Monoprice 38296 Manual de usuario

2x4/4x4 USB 2.0 Peripheral Sharing Switch

P/N 38296, 38297

Quick Start Guide

ONLINE SUPPORT

Monoprice is pleased to provide free online support. For order related

issues, contact the Customer Service department through the Live Chat

link on our website www.monoprice.com during normal business hours

(Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-6pm PT) or via email at

support@monoprice.com

For technical issues, contact the Technical Support department through

the online chat button on our website www.monoprice.com during

regular business hours, 7 days a week. You can also get assistance

through email by sending a message to tech@monoprice.com

PACKAGE CONTENTS

Please take an inventory of the package contents to ensure you have all

the items listed below. If anything is missing or damaged, please contact

Monoprice Customer Service for a replacement.

1x 2x4 or 4x4 USB Peripheral Sharing Switch

1x Quick Start Guide

2

PRODUCT OVERVIEW

1. Port LEDs: Two LEDs to indicate which computer is selected. For

both models, the LEDs illuminate green to indicate that PC1 or PC2 is

selected. For 38297, the LEDs illuminate red to indicate that PC3 or

PC4 is selected.

2. Micro USB Power Port: A micro USB port for optionally connecting a

USB power source.

3. USB Ports: Four USB ports for connecting USB peripherals.

4. Remote Port Selector: Press the button to cycle through the

connected PCs.

3

INSTALLATION

Perform the following steps to install this switch.

Note that the image above shows connections for model 38297. Model

38296 can connect to only two PCs, not four.

1. Ensure that all equipment to be connected is powered off and

unplugged from its power source.

2. Plug the USB cables on the switch into a USB port only up to two or

four computers.

3. Plug up to four USB peripherals into the switch's USB ports.

4. (Optional) Using a Micro USB cable (not included), plug one end into

the Micro USB Power Port, then plug the other end into a USB

power source.
