1 Version 2.1
Bush Baby Stealth Bottle
Hidden Camera Manual
SKU: BBSBottle
2 Version 2.1
THANK YOU FOR PURCHASING THE
BBSBOTTLECAM
Please read this manual before operating the
device and keep it handy. Separate areas contain
water on the top and bottom to give the
impression of a full bottle. We advise that you NOT
use this like a normal bottle of water by repeatedly
drinking from it, as this increases the chance of
water leakage/damage.
Your purchase should include:
1 x BBSBottleCam
1 x BBS Remote Control
1 x Mini USB 8 Pin Cable
1 x Wall AC Adapter
1 x MicroSD Card Reader
1 x 16GB MicroSD Card
1 x User Manual
3 Version 2.1
GET FAMILIAR WITH YOUR BBSBOTTLECAM
4 Version 2.1
5 Version 2.1
BEFORE YOU START
To preserve battery power, your bottle will come
with the toggle switch in the “OFF” position.
Before attempting to use the device, be sure to
turn the toggle switch “ON”.
Note: If you are not located in the US, or if you
intend to use this product anywhere other than the
US, you will need to purchase a converter in order
to use the AC wall plug in and avoid damaging the
product. Because different countries use different
voltages in their electrical wiring, you will need a
converter that adapts to the current in your
particular country.
IMPORTANT WARRANY INFORMATION: If the
warranty sticker on your device has been removed
or tampered with, your lifetime warranty will be
voided. You may be charged fees or denied a
return should this happen.
6 Version 2.1
OPERATING THE CAMERA
IMPORTANT NOTICE: Allow the device to charge 6
–8 hours before using.
REMOVING AND CHARGING THE BATTERY
1. Unscrew the bottle, and locate the USB
port on the device.
2. Connect the mini usb 8 pin charging cable
into the device.
3. Plug the other end of the USB cable into
the wall AC adapter and plug it into the
wall.
4. Wait 6 to 8 hours for the battery to fully
charge.
HOW TO TURN ON THE CAMERA
1. Switch the On/Off Switch to the On
position.
2. Press the Power Button on the remote
control one time (see page 5). Your device
is on when you see an indicator light inside
7 Version 2.1
of the water bottle. The device will also
vibrate once while turning on. The device is
automatically in Standby mode.
HOW TO RECORD CONTINUOUS VIDEO (720P)
1. When the camera is in Standby Mode,
press the “B” button once quickly (see
page 5). The indicator LED will flash twice,
and the unit will vibrate twice.
2. Once the indicator LED turns off, the
camera is now recording video.
3. To stop the recording, press the “B”button
again, the unit will vibrate once & the LED
will turn back on to represent standby
mode.
HOW TO RECORD CONTINUOUS VIDEO (1080P)
1. While the camera is in standby mode, hold
the “C” button for 3 seconds then release.
2. The unit will vibrate two times, and the LED
will blink three times then turn off. The
camera is now recording 1080P video.
8 Version 2.1
3. To save video and return to standby mode,
quickly press the C button. The device will
vibrate once and the unit’s LED light will
come back on for standby mode.
HOW TO RECORD MOTION DETECTION
1. In Standby mode, press the “D” button one
time (see page 5). The indicator light will
flash three times then turn off. The unit
will also vibrate 3 times.
2. The unit is now in motion detection mode
and will begin recording video once motion
is detected. NOTE: There will be no LED or
vibration indicator to indicate when motion
is detected.
3. To return to standby mode and stop
motion detection, press the “D” button
again. The unit will vibrate, and the LED
will come back on.
9 Version 2.1
HOW TO TAKE PICTURES
1. When the camera is in Standby Mode,
press the “C” button (see page 5). The LED
will flash once, the unit will vibrate, then
take one picture. It will return to standby
mode once the photo is taken.
MICROSD CARD SLOT
To access the MicroSD Card Slot, you must
unscrew the bottle right above the label (see page
3).
1. Gently push the MicroSD Card into the slot
(see page 4). The gold contacts on the card
will be inserted first, and they should face
the main circuit board. You will feel some
spring resistance before the card clicks in
to place.
2. Never force the card into the Card Slot
under any circumstance. Otherwise the
Bottle unit or the MicroSD card itself will
be damaged.
10 Version 2.1
3. To remove the SD card, use the thumb of
your nail or tweezers.
MicroSD cards 64GB and above will require
special formatting to work. The device will not
function with these cards if they are not properly
formatted beforehand.
Visit www.mgidownloads.com/Software and
download the “guiformat.zip” file. Extract the files
and follow the instructions in the “64GB SD Card
Formatting.pdf” document.
IMPORTANT NOTICE: Ensure that the bottle is off
before inserting the MicroSD card. Otherwise,
potential corruption of the card file(s) may occur.
RETRIEVE THE FILES TO YOUR PC
1. Connect the MicroSD card to your
computer using the MicroSD card reader.
