Multitech MultiMobile MT56128ZLX-NT Manual de usuario

Owner’sManual

MultiMobileTM

Model#MT56128ZLX-NT&MT56128ZLX-ST

P/N82076503

This publication may not be reproduced, in whole or in part, without prior expressed

Multi-Tech Systems, Inc. makes no representations or warranties with respect to the

content hereof and specifically disclaims any implied warranties of merchantability or

fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves the

right to revise this publication and to make changes from time to time in the content

hereof without obligation of Multi-Tech Systems, Inc. to notify any person or

organization of such revisions or changes.

Record of Revisions

Revision Description

A Manual released at revision level A.

(2/5/98)

B  Dial-Up Networking v.1.2 product update added

(4/ 6/98)  ISDN CAPI 2.0 product update added

 Manual format size changed

 Minor editorial, technical, and format changes

C V.90 support, S-Registers and Result Codes added; minor

(7/17/98) editorial and format changes

D Manual revised and reorganized to reflect software/driver changes.

(1/15/99)

TRADEMARKS

Trademarks of Multi-Tech Systems, Inc. are as follows: MultiMobile, Multi-Tech, and

the Multi-Tech logo. All other trademarks are owned by their respective companies.

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112 U.S.A.

(612) 785-3500 or (800) 328-9717

U. S. FAX 612-785-9874

Fax-Back Service 612-717-5888

Technical Support (800) 972-2439

BBS (612) 785-3702 or (800) 392-2432

Internet Address: http://www.multitech.com

Contents

Chapter1—Introduction/Description

Features ..................................................................................................... 6

Technical Specifications ............................................................................ 7

Shipping Kit Contents ............................................................................... 9

About This Manual ................................................................................... 9

Chapter2—Hardware/DriverInstallation

Installing PC Card and Drivers/Software ..................................................12

Safety Warnings .......................................................................................12

Windows 95/98 InstallationVCOMM & CAPI ......................................13

Windows 95/98 InstallationNDIS ..........................................................15

Windows NT Installation ..........................................................................16

Customizing the TerminalAdapter (Optional) ...........................................18

Chapter 3—Application Program Interfaces (APIs)

Introduction ..............................................................................................20

VCOMM (Virtual Communications Port) ...................................................21

NDIS (Network Driver Interface Specification) .........................................31

CAPI (Common ISDNApplication Programming Interface) ......................36

Chapter4—Troubleshooting

How can I make sure MultiMobile hardware functions properly? ............54

COM Port and IRQ Conflicts ....................................................................55

Windows 95 COM Port and IRQ Conflicts................................................56

Chapter5—Service,Warranty,Technical Support

Introduction ..............................................................................................58

Limited Warranty ......................................................................................58

On-line Warranty Registration ..................................................................58

Software User LicenseAgreement ............................................................59

Tech Support ............................................................................................60

Service ......................................................................................................61

About the Multi-Tech BBS .......................................................................62

About CompuServe ..................................................................................64

About the Internet ....................................................................................64

About the Multi-Tech Fax-Back System ...................................................64

Appendix

Appendix A: Pin Assignments ..................................................................66

Appendix B: AT Command Summary, S-Register Summary, and Result

Codes Summary ........................................................................................67

Appendix C: Upgrade Procedures ............................................................79

Appendix D: RegulatoryAgency Information ..........................................85

Index

..................................................................................................................94

Chapter 1—Introduction/Description

6 MultiMobile

Chapter 1—Introduction/Description

ongratulations

on your purchase of the MultiMobile ISDN/Modem

PC Card. The MultiMobile (models MT56128ZLX-NT and

MT56128ZLX-ST) is the only multifunction PC Card in the world that

offers seamless connection between digital ISDN lines and analog

telephone lines (PSTN) within one single PC Card.

Its peerless switchable technology integrates both ISDN terminal adapter

(TA) and todays fastest 56K fax/modem technologies. Users can switch

between digital ISDN or analog PSTN connections simply by plugging in

bundled network connection cables. In addition to its unique switchable

ability, the MultiMobile features an ISDN Phone voice capability.

Features

 Switchable ISDN line or analog telephone line (PSTN) connection

 56K modem or G3 fax connections over both analog telephone and

ISDN lines

 Built-in microphone/speakerphone interface for ISDN Phone voice

applications

 Options for ISDN S/T-interface or U-interface

 Complies with prevalent ISDN software standards such as ISDN AT

commands, NDIS WAN, and CAPI 2.0

 Microsoft Plug-and-Play compatible

 Menu-driven configuration utility included

MultiMobile 7

Chapter 1—Introduction/Description

Technical Specifications

TradeName

 MultiMobileTM

Model Numbers:

 MT56128ZLX-NT (U-interface)

 MT56128ZLX-ST(S/T-interface)

SystemRequirements

 Intel 486, Pentium, or above (Pentium strongly recommended)

 30 MB free space

 One Type II or Type III PCMCIA slot

 Windows 95, OSR2, 98 or Windows NT installed

Fax

 G3, send and receive

 EIA Class 1/Class 2 Fax command set

Modem

 V.90, K56flex, V.34+ (33.6 Kbps), V.34 (28.8 Kbps), V.32bis

(14.4 Kbps)

Note: Though this terminal adapter is capable of 56 Kbps download

performance, line impairments, public telephone infrastructure, and

other external technological factors currently prevent maximum 56 Kbps

connections.

 V.42/V.42bis, MNPClass 2 to 5 error correction and data compression

ISDNStandards

 Basic RateAccess (2B+D)

 U-interface: complies with ANSI T1.601

 S/T-interface: complies with ITU-T I.430

 Protocol: ITU-T Q.921, Q.931, and ETSI NET3

8 MultiMobile

Chapter 1—Introduction/Description

LineRate

 64/56 Kbps on 1 B-channel (ISDN data mode)

 128/112 Kbps on 2 B-channel (PPP/MP)

 56 Kbps on 1 B-channel (modem mode)

 16 Kbps on D-channel for signaling

DTERate

 Asynchronous, up to 460.8 Kbps (COM port emulation mode)

ISDN Network & Switch Compatibility

 National ISDN-1 (NI-1)

 AT&T 5ESS Custom

 Northern Telecom DMS-100 Custom

 DSS1 (Euro-ISDN)

 INS-Net 64

B-ChannelProtocols

 X.75

 V.120

V.110

 PPP and Multi-Link Protocol

 Async-to-Sync PPP Conversion

 56K modem over B-channel

 G3 fax over B-channel

 Voice over B-channel

Application Program Interfaces

 ISDN AT Command Set

 CAPI 2.0

 NDIS WAN

Operating System Support

 Windows 95, OSR2, and 98

 Windows NT 4.0

MultiMobile 9

Chapter 1—Introduction/Description

Shipping Kit Contents

 One MultiMobile ISDN + Voice Modem 56K

 One ISDN U-interface, or S/T-interface, ISDN network connection

cable

 One analog fax/modem DAA connection cable

 One ISDN phone kit

 One ISDN phone cord with RJ-45 plugs

 One analog telephone cord with RJ-11 plugs

 One Owners Manual

 Four 3.5" software/driver program diskettes

(Note: This manual supports 4.0, or later, drivers only.)

 RVS-COM Lite

 MultiMobile Global Wizard

About This Manual

This manual explains how to install, configure, and use your

MultiMobileTM Multifunction PC card. Manual chapters and appendixes

are as follows:

Chapter1—Introduction/Description

Chapter2—Hardware/DriverInstallation

Chapter 3—Application Program Interfaces (APIs)

Chapter4—Service,Warranty,Technical Support

Appendix A—Pin Assignments

Appendix B—AT Commands, S-Registers, and Result Codes

AppendixC—UpgradeProcedures

AppendixD—Regulatory Information

Index

10 MultiMobile

Chapter 1—Introduction/Description
