Monoprice 10319 Manual de usuario

3G SDI 2x1 Switch

P/N 10319

User's Manual

SAFETY WARNINGS AND GUIDELINES

Please read this entire manual before using this device, paying extra attention to these

safety warnings and guidelines. Please keep this manual in a safe place for future reference.

•This device is intended for indoor use only.

•Do not expose this device to water or moisture of any kind. Do not place drinks or

other containers with moisture on or near the device. If moisture does get in or on

the device, immediately remove it from its power source and allow it to fully dry

before reapplying power.

•Do not touch the device, the power cord, or any other connected cables with wet

hands.

•Do not expose this device to excessive vibration or extreme force, shock, or

fluctuations in temperature or humidity.

•Do not expose this device to excessively high temperatures. Do not place it in, on,

or near a heat source, such as a fireplace, stove, radiator, etc. Do not leave it in

direct sunlight.

•Do not place or install this device in an area where it can be exposed to excessive

amounts of dust, humidity, oil, smoke, or combustible vapors.

•Prior to operation, check the unit and power cord for physical damage. Do not use if

physical damage has occurred.

•Unplug this device from the power source when not in use.

•Take care to prevent damage to the power cord. Do not allow it to become

crimped, pinched, walked on, or become tangled with other cords. Ensure that the

power cord does not present a tripping hazard.

•Never unplug the unit by pulling on the power cord. Always grasp the connector

head or adapter body.

•Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or

detergents. For stubborn deposits, moisten the cloth with warm water.

•This device has no user serviceable parts. Do not attempt to open, service, or

modify this device.

INTRODUCTION

Designed for professional SMPTE video applications, this 3G SDI 2x1 Switch allows you to

determine which of two connected SDI video sources will be displayed on an SDI monitor.

It supports bit rates up to 2.97 Gbps and supports SD-SDI, HD-SDI, and 3G-SDI video signals.

FEATURES

•Distributes one of two connected SDI sources to a single SDI display

•Compatible with the HDcctv 1.0, HD-SDI (ST 292), 3G-SDI (ST 424), and SD-SDI (ST

259) standards

•Supports video resolutions up to 1080p@60Hz

•Supports data raters from 270MHz ~ 2.97Gbps

•Supports 8-bit, 10-bit, and 12-bit Deep Color

•Inputs and outputs are equalized, allowing for longer than normal cable runs

•Supports the RGB, YCbCr 4:4:4, and YCbCr 4:2:2 color spaces

CUSTOMER SERVICE

The Monoprice™ Customer Service department is dedicated to ensuring that your ordering,

purchasing, and delivery experience is second to none. If you have any problem with your

order, please give us an opportunity to make it right. You can contact a Monoprice

Customer Service representative through the Live Chat link on our website

www.monoprice.com or via email at sup[email protected]. Check the website for

support times and links.

PACKAGE CONTENTS

Please take an inventory of the package contents to ensure you have all the items listed

below. If anything is missing or damaged, please contact Monoprice™ Customer Service for

a replacement.

1x 3G SDI 2x1 Switch

1x AC Power Adapter

1x User's Manual

PRODUCT OVERVIEW

Front Panel

1. Select: Press the button to switch between the two inputs.

2. 1/2: One of the two LEDs illuminates to indicate the selected input.

3. Power: The LED illuminates when power is applied.

4. ON/OFF: Use the switch to turn the device on or off.

Rear Panel

5. DC/5V: DC barrel connector for connecting the included AC power adapter.

6. IN2: BNC connector for connecting an SDI video source device.

7. IN1: BNC connector for connecting an SDI video source device.

8. OUT: BNC connector for connecting an SDI display.

SAMPLE CONNECTION DIAGRAM

INSTALLATION

Perform the following steps to install this switch into your SDI video system.

1. Ensure that all equipment to be connected is powered off and unplugged from its

power source.

2. Place the Switch in its desired location.

3. Ensure that the ON/OFF switch is in the OFF (O) position.'

4. Plug one end of a 75-ohm RG-59 cable (available separately) into the video input of

an SDI display, then plug the other end into the OUT connector on the Switch.

5. Plug one end of a 75-ohm RG-59 cable (available separately) into the IN1 connector

on the Switch, then plug the other end into the video output of an SDI video source

device.

6. Plug one end of a 75-ohm RG-59 cable (available separately) into the IN2 connector

on the Switch, then plug the other end into the video output of an SDI video source

device.

7. Plug the included AC Power Adapter into the DC/5V connector on the Switch, then

plug the adapter into a nearby AC power outlet.

8. Plug in and power on all connected devices. If necessary, start video playback on

each source device.

9. Flip the ON/OFF switch to the ON (I) position. The Power LED will illuminate.

10. By default, the 1 LED will illuminate, indicating that input 1 is selected. Verify that

you can see video from the input 1 device on the connected display.

11. Momentarily press the Select button. The 2 LED will illuminate to indicate that input

2 is selected. Verify that you can see video from the input 2 device on the

connected display.

Congratulations, the Switch has been successfully installed into your system.

SPECIFICATIONS

P/N

10319

Inputs

2x SDI BNC

Output

1x SDI BNC

Supported Standards

HDcctv 1.0, HD-SDI (ST 292),

3G-SDI (ST 424), SD-SDI (ST 259)

Supported Cable Lengths

3G (1080p@60Hz): up to 262 ft. (80m)

HD (720p@60Hz): up to 393 ft. (120m)

SD (480i): up to 656 ft. (200m)

Input Power

5 VDC, 2A

AC Adapter Input Power

100 ~ 240 VAC, 50/60 Hz

Maximum Power Consumption

1.5 watts

Operating Temperature

+32 ~ +158°F (0 ~ +70°C)

Storage Temperature

+14 ~ +176°F (-10 ~ +80°C)

Operating Humidity

10 ~ 85% RH, noncondensing

Storage Humidity

5 ~ 90% RH, noncondensing

Dimensions (LxWxH)

3.5" x 3.3" x 1.0" (90 x 85 x 25 mm)

Weight

7.1 oz (200g)

TECHNICAL SUPPORT

Monoprice™ is pleased to provide free, live, online technical support to assist you with any

questions you may have about installation, setup, troubleshooting, or product

recommendations. If you ever need assistance with your new product, please come online

to talk to one of our friendly and knowledgeable Tech Support Associates. Technical

support is available through the online chat button on our website www.monoprice.com

or through email by sending a message to [email protected]. Check the website for

support times and links.

To download the latest drivers, firmware, manuals, etc., go to www.monoprice.com and

type the P/N into the search bar. If available, support files are linked at the bottom of the

product page.

REGULATORY COMPLIANCE

Notice for FCC

This device complies with Part 15 of the FCC rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired

operation.

Modifying the equipment without Monoprice's authorization may result in the equipment

no longer complying with FCC requirements for Class B digital devices. In that event, your

right to use the equipment may be limited by FCC regulations, and you may be required to

correct any interference to radio or television communications at your own expense.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Monoprice™ and all Monoprice logos are trademarks of Monoprice Inc.
