for iPad, iPhone, iPod touch and iTunes

专为 iPad, iPhone, iPod touch 和 iTunes 打造

Air Speaker

Getting started with

Logitech UE™ Air Speaker

Wireless speaker with AirPlay

快速入门

罗技UE™ Air Speaker

无线音箱 (AirPlay 技术)

Logitech UE Air Speaker

for iPad, iPhone, iPod touch and iTunes

专为 iPad, iPhone, iPod touch 和 iTunes 打造

Air Speaker

Getting started with

Logitech UE™ Air Speaker

Wireless speaker with AirPlay

快速入门

罗技UE™ Air Speaker

无线音箱（AirPlay技术）

Logitech UE Air Speaker

Contents

English. . . . . . . . . . . . . . . . . . 4 简体中文 . . . . . . . . . . . . . . . . . 9

www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4 English

Logitech UE Air Speaker

Features

1. Status indicator

Green: Normal operation

Orange: Network or ﬁrmware issue

2. Ethernet port Connector

for direct connection to a network.

Visit www.logitech.com/support/

airspeaker for setup instructions using

an Ethernet cable

3. Wi-Fi Connect button For use with

computer setup (optional)

4. Auxiliary input 3.5mm audio input

for other music devices (optional)

5. AC power input

6. Mute Press to mute and unmute.

7. Volume Turn clockwise to increase

volume and counterclockwise

to decrease volume.

8. Power Press to turn on the speaker.

While the speaker is on, press to sleep.

Press again to wake. Press and hold

for 5 seconds to turn o the speaker.

(Power-on takes 35 seconds.)

6 7 8

2 3 4 5

Back

Front

Top

English 5

Logitech UE Air Speaker

Set up AirPlay using an iOS device (preferred)

1. Connect the AC power supply and turn

on the speaker. The speaker powers up

in 35 seconds.

2. Press to open the device dock.

Do not dock your iOS device while

the speaker is powering up.

3. Make sure your iOS device is connected

to the same Wi-Fi network on which

you want to operate the speaker.

4. Dock your iOS device after the speaker

powers up. A notiﬁcation will appear

on your screen. Select Yes to install

the Logitech UE Air app.

5. Keep your iOS device docked,

launch the APP, and then follow

the on-screen instructions. Be ready

to enter your Wi-Fi network password.

When the Status indicator turns solid

green, the Wi-Fi network connection

is made.

2 3 4 5

6 English

Logitech UE Air Speaker

Set up AirPlay using

acomputer (optional)

1. Connect the AC power supply.

Turn on the speaker. Wait until

power-on ﬁnishes before proceeding.

(Power-on takes 35 seconds.)

2. Press and hold the Wi-Fi Connect

button for more than 5 seconds.

After 35 seconds the Status indicator

changes from slow blinking green to

fast blinking green to indicate that setup

mode is ready.

3. Open Wi-Fi network settings on

your computer. Select the network called

“Air Speaker Setup”. (For Wi-Fi help

refer to your computer documentation.)

4. Launch an Internet browser.

Enter http://192.168.1.12 in

the address bar. A conﬁguration page

launches.

5. Follow the on-screen instructions.

Be ready to select your Wi-Fi network

and to enter your password. The speaker

will restart. The Status indicator will turn

solid green after the Wi-Fi connection

is made.

Your computer should automatically

reconnect to your Wi-Fi network.

If not, you will need to reconnect it

manually.

Note: If the Status indicator changes

to slow blinking orange, the speaker

did not connect to your Wi-Fi network.

Please visit www.logitech.com/support/

airspeaker for help and try again.

Playing music

The speaker plays music from only

one device at a time. To switch devices,

stop the current device before playing

music on another device.

AirPlay with iOS device (wireless)1

1. Make sure Wi-Fi is turned on for

your iOS device and your iOS device

is connected to the same network as

the Air Speaker

2. Tap the iPod app or a music app.

3. Find the AirPlay icon and tap it.

4. Choose the Air Speaker from the list

of speakers.

5. Select a song or track to play it.

1You can also dock your iOS device.

English 7

Logitech UE Air Speaker

AirPlay with iTunes on

your computer (wireless)

1. Open iTunes. Open Preferences.

Select Devices tab.

2. Activate “Allow iTunes control

from remote speakers.” Click “OK.”

Close Preferences.

3. Find the AirPlay icon and click it.

4. Choose the Air Speaker from the list

of speakers.

5. Select a song or track to play it.

Auxiliary device

1. Connect audio device (e.g., MP3 player)

to auxiliary input.

2. Select a song or track to play it.

Troubleshooting

The speaker is not working

• Is the power cable connected?

Is the speaker powered on?

• Check the volume on the speaker and

at the source. Is the speaker mute on?

• Is the speaker, iOS device, or computer

within range of your Wi-Fi network?

Are they connected to the same

Wi-Fi network? When the speaker

encounters a network issue, the Status

indicator will slowly blink orange.

• Have you selected the “Logitech UE

Air Speaker” as the output device?

• Is your router (modem or gateway)

working properly? Is there a disruption

in your Internet service?

• Security software and ﬁrewalls

may block ports used by AirPlay

to stream content. To resolve this

issue, try updating or reconﬁguring

your ﬁrewall or security products.

(Refer to your ﬁrewall or security

documentation for more information.)

• Does your iOS device have the latest

software?

• If the Status indicator rapidly blinks

orange, the Speaker has a ﬁrmware

issue. Please visit www.logitech.com/

support/airspeaker for help.

8 English

Logitech UE Air Speaker

I don’t know my Wi-Fi network name

(SSID) and password

Please consult your router or ISP modem/

gateway documentation. If you need help,

contact your router manufacturer or ISP

(Internet service provider) if you’re using

an ISP modem/gateway with a built-in

wireless router.

Additional help

If you have more questions about

the Logitech UE Air Speaker,

visit www.logitech.com/support/airspeaker.

Status indicator

Speaker condition STANDBY ON

Booting up (35 seconds or less) — slow blinking green

Connecting to network — blinking green

Connected to network pulsing green solid green

Network problem (no connection) pulsing orange blinking orange

Firmware problem (no connection) pulsing orange fast blinking orange

Wi-Fi Connect mode — fast blinking green

简体中文 9

罗技 UE Air Speaker

功能

1. 状态指示灯

绿灯：运行正常

橙灯：网络或固件故障

2. 以太网端口用于直接连接到网络的接

口。有关使用以太网线缆的设置说明，

请访问 www.logitech.com/support/

airspeaker

3. Wi-Fi 连接按钮进行电脑设置时使用

(可选）

4. 辅助输入接口用于其他音乐设备的

3.5 毫米音频输入接口（可选）

5. 交流电源输入接口

6. 静音按下可静音或取消静音。

7. 音量顺时针旋转可增大音量；逆时针

旋转可减小音量。

8. 电源按下电源按钮可打开音箱。

音箱打开时，按下该按钮可使音箱进

入休眠状态。再按一次该按钮即可唤

醒音箱。按住该按钮 5 秒将关闭音箱。

(音箱启动需要 35 秒。）

6 7 8

2 3 4 5

后面

前面

顶部

10 简体中文

罗技 UE Air Speaker

使用 iOS 设备设置 AirPlay（推荐）

1. 接通交流电源，打开音箱。音箱将在

35 秒内完成启动。

2. 按下打开设备底座。音箱启动过程中，

请勿将 iOS 设备插入底座。

3. 确保 iOS 设备已连接到与音箱相同的

Wi-Fi 网络。

4. 音箱启动后，将 iOS 设备插入底座。

屏幕上将会显示通知。选择“是”，

以安装罗技 UE Air 应用程序。

5. 将 iOS 设备留在底座中，启动应用程

序并按照屏幕指示操作。需输入 Wi-Fi

网络密码，请准备就绪。

当状态指示灯变为稳定的绿灯时，

表示 Wi-Fi 网络已连接成功。

2 3 4 5
