examples of how to run

FPGA VIs and Host VIs on your

device.

IPNet Located at ni.com/ipnet. Contains LabVIEW FPGA

functions and intellectual property

to share.

FlexRIO product page Located at ni.com/flexrio. Contains product information and

data sheets for FlexRIO devices.

NI 6589 Getting Started Guide | © National Instruments | 3

Verifying the System Requirements

To use the FlexRIO Support instrument driver, your system must meet certain requirements.

For more information about minimum system requirements, recommended system, and

supported application development environments (ADEs), refer to the FlexRIO Support

Readme, which is available on the FlexRIO Support software DVD or online at ni.com/

updates.

Unpacking

Caution To prevent ESD from damaging the devices, ground yourself using a

grounding strap or by holding a grounded object, such as your computer chassis.

1. Touch the antistatic package to a metal part of the computer chassis.

2. Remove each module from the package and inspect it for loose components or any other

sign of damage.

Caution Never touch the exposed pins of connectors.

Note Do not install a device if it appears damaged in any way.

3. Unpack any other items and documentation from the kit.

Store the devices in the antistatic package when they are not in use.

Preparing the Environment

Ensure that the environment you are using the NI 6589 in meets the following specifications.

Operating temperature (IEC 60068-2-1,

IEC 60068-2-2)

0 °C to 55 °C

Operating humidity (IEC 60068-2-56) 10% to 90% RH, noncondensing

Pollution Degree 2

Maximum altitude 2,000 m at 25 °C ambient temperature

Indoor use only.

Note Refer to the NI 6589 Specifications at ni.com/manuals for complete

specifications.

Caution Clean the hardware with a soft, nonmetallic brush. Make sure that the

hardware is completely dry and free from contaminants before returning it to

service.

4| ni.com | NI 6589 Getting Started Guide

Installing the NI 6589

Refer to the getting started guide for your FlexRIO FPGA module or Controller for FlexRIO

for instructions about how to install your FlexRIO system, including the NI 6589.

Confirming that Measurement & Automation

Explorer (MAX) Recognizes the Device

Use Measurement & Automation Explorer (MAX) to configure your NI hardware. MAX

informs other programs about which devices reside in the system and how they are configured.

MAX is automatically installed with FlexRIO Support.

1. Launch MAX by navigating to Start»All Programs»National Instruments»NI MAX or

by clicking the NI MAX desktop icon.

2. In the Configuration pane, double-click Devices and Interfaces to see the list of installed

devices. Installed devices appear under the name of their associated chassis.

3. (PXI and PXI Express devices only) Expand your Chassis tree item. MAX lists all

devices installed in the chassis. Your default device names may vary.

Note If you do not see your hardware listed, press <F5> to refresh the list of

installed devices. If the device is still not listed, power off the system, ensure

the device is correctly installed, and restart.

4. (Controllers for FlexRIO only) Your device appears under the Remote Devices section.

Cables

Caution You must operate the NI 6589 with shielded cables and shielded

accessories to ensure compliance with the EMC requirements defined in the NI 6589

Specifications. Do not use unshielded cables or accessories unless they are installed

in a shielded enclosure with properly designed and shielded input/output ports and

are connected to the NI 6589 using a shielded cable. If unshielded cables or

accessories are not properly installed and shielded, the EMC specifications for the

NI 6589 are no longer guaranteed.

Use a shielded 50 Ω coaxial cable with an SMA plug end to connect to the PFI 0 and

CLOCK IN connectors on the NI 6589 front panel. Use the NI SHB12X-B12X shielded cable

(NI part number 192344-01) or the NI SHB12X-H3X24 differential flying-lead cable (NI part

number 196236-1R5) to connect to the DDC connector. You can also connect the

NI SMA-2164 accessory to the NI 6589 through the SHB12X-B12X shielded cable for testing

and debugging.

Note If you design a custom cabling solution with the DDC connector (779157-01)

and SHB12X-B12X shielded cable (192344-01), the NI 6589 pinout is reversed at

NI 6589 Getting Started Guide | © National Instruments | 5

the end connector. For example, the signal shown on pin 1 maps to pin 73 at the end

connector.

The following NI cables and accessories are not properly shielded for EMC-compliant use

with the NI 6589:

• NI SMA-2164 accessory

• NI SHB12X-H3X24 differential flying-lead cable

Note Whether you use NI cables and accessories or design your own, terminate

cables properly to avoid improper measurements caused by signal reflections,

overshoot, and undershoot.

Accessories

The NI SMA-2164 test fixture is a breakout box for differential signals. This fixture provides

an easy way to connect to other devices for testing and debugging.

The following figure shows how to connect the differential DDC connector to the

NI SMA-2164, using the NI SHB12X-B12X cable. For more information about using the

NI SMA-2164, refer to the NI SMA-2164/2165 Test Fixture User Guide.

Figure 1. Connecting the NI SMA-2164 Accessory

NI PXI-1042

STROBE

CLK_LVPECL

IO_3

–

IO_7

IO_10

IO_6

IO_11

IO_13

MADEIN U.S.A.

IO_15

ASSY192533 A- 01

–

I O_ 12

–

IO_4

IO_5

IO_8

IO_2

IO_9

–

IO_1

–

PFI_3

CLK_LVDS

PFI_2

–

PFI_1

VOS

IO_0

VOS

–

S/N

–

VOS

–

VOS

NI SMA-2164

DIFFERENTIAL

DIGITALI/O ACCESSORY

FOR PATENTS:NI.COM/PATENTS

NI 6587

PFI 0

CLOCKIN

1 Gbps

LVDS

1. PXI/PXIe Chassis with an NI 6589R

2. NI SHB12-B12X Cable

3. NI SMA-2164

A flying lead cable, the NI SHB12X-H3X24, is also available for differential signals. This

cable offers connectivity similar to that found on a typical logic analyzer, so you can use it in

logic analyzer-type applications. This cable is shown in the following figure.

6| ni.com | NI 6589 Getting Started Guide

Figure 2. NI SHB12X-H3X24 Flying Lead Cable

1. Leads (1 × 3 Header Receptacle)

2. DDC Connector

3. Removeable Sleeving

Custom Accessories

If you are creating a custom accessory to use with a DUT with a VHDCI DDC connector, you

can purchase the mating connector for the VHDCI cable from NI. For more information about

creating these custom accessories, refer to the Interfacing to the NI Digital Waveform

Generator/Analyzer using the VHDCI Connector application note.

Visit ni.com/info and enter the Info Code rdinwa to download this note.

If you are designing a custom accessory to use with a device that uses an InfiniBand

connector, you can also purchase this connector from NI.

Note If you design a custom cabling solution with the DDC connector (779157-01)

and SHB12X-B12X shielded cable (192344-01), the NI 6589 pinout is reversed at

the end connector. For example, the signal shown on pin 1 maps to pin 73 at the end

connector.

For more information about connecting I/O signals on your device, refer to the NI 6589

Specifications.

NI 6589 Getting Started Guide | © National Instruments | 7

Front Panel and Connector Pinouts

The NI 6589 provides one PFI signal and one clock signal through the two SMA connectors

on the device front panel. Additionally, the NI 6589 provides sixteen LVDS signals, four

LVDS PFI signals, three single-ended PFI signals, and an LVDS clock out signal on the

Digital Data & Control (DDC) connector. The following figure shows the front panel

connector and signal descriptions for the NI 6589.

Figure 3. NI 6589 Front Panel and Connector Pinout

NI 6589

PFI 0

CLOCK IN

1 Gbps

LVDS

PFI 1+

GND

PFI 2+

GND

PFI 3+

GND

DIO 0+

GND

DIO 1+

GND

DIO 2+

GND

DIO 3+

GND

DIO 4+

GND

DIO 5+

GND

DIO 6+

GND

DIO 7+

GND

DIO 8+

GND

DIO 9+

GND

DIO 10+

GND

DIO 11+

GND

DIO 12+

GND

DIO 13+

GND

DIO 14+

GND

DIO 15+

GND

PFI 1–

PFI 2–

PFI 3–

DIO 0–

DIO 1–

DIO 2–

DIO 3–

DIO 4–

DIO 5–

DIO 6–

DIO 7–

DIO 8–

DIO 9–

DIO 10–

DIO 11–

DIO 12–

DIO 13–

DIO 14–

DIO 15–

3332

4544

5756

6968

SE_PFI_3

SE_PFI_2

DDC CLK OUT–

DDC CLK OUT+

GND

SE_PFI_1

STROBE–

STROBE+

PFI 4 –

PFI 4+

DIGITAL DATA & CONTROL

Caution To avoid permanent damage to the NI 6589, disconnect all signals

connected to the NI 6589 before powering down the module, and connect signals

only after the adapter module has been powered on by the FlexRIO FPGA module or

Controller for FlexRIO.

8| ni.com | NI 6589 Getting Started Guide

Caution Connections that exceed any of the maximum ratings of any connector on

the NI 6589 can damage the device and the chassis. NI is not liable for any damage

resulting from such connections.

Note If you design a custom cabling solution with the Infiniband connector

(779157-01) and the SHB12X-B12X LVDS shielded cable (192344-01), the NI 6589

pinout is reversed at the end connector. For example, the signal shown on pin 1 maps

to pin 73 in the pinout at the end connector.

The following table contains SMA pin location information and signal information for the

NI 6589. The signal names listed in this table refer to the signals shown in the front panel

pinout.

Table 2. SMA Connector Names and Descriptions

Signal Name Connector Signal Type Signal Description

PFI 0 PFI 0 Control Bidirectional single-ended terminal for channel

PFI 0.

CLOCK IN CLOCK IN Clock External single-ended clock input terminal.

The following table contains DDC pin location information for the NI 6589. The signal names

listed in this table refer to the signals shown in the front panel pinout.

Table 3. NI 6589 DDC Connector Names and Descriptions

Signal Name Pin(s) Signal

Type

Signal Description

DDC CLK OUT+ 65 Control Positive terminal for the LVDS

exported Sample Clock.

DDC CLK OUT- 66 Control Negative terminal for the LVDS

exported Sample Clock.

STROBE+ 62 Control Positive differential terminal for the

external Sample Clock source that

can be used for synchronous

dynamic acquisition.

STROBE- 63 Control Negative differential terminal for

the external Sample Clock source

that can be used for synchronous

dynamic acquisition.

Table 3. NI 6589 DDC Connector Names and Descriptions (Continued)

Signal Name Pin(s) Signal

Type

Signal Description

DIO<0..15>+ 14, 17, 20, 23, 26,

29, 32, 35, 38, 41,

44, 47, 50, 53, 56, 59

Data Positive differential terminal for the

bidirectional digitial I/O data

channels 0 through 15.

DIO<0..15>- 15, 18, 21, 24, 27,

30, 33, 36, 39, 42,

45, 48, 51, 54, 57, 60

Data Negative differential terminal for

the bidirectional digitial I/O data

channels 0 through 15.

PFI <1..4>+ 2, 5, 8, 11 Control Positive differential terminals for

bidirectional PFI channels 1

through 4.

PFI <1..4>- 3, 6, 9, 12 Control Negative differential terminals for

bidirectional PFI channels 1

through 4.

SE_PFI<1..3> 68, 71, 72 Control Single-ended terminals for

bidirectional PFI channels 1

through 3.

GND 1, 4, 7, 10, 13, 16,

19, 22, 25, 28, 31,

34, 37, 40, 42, 46,

49, 52, 55, 58, 69

Ground Ground reference for signals.

For more detailed information about the NI 6589 front panel connectors, refer to the NI 6589

Specifications.

Block Diagrams

The following figures show the data flow through the NI 6589. Single-ended data lines use

standard clock levels to interpret data as either a binary zero or a one in high-speed digital data

transfers. Differential data lines provide a low-noise, low-power, low-amplitude differential

method for high-speed digital data transfer.

Figure 4. Clock Input Signal

CLOCK IN

Global Clock to

NI FlexRIO FPGA Module

(UserGclkLvttl)

10 | ni.com | NI 6589 Getting Started Guide

Tabla de contenidos

Otros manuales de Unidad de control de National Instruments

National Instruments

National Instruments NI 9214 Manual de usuario

National Instruments

National Instruments NI 9211 Manual de usuario

National Instruments

National Instruments SCXI-1181K Manual de usuario

National Instruments

National Instruments sbRIO-9651 Guía

National Instruments

National Instruments SCXI Series Manual de usuario

National Instruments

National Instruments FlexRIO PXIe-79 R Series Manual de usuario

National Instruments

National Instruments sbRIO-9609 Manual de usuario

National Instruments

National Instruments NI 9474 Manual de usuario

National Instruments

National Instruments FieldPoint FP-1000 Manual de usuario

National Instruments

National Instruments 9501 C Series Manual de usuario

National Instruments

National Instruments NI FlexRIO Manual de usuario

National Instruments

National Instruments NI 9770 Manual de usuario

National Instruments

National Instruments 9759 Manual de usuario

National Instruments

National Instruments PXIe-8245 Manual de usuario

National Instruments

National Instruments SCXI-1100 Manual de usuario

National Instruments

National Instruments NI 9882 Manual de usuario

National Instruments

National Instruments NI 9351 Manual de usuario

National Instruments

National Instruments PXI-6683 Series Manual de usuario

National Instruments

National Instruments PXI-8840 Quad-Core Manual de usuario

National Instruments

National Instruments NI 5772R Manual de usuario

National Instruments

National Instruments 9755 Manual de usuario

National Instruments

National Instruments FIeldPoint FP-AO-200 Manual de usuario

National Instruments

National Instruments SCXI-1104 Manual de usuario

National Instruments

National Instruments Relay Module SCC-RLY01 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
