Monoprice 38295 Manual de usuario
2-Port USB and HDMI® KVM Switch
P/N 38295
User's Manual
2
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra
attention to these safety warnings and guidelines. Please keep this
manual in a safe place for future reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. Do not
place drinks or other containers with moisture on or near the device.
If moisture does get in or on the device, immediately unplug it from
the power outlet and allow it to fully dry before reapplying power.
Do not touch the device, the power cord, or any other connected
cables with wet hands.
Do not expose this device to excessive vibration.
Do not subject the product to extreme force, shock, or fluctuations
in temperature or humidity.
Do not expose this device to excessively high temperatures. Do not
place it in, on, or near a heat source, such as a fireplace, stove,
radiator, etc. Do not leave it in direct sunlight.
Ensure that power is turned off and disconnected before making
any electrical connections.
Clean using a soft, dry cloth only. Do not use chemical cleaners,
solvents, or detergents. For stubborn deposits, moisten the cloth
with warm water.
This device has no user serviceable parts. Do not attempt to open,
service, or modify this device.
3
INTRODUCTION
This 2-Port USB and HDMI® KVM Switch allows you to use a single HDMI
monitor, USB keyboard, USB mouse, microphone, and headset/speakers
with two desktop or laptop computers. You can easily switch computers
using the built-in Port Selector, keyboard hotkeys, or with a simple
double-click of the mouse wheel. It supports HDMI video resolutions up
to 1900x1200 and is compatible with Windows®, Mac®, Linux®, UNIX®,
Novell® NetWare®, and DOS PCs. It features Video DynaSync™
technology, which eliminates boot-up display problems and optimizes
the video resolution when switching ports. The KVM and audio focus can
be separated, so one computer can have the KVM focus and the other
the audio focus. If one of the connected computers is powered off, the
switch will automatically select the other computer.
4
FEATURES
Includes two sets of 3.9-foot USB, HDMI®, and audio cables built-in
for connecting the two computers
Allows computer selection using the dedicated Remote Port
Selector button, keyboard hotkey, or with the simple double-click
of the mouse wheel
Supports independent KVM and audio selection, one computer can
have the KVM focus, while the other has the audio focus
Supports HDMI resolutions up to 1900x1200
Features Video DynaSync™ technology, which eliminates boot-up
display problems and optimizes the video resolution when
switching ports
Compatible with Windows®, Mac®, Linux®, UNIX®, Novell®
NetWare®, and DOS PCs
Features independent KVM and audio computer selection
Supports gaming and multimedia keyboards
Supports multifunction and wireless keyboards and mice
The console mouse port emulation/bypass feature supports most
mouse drivers
Features Mac keyboard support and emulation
Supports US English, French, and Japanese keyboard layouts
Supports firmware upgrading
Requires no external power connection
5
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring
that your ordering, purchasing, and delivery experience is second to
none. If you have any problem with your order, please give us an
opportunity to make it right. You can contact a Monoprice Customer
Service representative through the Live Chat link on our website
website for support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all
the items listed below. If anything is missing or damaged, please contact
Monoprice Customer Service for a replacement.
1x 2-Port KVM Switch
2x Hotkey Stickers
1x User's Manual
1x Quick Start Guide
6
PRODUCT OVERVIEW
1. Port LEDs: Two LEDs to indicate the selected computer and its
status. The LED illuminates solid when the corresponding computer
is selected. The LED flashes when the corresponding computer is
being scanned by the Auto Scan function. The LED is off when the
corresponding computer is not selected.
2. Console Keyboard Port: Plug your USB keyboard into this port.
3. Console Monitor Port: Plug your HDMI® display into this port.
4. Console Mouse Port: Plug your USB mouse into this port.
5. KVM Cables: Two sets of USB, HDMI, and audio cables for
connecting the two computers.
7
6. Console Audio Ports: 3.5mm jacks for connecting a microphone and
headphones/speakers. Note that if your HDMI display has speakers,
you do not need to connect headphones/speakers, unless you want
to use separate the KVM and audio focus feature.
7. Remote Port Selector: Momentarily press the button to switch
computer selection. Press and hold the button for 3 seconds to
swap the default Hotkey Prefix between Scroll Lock and Ctrl.
OPERATING SYSTEM COMPATIBILITY
The following table details the specific operating system versions
supported by the KVM.
OS
Version
Windows®
2000 / XP / 2003 / 2008 / Vista® / 7
Linux®
RedHat
9.0 / Fedora and higher
SuSE
10 / 11.1 and higher
Ubuntu
7.04 / 7.10
UNIX®
FreeBSD
5.5 / 6.1 / 6.2
Novell®
NetWare®
6.0 / 6.5
Mac®
OS 9 and higher
DOS
6.2 and higher
8
INSTALLATION
Perform the following steps to install this KVM switch.
1. Ensure that all equipment to be connected is powered off and
unplugged from its power source. This is especially true for
computers that have the Keyboard Power On feature.
2. Plug your USB keyboard into the Console Keyboard Port on the
switch.
3. Plug your HDMI® display into the Console Monitor Port on the
switch.
4. Plug your USB mouse or graphics tablet into the Console Mouse
Port on the switch.
5. (Optional) Plug a microphone into the 3.5mm Console Audio Port
with the pink plastic ring.
6. (Optional) Plug a pair of headphones or powered speakers into the
3.5mm Console Audio Port with the green plastic ring. Note that if
your HDMI display has speakers, you do not need to use external
headphones/speakers, unless you want to use the separate KVM
and audio focus feature.
9
7. Plug the two USB, one HDMI®, and two audio cables on one of the
KVM Cables into the appropriate ports on the first computer.
8. Repeat step 7 for the second KVM Cable and second computer.
9. Plug in and power on both computers. By default, the switch will
select the first computer that is powered on.
Note: The USB ports are standard USB 2.0 ports and can accept any USB
peripheral. If you want to use additional peripherals, plug a USB hub into
one of the two USB ports, then plug the keyboard, mouse, and additional
peripheral(s) into the hub.
10
OPERATION
This KVM switch supports three different methods of switching the
selected computer, which are detailed in the following sections.
Important Note: Do not switch focus when a USB peripheral, other than
the keyboard and mouse, is in active operation. Doing so could result in
data loss and/or file corruption.
Manual Switching
Momentarily press the button on the Remote Port Selector to manually
switch the KVM and audio focus from one computer to the other.
Mouse Switching
Double-click the mouse wheel button to swap the KVM and audio focus
from one computer to the other.
Notes:
1. This method is only supported by USB 3-button mice with a scroll
wheel.
2. The function is not available by default. It must be enabled by first
enabling Mouse Emulation with the hotkey command ([m] [Enter]),
then turning on the Scroll Wheel Switching function ([w] [Enter]).
Hotkey Switching
The hotkey method of switching offers the most flexibility in that you can
independently switch the KVM and audio focus. All hotkey commands
are prefaced with the Hotkey Prefix, which by default is two presses of
the [Scroll Lock] key. To swap the KVM and audio focus from one
computer to the other, type:
[Scroll Lock] [Scroll Lock] [Enter]
