Logitech Keyboard Folio Manual de usuario

Setup Guide

Keyboard Folio

Logitech Keyboard Folio

Contents

English. . . . . . . . . . . . . . . . . . 3

Français . . . . . . . . . . . . . . . . 12

Nederlands . . . . . . . . . . . . . . 21

Ελληνικά . . . . . . . . . . . . . . . . . 30

По-русски . . . . . . . . . . . . . . . . 39

Magyar . . . . . . . . . . . . . . . . 48

Česká verze . . . . . . . . . . . . . . 57

Po polsku . . . . . . . . . . . . . . . 66

Eesti . . . . . . . . . . . . . . . . . . 75

Latviski . . . . . . . . . . . . . . . . 84

Lietuvių . . . . . . . . . . . . . . . . 93

Hrvatski . . . . . . . . . . . . . . . .102

Srpski . . . . . . . . . . . . . . . . . 111

Slovenščina . . . . . . . . . . . . . 120

Slovenčina. . . . . . . . . . . . . . .129

Română . . . . . . . . . . . . . . . .138

Български . . . . . . . . . . . . . . . .147

Українська . . . . . . . . . . . . . . .156

Türkçe . . . . . . . . . . . . . . . . .165

174 . . . . . . . . . . . . . . . . . . 

www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Logitech Keyboard Folio

English 3

Know your product

1. iPad holder

2. Protective folio

3. Function keys

4. Keyboard

5. Bluetooth and battery

status light

6. Bluetooth

connect button

7. On/o switch

8. Micro-USB

charging port

9. Micro-USB

charging cable

10. Product documentation

Setup Guide

Keyboard Folio

Logitech Keyboard Folio

4 English

Setting up the keyboard folio

Getting started

1. Open the keyboard folio and insert

your iPad in the iPad holder:

2. Move the iPad holder into the typing

position (see “Using the keyboard folio”).

Establishing connection

with your iPad

The keyboard folio links to your iPad via

a Bluetooth connection. The ﬁrst time

you use the keyboard folio, you must pair it

with your iPad:

1. Turn on the keyboard:

The status light blinks blue to indicate

that the keyboard is discoverable,

ready for pairing with your iPad.

The ﬁrst time you turn on the keyboard

it remains discoverable for 15 minutes.

If the status light turns red, charge

the battery. For more information,

see “Charging the keyboard battery.”

Logitech Keyboard Folio

English 5

2. On your iPad:

•Make sure your iPad’s Bluetooth

feature is on. Select Settings >

Bluetooth > On.

•Select “Logitech Keyboard Folio”

from the Devices menu.

3. If your iPad requests a PIN, enter it using

the folio keyboard (not on your iPad).

When successful connection is made,

the status light turns solid blue for

a short time, and then turns o.

Connecting to another iPad

1. Make sure the keyboard is turned on.

2. Make sure your iPad’s Bluetooth feature

is on. Select Settings > Bluetooth > On.

3. Press the Bluetooth Connect button:

The keyboard is discoverable

for 3 minutes.

4. Select “Logitech Keyboard Folio”

on your iPad’s Devices menu.

5. If your iPad requests a PIN, enter it using

the folio keyboard (not on your iPad).

When successful connection is made,

the status light turns solid blue for

a short time, and then turns o.

Logitech Keyboard Folio

6 English

Storing your iPad for travel

1. Insert your iPad in the iPad holder.

2. Close the keyboard folio:

Using the keyboard folio

Two viewing positions

The keyboard folio provides two viewing

positions—one for typing and another

for browsing.

To type, move the iPad holder into the

typing position, aligning it with the built-in

magnet to secure it. Turn on the keyboard:

To browse, place the iPad holder in

the browsing position remembering

to switch o the keyboard to conserve

battery power:

If you don’t use the keyboard for a while

in the typing position, it enters sleep mode

automatically. Pressing any key wakes it.

Typing position

Browsing position

Logitech Keyboard Folio

English 7

Status light indicators

Bluetooth and battery status light

Light Description

Blinking green The battery is charging.

Green The battery is charged (more than 20%).

Red Battery power is low (less than 20%). Recharge the battery.

Blinking blue The keyboard is ready for pairing or is trying to reconnect

to your iPad.

Solid blue Bluetooth pairing or reconnection is successful.

Logitech Keyboard Folio

8 English

Function keys

Home = iPad Home screen

Fn + 1 = Lock screen

Locks or unlocks the iPad screen

Fn + 2 = Siri

Use your voice to send messages,

make calls, schedule meetings,

and more

Fn + 3 = Search

Launches the iPad search function

Fn + 4 = Switch language

Switches the keyboard language

Fn + 5 = Virtual keyboard

Shows/hides the virtual keyboard

Fn + 6 = Slide show

Fn + 7 = Previous track

Fn + 8 = Play/Pause

Fn + 9 = Next track

Fn + 0 = Mute

Fn + dash = Volume down

Fn + plus = Volume up

Fn + X = Cut

Fn + C = Copy

Fn + V = Paste

Fn + Left cursor = Select left

Selects text on the left,

word by word

Fn + Right cursor = Select right

Selects text on the right,

word by word

Fn + Spacebar =

Switch applications

Notes:

• To select a function key, press and hold the Fn key, and then press the key indicated above.

• Siri is not supported on iPad 2 or earlier versions.

Logitech Keyboard Folio

English 9

Charging the keyboard battery

If the status light is red the keyboard folio

battery needs to be charged.

1. Plug one end of the micro-USB cable

into the charging port, and the other end

into a USB port on your computer.

The status light blinks green as the

battery charges.

Note: Please note the power input max is 5V,

500mA, if you use an alternative charging

solution.

2. Charge the battery until the status light

turns solid green.

Battery information

•A fully charged battery provides about

three months of use when the keyboard

is used about two hours a day.

•Charge the battery if the status light

turns red brieﬂy after the keyboard

turns on.

•When not in use, turn o the keyboard

to conserve battery power.

•The keyboard enters sleep mode

automatically if not used for a while

in the typing position. Press any key

to wake it.

USB

Logitech Keyboard Folio

10 English

Battery disposal at product

end of life

1. Pry o top cover of keyboard

with screwdriver.

2. Detach battery from circuit board

and remove battery.

3. Dispose of your product and its battery

according to local laws

Visit Product Central

There’s more information and support

online for your product. Take a moment

to visit Product Central to learn more about

your new keyboard folio.

www.logitech.com/support/keyboardfolio

Browse online articles for setup help,

usage tips, and information about

additional features.

Connect with other users in our Community

Forums to get advice, ask questions,

and share solutions.

Find a wide selection of content including:

•Tutorials

•Troubleshooting

•Support community

•Online documentation

•Warranty information

•Spare parts (when available)
