Logitech K780 Manual de usuario

EXPLORE THE K780

MULTI-DEVICE

KEYBOARD

DUAL LAYOUTS

GET STARTED ENHANCED FUNTIONS

EXPLORE THE K780 MULTI-DEVICE KEYBOARD

The K780 Multi-Device Keyboard is a fully equipped computer keyboard that also

works perfectly with smartphones and tablets. Enjoy quiet, comfortable typing,

switching easily between all the devices you enter text on. Works with Windows,

Mac, Chrome OS, Android and iOS.

To enhance your experience on MacOS and Windows download Logitech Options. In

addition to optimizing the keyboard for your preferred operating system, the software

lets you customize the K780 according to your individual needs.

K780 MULTI-DEVICE KEYBOARD

One keyboard. Fully equipped. For computer, phone, and tablet.

K780 Multi-Device at a glance

1Easy-Switch keys

2Dual-printed layout

3Integrated device stand

4Battery door and receiver storage

6Dual connectivity

MX: FAVOR DE LEER EL INSTRUCTIVO ANTES

DE INSTALAR Y OPERAR EL PRODUCTO

650-023723 009

www.logitech.com/downloads

Mac | Windows

Logitech

Options

0:03 Sec.

www.logitech.com/k780

0:03 Sec.Mac: +

0:03 Sec.Windows

2205-10-3229

PMS 3255C

Dieline (does not print)

Project

Date

File Name

P/N

InksGeneva — QSG insert

17 June 2016

PKG_0455 - 650-023723 009 Geneva QSG Insert WW.ai

650-023723.009

Print size

Trim size

383mm x 202.5mm

Finish

Paper

Dieline: DWS-650-023723_004-GENEVA INSERT

Standard AQ

300gsm Duplex

Fonts Brown Pro

GET CONNECTED

K780 Multi-Device keyboard allows you to connect up to three devices either via Bluetooth

Smart or via the pre-paired Unifying USB receiver*.

Quick Setup

Follow the steps below to quickly connect to your computer, laptop or tablet. For more

information on how to connect with Unifying or Bluetooth Smart, go to the sections below.

*The Unifying Receiver is stored in the keyboard under the battery door.

Dual Connectivity

Connect Geneva K780 lets you connect up to 3 devices

(computer, laptops, tablets or smartphones) either via the

Unifying Receiver (2.4 Ghz) or Bluetooth Smart

How to connect

1Download Unifying software. You can download the

software here.

2Make sure your keyboard is turned on.

3Press and hold one of the white easy-switch keys for 3 seconds

(Then LED on the selected channel rapidly blink).

4Congure your keyboard according to your operating system:

For MacOS: Press & Hold fn + o for 3 seconds (The LED on

selected channel will light up)

For Windows, Chrome or Android: Press & Hold fn + p for 3

seconds (The LED on selected channel will light up)

5Plug in the Unifying receiver.

6Open the Unifying software and follow the instructions on

the screen.

Connect with

K780 Multi-Device comes with a pre-paired receiver that provides a plug-and-play

connection to your computer or laptop. If you want to pair a 2nd time to the receiver in

the box or pair to an existing Unifying Receiver, follow these steps.

Requirements

A USB port

Unifying Software

Windows 7, 8, 10 or later

Mac OS X 0.08 or later

Chrome OS

Connect with

K780 Multi-Device Keyboard allows you to connect via Bluetooth Smart. Please ensure

your device is Bluetooth Smart ready and runs one of the following operating systems:

Requirements

Windows 8 or later

Mac OS X 10.10 or later

iOS 5 or later

Android 5.0 or later

Chrome OS

How to connect

1Make sure your K780 Multi-Device is turned on and Bluetooth

is enabled on your computer, tablet or phone.

2Press and hold one of the easy-switch keys for 3 seconds (The

LED on the selected channel will blink rapidly).

3Open Bluetooth settings on your device and pair with

“Keyboard K780”.

4Type the on-screen password and press enter or return.

Keys

Windows 10 Task View Contextual

menu*

Back in

browser

Cortana

search Prev track Play/pause Next Track Mute Volume

down Volume up

Windows 7,

Windows 8

or later

Browser

home page

Contextual

menu*

Back in

browser Search Prev track Play/pause Next Track Mute Volume

down Volume up

Android Home Menu Back Search Prev track Play/pause Next Track Mute Volume

down Volume up

iOS Home

Show/

hide virtual

keyboard

Home Search Prev track Play/pause Next Track Mute Volume

down Volume up

MacOS Mission

Control Dashboard* Back in

browser Search Prev track Play/pause Next Track Mute Volume

down Volume up

Hot keys and media keys

The table below shows hot keys and media keys available for Windows, Mac OS X, Android, and iOS.

Shortcuts

To perform a shortcut, hold down the fn (function) key while pressing the key associated with an action. The

table below shows function key combinations for the dierent operating systems.

Keys

Windows 10 Insert Print screen Lock screen Home (when

editing text)

End (when editing

text) Page up Page down

Windows 7,

Windows 8

or later

Insert Print screen Lock screen Home (when

editing text)

End (when editing

text) Page up Page down

Android - Print screen Lock screen Home (when

editing text)

End (when editing

text) Page up Page down

iOS Language switch Screen Capture Lock screen Home (when

editing text)

End (when editing

text) Brightness down Brightness up

MacOS Language switch Print screen Lock screen Home (when

editing text)

End (when editing

text) Brightness down Brightness up

ENHANCED FUNCTIONS

The K780 Multi-Device has a number of enhanced functions to get even more out of your

new keyboard. The following enhanced functions and shortcuts are available.

*Requires installation of Logitech Options software

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of

such marks by Logitech is under license.

All other trademarks are the property of their respective owners.

To select

an OS

Hold down key

combination

for 3 seconds

Mac OS X +

Windows +

IOS +

White on gray circle

Symbol reserved for

use with Alt Gr on

computers running

Windows

Gray

Reserved for use with

Apple computers

(Mac OS X) or iPhones

and iPads (iOS)

Example (Windows)

Example (Mac OS X or iOS)

Above: Windows and Android

Below: Mac OS X and iOS Split line

Split key labels

Reserved key labels

Key Label Color

Grey labels indicate functions valable on Apple

devices running mack OSX or iOS.

White labels on grey cirlces identify symbols

reserved for us with Alt GR on Windows

computers.*

Split keys

Modier keys on either side of the space bar

display two sets of labels separated by split lines.

The Label above the split line shows the modier

sent to a Windows or Android device.

The Label Below the split line shows the modier

sent to an Apple computer, iPhone, or iPad. The

Keyboard automatically uses modiers associated

with the currently selected device.

How to congure your keyboard

To congure the layout according to your operating

system you have to press one of the following

shortcuts for 3 seconds. (The LED on selected

channel will light up to conrm when the layout has

been congured).

iOS fn + i

Mac OS X fn + o

Windows fn + p

If you connect in Bluetooth Smart this step is

not necessary as OS Detection will congure it

automatically.

DUAL LAYOUT

Unique dual-printed keys make the K780 Multi-Device compatible across dierent

operating system (e.g. Mac OS X, iOS,Windows, Chrome, Android). Key label colors and

split lines identify functions or symbols reserved for dierent operating systems.
