Mini Gadgets BBS Manual de usuario
1 Version 2.1
Bush Baby Stealth Manual
For Custom-Built Products
THANK YOU FOR PURCHASING YOUR BBS
CAMERA
2 Version 2.1
Please read this manual before operating the
device, and keep it handy.
Your purchase should include:
1 x BushBaby Stealth Camera
1 x Remote Control
1 x Charging Adapter with Indicator Lights
1 x MicroUSB Cable
1 x Removable Battery
1 x Wall AC Adapter
1 x MicroSD Card Reader
1 x 16GB MicroSD Card
1 x User Manual
GET FAMILIAR WITH YOUR BBS CAMERA
3 Version 2.1
4 Version 2.1
5 Version 2.1
BEFORE YOU START
To preserve battery power, your product will
come with the battery connector disconnected.
Before attempting to use the device, be sure to
connect the battery’s connector to the circuit
board power lead (red plastic pieces at the end of
black and red wires).
Note: If you are not located in the US, or if you
intend to use this product anywhere other than the
US, you will need to purchase a converter in order
to use the AC wall plug in and avoid damaging the
product. Because different countries use different
voltages in their electrical wiring, you will need a
converter that adapts to the current in your
particular country.
IMPORTANT WARRANY INFORMATION: If the
warranty sticker on your device has been removed
or tampered with, your lifetime warranty will be
voided. You may be charged fees or denied a
return should this happen.
6 Version 2.1
OPERATING THE BUSHBABY STEALTH CAMERA
IMPORTANT NOTICE: Allow the device to charge 6 –
8 hours before using.
REMOVING AND CHARGING THE BATTERY
1. Remove battery from your device.
2. Disconnect the battery connector that is
connecting the battery to the circuit board.
Be careful not to pull on the wires as that
could damage them –gently pull on the
plastic pieces instead.
3. Connect the connector on the battery to
the connector on the charging adapter (see
page 4).
4. Plug the provided USB cable into the other
end of the charging adapter.
5. Plug the other end of the USB cable into
the wall AC adapter and plug it into the
wall.
6. Wait 6 to 8 hours.
7 Version 2.1
a. The larger the battery capacity, the
longer it takes to charge.
HOW TO TURN ON THE BUSHBABY STEALTH
CAMERA
1. Press the Power Button on the remote
control one time (see page 3).
2. The device is automatically in Standby
mode.
HOW TO RECORD CONTINUOUS VIDEO (720P)
1. When the camera is in Standby Mode,
press the “B” button once quickly (see
page 3). The unit will vibrate twice.
2. Once the device stops vibrating, it will start
recording video.
3. To stop the recording, press the “B”button
again, and wait three seconds. The device
will return to standby mode.
HOW TO RECORD CONTINUOUS VIDEO (1080P)
8 Version 2.1
1. While the camera is in standby mode, hold
the “C” button for 3 seconds then release.
2. The unit will vibrate three times. When the
device stops vibrating, the camera is
recording 1080P video.
3. To save video and return to standby mode,
quickly press the “C”button, and wait
three seconds.
HOW TO RECORD MOTION DETECTION
1. In Standby mode, press the “D” button one
time (see page 3). The unit will vibrate 3
times.
2. The unit is now in motion detection mode
and will begin recording video once motion
is detected. Note: there will be no
indication when the device detects motion
–it will simply start recording.
3. To return to standby mode and stop
motion detection, press the “D” button
again. The unit will vibrate, and
automatically return to standby mode.
9 Version 2.1
HOW TO TAKE PICTURES
1. When the camera is in Standby Mode,
press the “C” button (see page 3). The unit
will vibrate, and then take a picture. It then
returns to standby mode.
MICROSD CARD SLOT
To access the MicroSD Card Slot, you must check
inside the hat’s bill to find the camera board. It is
inside a black rectangle next to the battery.
1. Gently push the MicroSD Card into the slot.
The gold contacts on the card will be
inserted first, and they should face the
main circuit board. You will feel some
spring resistance before the card clicks in
to place.
2. Never force the card into the Card Slot
under any circumstance. Otherwise the
unit or the MicroSD card itself will be
damaged.
10 Version 2.1
3. To remove the SD card, gently push the
card in so that it clicks.
4. The internal spring tension will eject the
card.
64GB and 128GB microSD cards will require
special formatting to work. The device will not
function with these cards if they are not properly
formatted beforehand.
Visit www.mgidownloads.com/Software and
download the “guiformat.zip” file. Extract the files
and follow the instructions in the “64GB SD Card
Formatting.pdf” document.
IMPORTANT NOTICE: Ensure that the bottle is off
before inserting the MicroSD card. Otherwise
potential corruption of the card file(s) may occur.
RETRIEVE THE FILES TO YOUR PC
