Metra Electronics 95-2009 Manual de usuario

INSTALLATION INSTRUCTIONS FOR PART 95-2009

95-2009

APPLICATIONS

GM/SUZUKI

MULTI KIT

KIT FEATURES

•Double DIN Radio Provision

•Stacked ISO Mount Units Provision

•A) Double DIN Brackets • B) Double DIN Trim Plate • C) Spacers • D) (4) Carriage Bolts

•E) (4) Kep Nuts • F) (3) Screws-(3) Speed Clips

KIT COMPONENTS

TOOLS REQUIRED:

Utility knife • Phillips Screwdriver • Socket Set

1-800-221-0932

www.metraonline.com

WIRING AND ANTENNA CONNECTIONS

(Sold Separately)

• Wiring Harness - Please see www.metraonline.com

for specific interface applications

•Antenna Adapter -

•40-GM10 - GM Antenna Adapter 1988-up

•40-CR10 - Chrysler Antenna Adapter 2002-up

BUICK

Century 1997-2005 3

Le Sabre 1995-2005 4

Park Avenue 1995-2005 5

Rainier 2004-2007 28

Regal 1995-2004 3

Rendezvous 2002-2007 6

Riviera 1996-1999 7

Roadmaster 1995-1996 8

Skylark 1996-1998 9

CADILLAC

Escalade/EXT 2003-2006 10

Fleetwood/Broughham 1990-1996 11-12

Eldorado 1992-1995 13

Seville 1992-1995 13

CHEVROLET

Avalanche 2003-2006 10

Blazer 2002-2005 14

Cavalier 2000-2005 15

Colorado 2004-2010 16

Express Van (full size) 2001-2007 17,18

Impala 2000-2005 19

Malibu 2001-2003 20

Malibu Classic 2004 20

Metro (Geo included) 1995-2001 21

Monte Carlo 2000-2005 22

SSR 2003-2006 23

S-10 Pickup

with DDIN Radio 2002-2004 14

Silverado (all) 2003-2007 10

Suburban 2003-2006 10

Tahoe 2003-2006 10

Tracker 1992-2004 24

Trailblazer 2002-2009 25

Venture 2000-2005 26,27

GMC

Canyon 2004-2010 16

Envoy 2002-2009 28

Savanna 2001-2007 17,18

Sierra 2003-2007 10

Sonoma 2002-2004 14

Yukon/Denali/XL 2003-2006 10

HONDA

Passport 1998-2002 29

HUMMER

H2 2003-2007 30,31

ISUZU

Ascender 2003-2009 28

Amigo 1998-2000 29

I-290/I370 2007-2008 16

I-280/I350 2006 16

Rodeo 1998-2004 29

Rodeo Sport 2001-2003 29

OLDSMOBILE

Achieva 1996-1998 32

Alero 1999-2004 33

Aurora 1995-2003 34

Bravada 1998-2001 14

Bravada 2002-2004 28

Cutlass 1997-1999 35

Cutlass Supreme 1995-1997 35

Eighty-Eight 1994-1999 36

Intrigue 1998-2003 37

LSS 1996-1999 38

Ninety-Eight 1994-1996 36

Regency 1997-1998 38

Silhouette 2000-2004 26,27

PONTIAC

Aztec 2001-2005 39

Bonneville 2000-2005 40

Grand Am 2001-2005 41

Montana 2000-2005 26,27

Sunfire 2000-2005 42

SSUZUKI

Aerio 2002 44

Esteem 1995-2003 45

Sidekick 1992-1998 24

Swift 1995-2001 21

Vitara 1999-2005 24

Grand Vitara 1999-2002 24

XL-7 2001-2002 24

TTOOYYOOTTAA

Matrix 2003-2004 43

TTaabbIInnssttrruuccttiioonnss

CHEVY/GM/METRO/SUZUKI/

CADILLAC - FLEETWOOD/BROUGHHAM . . . . . . . . 46

ISUZU/PONTIAC/TOYOTA/

CADILLAC - ELDORADO/SEVILLE . . . . . . . . . . . . . 47

Kit Assembly

CADILLAC - FLEETWOOD/BROUGHHAM . . . . . . . . 48

CADILLAC - ELDORADO/SEVILLE . . . . . . . . . . . . . 49

DOUBLE DIN RADIO/STACKED ISO MOUNT UNITS

PROVISION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

95-2009

*Note: Refer also to the instructions included with the aftermarket radio.

NOWLEDGE IS

OWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Vibe 2003-2008 43

VEHICLE APPLICATION CONTENTS

Dash Disassembly

95-2009 DASH DISASSEMBLY

BUICK • CENTURY 1997-2005 / REGAL 1995-2004

Unsnap the top edge of the knee

bolster panel.

Disconnect the negative battery

terminal to prevent an accidental

short circuit.

Remove the plastic trim piece to the

left of the glove box and (1) Phillips

screw exposed.

Remove (1) Phillips screw from the

panel.

Remove the ashtray cluster and (2)

Phillips screws from each side.

Unclip the entire dash trim bezel and

remove.

Open doors and unsnap end caps

from each side of dash.

Unsnap and remove radio/instrument

cluster panel.

Remove (3) screws in order to remove

radio.

Continue to kit assembly.

95-2009 DASH DISASSEMBLY

BUICK • LESABRE / PARK AVENUE 1995-1999

Pop out the a/c vents and remove (1)

Phillips screw exposed in each vent

cavity.

Disconnect the negative battery

terminal to prevent an accidental

short circuit.

Unsnap the climate control trim panel

(from door to door) and remove

(4) Phillips screws exposed.

Unclip the radio trim bezel and remove.

Remove the screws securing the fac-

tory head unit and disconnect the

wiring.

Continue to kit assembly.

95-2009 DASH DISASSEMBLY

BUICK • LESABRE / PARK AVENUE 2000-2005

Unsnap and remove trim along center

of dash. (One piece on right and one

on left of wheel)

Disconnect the negative battery

terminal to prevent an accidental

short circuit.

Open drivers door and unsnap and

remove dash end cap.

Unsnap and remove radio/instrument

bezel.

Remove (2) screws in order to remove

radio.

Continue to kit assembly.

95-2009 DASH DISASSEMBLY

BUICK • RENDEZVOUS 2002-2007

Remove liners from cup holders and storage pocket next to cup holders,

then remove screws. Unsnap and remove panel.

Disconnect the negative battery

terminal to prevent an accidental short circuit.

Open center console and remove 2 screws at front of console opening.

Remove (2) screws from bottom of radio/climate control bezel, unclip and remove.

Remove (3) 9/32" hex head screws to remove radio.

Continue to kit assembly.

95-2009 DASH DISASSEMBLY

Remove (1) Phillips screw and unsnap right side panel to expose (1) Phillips screw

beneath panel and remove.

Disconnect the negative battery terminal to prevent an accidental short circuit.

Unsnap left side panel exposing (1) Phillips screw to remove.

Unsnap underside of overhanging dash to unsnap (6) plastic rivets and remove

panel.

Remove (5) hex head screws now exposed under overhang.

Unsnap bottom edge of trim bezel, then while holding overhang up, unsnap and

remove trim bezel by removing any necessary harnesses.

Remove (3) Phillips screw to remove climate control.

Remove (2) Phillips screws to remove rear support and (3) 9/32" hex head screws

to remove radio.

Continue to kit assembly.

BUICK • RIVIERA 1996-

95-2009 DASH DISASSEMBLY

Unclip panel below steering column and remove.

Disconnect the negative battery terminal to prevent an accidental short circuit.

Unclip dash panel sides and remove.

Remove (2) 7mm screws above instrument cluster.

Set parking brake, turn car on, and move shifter to the lowest gear. Tilt steering

wheel down then unsnap entire instrument cluster/radio panel and remove.

Remove (3) 7mm screws to remove radio.

Continue to kit assembly.

BUICK • ROADMASTER 1995-1996

95-2009 DASH DISASSEMBLY

Under glove box and drivers knee bol-

ster, remove (2) plastic panels by

turning (2) 1/4 turn fasteners per side.

Disconnect the negative battery

terminal to prevent an accidental

short circuit.

Remove (6) 9/32" screws inside glove

box.

Remove (4) 9/32" screws revealed.

(2 per side).

Unsnap panel from driver's side to

passenger's side.

Remove (3) 9/32" screws to remove

radio.

ontinue to kit assembly.

BUICK • SKYLARK 1996-1998

95-2009 DASH DISASSEMBLY

Remove (3) 9/32" screws and remove

radio.

Disconnect the negative battery

terminal to prevent an accidental

short circuit.

Unsnap and remove dash bezel.

Continue to kit assembly.

CADILLAC • ESCALADE 2003-2006

CHEVROLET • AVALANCHE 2003-2006

SILVERADO 2003-2007 / SUBURBAN 2003-2006

TAHOE 2003-2006

GMC • SIERRA 2003-2007

YUKON / DENALI / XL 2003-2006
