RHT-64001-3800 Hand Crimp Tool
Doc No. 64001-3800 Release Date: 10-24-03 UNCONTROLLED COPY Pa e 1 of 5
Revision: A Revision Date: 10-24-03
Hand Crimp Tool
Operating Instruction and Specifications S eet
Order No. 64001-3800
FEATURES
A full cycle ratchetin hand tool ensures complete crimps
An economical tool for portable crimpin and field repair
3-nested tool eliminates the need for additional tools
SCOPE
Perma-Seal
Step Down Butt Slices for 14-16 to 18-22 AWG and 10-12 to 14-16 AWG. FIQD Couplers
Male and Female for 14-22 AWG.
Testing
Mec anical
The tensile test, or pull test, is a means of evaluatin the mechanical properties of the crimped connections. The
followin charts show the UL specifications for various wire sizes. The tensile stren th is shown in pounds and
indicates the minimum acceptable force to break or separate the terminal from the conductor.
UL – 486 A* UL – 486 C** UL*310***
Wire Size (AWG) Minimum Pull
22 8 8 8
20 13 10 13
18 20 10 20
16 30 15 30
14 50 25 50
12 70 35 70
10 80 40 80
*UL - 486 A - Terminals (copper conductors only).
**UL - 486 C - Butt Splices
***UL – 310 - Couplers
Caution:This Tool is not UL approved. If UL approval is required, contact your Molex sales en ineer or
authorized distributor for the UL approved tool.
The followin is a partial list of the product part numbers and their specifications that this tool is desi ned to run.
We will be addin to this list and an up to date copy is available on www.molex.com.
Wire Size: 18–22 AWG 0.80–0.35mm²
Wire Strip Lengt
Insulation Diameter Maximum
Terminal No.
Terminal Eng No.
(REF) In. mm In. mm
19164-0015 SAA-9260 .313 7.94 .145 3.68
19164-0017 SAA-9261 .313 7.94 .165 4.19
RHT-64001-3800 Hand Crimp Tool
Doc No. 64001-3800 Release Date: 10-24-03 UNCONTROLLED COPY Pa e 2 of 5
Revision: A Revision Date: 10-24-03
Wire Size: 14–16 AWG 2.00–1.30mm²
Wire Strip Lengt
Insulation Diameter Maximum.
Terminal No.
Terminal Eng No.
(REF) In. mm In. mm
19164-0048 SBB-9262 .313 7.94 .170 4.32
19164-0050 SBB-9263 .313 7.94 .170 4.32
STEP DOWN BUTT SPLICE
Wire Size: 14–16 AWG 2.00–1.30mm² to 18-22 AWG .080-0.35mm²
Wire Strip Lengt
Insulation Diameter Maximum
Terminal No. Terminal Eng No.
(REF) In. mm In. mm
19164-0043 SBA-631 .281 7.14 .230 5.84
STEP DOWN BUTT SPLICE
Wire Size: 10–12 AWG 5.00–3.30mm² to 14-16 AWG 2.00-1.30mm²
Wire Strip Lengt
Insulation Diameter Maximum
Terminal No. Terminal Eng No.
(REF) In. mm In. mm
19164-0077 SCA-646 .281 7.14 .300 7.62
OPERATION
Crimping Terminals
Open the tool by first closin the jaws sufficiently for the ratchet mechanism to
release.
1. Place the terminal centerin the barrel in the lower jaw as shown in
Fi ure 1.
2. Partially close the hand tool jaws until the connector is held snu in place.
See Fi ure 2.
3. Insert the properly stripped wire into the terminal barrel.
See Fi ure 2 and 3.
4. Complete the crimp by closin the hand tool handles until they release.
Note: The tamper proof ratchet action will not release the tool until it has been fully closed.
5. Remove the crimp and inspect for proper crimp. Molex offers a Crimp
Inspection Handbook for closed barrel industrial product. See our
website or contact your sales en ineer.
Crimping Butt Splices
1. Position the splice into the proper color-coded nest.
2. Partially close the tool to hold the splice in place.
3. Insert the properly stripped wire into the splice. The wires end should
butt a ainst the tab in the terminal (See Fi ure 4). Cycle the tool.
4. Remove the crimped splice. Inspect for proper crimp location.
5. Rotate the butt splice terminal 180°, so that the opposite end of splice is
in the nest.
6. Repeat steps 2 thru 4.
Note: Make sure the seam of the terminal is oriented up or down in the tool if usin unbrazed product, as
this will provide hi her pull force values.
TERMINAL
JAWS
OPEN
Figure 1
JAWS
SLIGHTLY
CLOSED
Figure 2
WIRE
TERMINAL
RHT-64001-3800 Hand Crimp Tool
Doc No: ATS-640013800 Release Date: 10-24-03 UNCONTROLLED COPY Pa e 3 of 5
Revision: B Revision Date: 07-28-09
TERMINAL
WIRE
CONDUCTOR
PUNCH
CO
NDUCTOR
ANVIL
Figure 3
WIRE
Figure 4
CONDUCTOR
ANVIL
CONDUCTOR
PUNCH
TAB OF
TERMINAL
STEP DOWN BUTT
SPLICE TERMINAL
Maintenance
It is recommended that each operator of the tool be made aware of, and responsible for, the followin maintenance
steps:
1. Remove dust, moisture and other contaminants with a clean
brush, or soft, lint-free cloth.
2. Do not use any abrasive materials that could dama e the tool.
3. Make certain all pins; pivot points and bearin surfaces are
protected with a thin coat of hi h quality machine oil. Do not
oil excessively. The 64001-3800 was en ineered for
durability, but like any fine piece of equipment, it needs
cleanin and lubrication for a maximum service life of trouble-
free crimpin . A li ht oil, such as 30 wei ht automotive oil
used at the oil points shown in Fi ure 5, every 5,000 crimps or
3 months will si nificantly enhance the tool life and ensure a
stable calibration.
4. When tool is not in use, keep the handles closed to prevent
objects from becomin lod ed in the crimpin dies, and store the tool in a clean, dry area.
Miscrimps or Jams
Should this tool ever become stuck or jammed in a partially closed
position, Do Not force the handles open or closed. The tool will
open easily by pressin the ratchet release lever. See Fi ure 6.
How to Adjust Crimp Force
(See Figure 7)
Over the life of the tool, it may be necessary to adjust tool handle
preload force. Listed below are the steps required to adjust the
crimpin force of the hand tool to obtain proper crimp conditions:
LUB
RICATION POINTS
(BOTH SIDES) LIGHT OIL
(EVERY 3 MONTHS OR
5,000 CRIMPS)
Figure 5
Figure 6
RACHET RELEASE
LEVER
RHT-64001-3800 Hand Crimp Tool
Doc No: ATS-640013800 Release Date: 10-24-03 UNCONTROLLED COPY Pa e 4 of 5
Revision: B Revision Date: 07-28-09
This tool is factory preloaded at 48-65 LBS.
1. Loosen the stud nut on the front of the handle with
a screwdriver.
2. Insert a screwdriver in the slot of the stud (on the
back of the tool) and adjust the force. Clockwise
(CW) will increase the force, counter clockwise
(CCW) will decrease the handle force. See Fi ure
7.
3. Reti hten the nut while holdin the stud on the
front of the tool.
4. Check the crimp specifications after tool force is adjusted.
Quality Assurance Test
To check the quality of this tool, pin au e measurements should be taken
in each conductor nest and compared to this chart. The tool should be
lubricated before the quality assurance test to ensure consistent
measurements. Handle preload is factory set to 48-65 LBS See How to
Adjust Crimp Force. See Fi ure 7. If the tool does not meet the
specifications below, durin the quality assurance test, then the tool should
be disqualified and a new tool purchased.
Wire Range “X” Dimension Conductor Crimp
Nest Color Code AWG mm² Mean Go No Go Crimp Inspection Marking
Red 18 - 22 0.35 - 0.80 .094 .090 .098 ---
Blue 14 - 16 1.30 - 2.00 .115 .110 .119 ---
Yellow 10 - 12 3.30 - 5.00 .161 .156 .167 ---
Hand held crimpin tools are intended for low volume, prototypin , or repair requirements only.
Caution: Repetitive use of this tool should be avoided.
Cautions
1. Termination quality is dependent on proper profile choice. Molex customers should independently verify that
the termination they intend to use, meets their quality and performance needs because this tool does not have
a terminal locator. Not all terminal, wire, and profile combinations will achieve minimum pull force
requirements, or provide an acceptable crimp form if the terminal is not positioned as described in these
operation instructions. As such, Molex makes no warranties, express or implied, as to the performance or
reliability of the crimp, or the appropriateness of the customer’s application.
2. Manually powered hand tools are intended for low volume or field repair. This tool is NOT intended for
production use. Repetitive use of this tool should be avoided.
3. Insulated rubber handles are not protection a ainst electrical shock.
4. Wear eye protection at all times.
PIN GAUGE IN
CONDUCTOR CRIMP
“Confining ” Crimp
X
Figure 7
STUD NUT
STUD
BACK
FRONT
RHT-64001-3800 Hand Crimp Tool
Doc No: ATS-640013800 Release Date: 10-24-03 UNCONTROLLED COPY Pa e 5 of 5
Revision: B Revision Date: 07-28-09
10
7
2
1
Figure 8
3
5
(4)
9
8
6
4
(2)
(2)
(
2)
PARTS LIST
Item Order No Engeering No Description Quantity
64001-3800 64001-3800 Hand Crimp Tool Figure 8
1 N/A N/A Torsion Sprin -Handle 1*
2 N/A N/A Sprin - Ratchet 1*
3 N/A N/A Pin-Handle 2
4 Roll Pin 3/16 dia. by 3/16” Lon
1
5 N/A N/A Cresent Rin 4
6 N/A N/A Pin Rivet 2
7 Handle 1
8 N/A N/A Conductor Anvil 1
9 N/A N/A Conductor Punch 1
10 N/A N/A Jaw Link 2
11 64000-0073 64000-0073 Repair Kit* 1
* All sprin s, pins, e-rin s.
Americas Headquarters
Lisle, Illinois 60532 U.S.A.
1-800-78MOLEX
Far East Nort Headquarters
Yamato, Kana awa, Japan
81-462-65-2324
Far East Sout Headquarters
Juron , Sin apore
65-6-268-6868
European Headquarters
Munich, Germany
49-89-413092-0
Corporate Headquarters
2222 Wellin ton Ct.
Lisle, IL 60532 U.S.A.
630-969-4550
Fax: 630-969-1352
Visit our Web site at ttp://www.molex.com
