Logitech ZONE WIRELESS PLUS Manual de usuario

LOGITECH ZONE WIRELESS PLUS

Setup Guide

Guide d’installation

CONTENTS

English . . . . . . . . . . . . . . . . .3

Français . . . . . . . . . . . . . . . 11

Español . . . . . . . . . . . . . . . . 19

Português . . . . . . . . . . . . . . 27

LOGITECH ZONE WIRELESS PLUS

Setup Guide

KNOW YOUR PRODUCT

Microphone boom

Power/Pairing

lightindicator

Active Noise Cancellation

(ANC)

Power/Bluetooth®pairing

USB port for

charging cable

Light indicator

USB-A Unifying™

+Audio receiver

Volume up

Volume down

Mute

Multi-function button Qi wireless

charging area

3English

USB-A

Greg’s

Headphones

CHARGING

Mic Mute

Noise Cancellation

Music EQ

Talk Settings

Sound

Notications

GREG’S IPHONE 8

80%

100%4:20 PM

Equalizer

Swipe to change the equalizer preset. To

personalize, simply move the fadersup and

down to taste.

BASS MIDS

SAVE ASCANCEL

TREBLE

Custom

100%4:20 PM

Greg’s

Headphones

CHARGING

Mic Mute

Active Noise

Cancellation

Equalizer

Talk Settings

Voice Prompts

45%

Greg’s iPhone 8

Home iPhone

100%4:20 PM

STANDARD

Side Tone

Put your headset on and start talking. Then

drag your nger to increase or decrease the

volume of your own voice until its just right.

100%4:20 PM

Greg’s

Headphones

Mic Mute

Active Noise

Cancellation

Equalizer

Sidetone

Voice Prompts

45%

MACBOOK PRO

100%4:20 PM

2 sec.

ZONE

WIRELESS

PLUS

WHAT’S IN THE BOX

1. Headset

2. USB-A Unifying™+ audio receiver

3. USB-A charging cable

4. Travel bag

5. User documentation

LOGI TUNE APP

Download Logi Tune App from the Apple App Store®

orGoogle Play™.

1. Headset controls: Mute or unmute your headset

andcontrol noise cancellation with one touch.

2. Wireless updates: Get notied when there is anupdate

of the latest features.

3. Device status: Know your active devices

connected to your headset and streaming.

4. Settings: Control your headset languages and adjust

when headset goes to auto sleep.

5. Status notications: Mute status, battery level

andcharging notications.

6. Immersion adjustments: Sidetone settings to hear

yourown voice at the right volume and EQ presets

toadjust or customize.

POWER ON/OFF

1. Press power button for 1 second.

2. Once powered on, light indicator turns white.

Ifnodevice is connected, it will ash white slowly.

PAIRING VIA BLUETOOTH

1. Press power button for 2 seconds. Light indicator

willash white rapidly.

2. Open Bluetooth settings on your device.

3. Select Zone Wireless Plus in discoverable devices.

4. Once successfully paired, light indicator will turn

solidwhite.

Power

4English

PAIRING HEADSET, KEYBOARD AND MICE VIA USB RECEIVER

1. Download Logitech®Unifying Software at www.logitech.com/support/unifying.

2. Insert the Zone Wireless Plus receiver into the computer USB-A port. Zone Wireless Plus

headset is already paired to the receiver it ships with.Just turn the headset on. Headset is

successfully connected when light indicator on receiver turns solid white.

3. To pair mice and keyboard,

a. Open the software and continue clicking “Next” on the bottom right corner.

Ifyoualready have other unifying receivers (with logo), please unplug them.

b. Locate the OFF-ON slider on your mice and keyboard. Turn each device o and back

onto restart your devices and nish pairing.

- If paired, please follow the on-screen prompt and test it out to conrm successful

pairing.

- If pairing failed, please retry or refer to our support page www.logitech.com/support/

zonewirelesspluspairing.

NOTE: you can pair up to 6 Logitech Unifying peripherals.

ADJUSTING HEADSET

1. Adjust headset by sliding earcups up and down

theheadband.

2. It may be easier to adjust the headset on your head.

Movethe earcups up and down the headband until

theysit comfortably on your ears.

ADJUSTING THE MICROPHONE BOOM

1. Microphone boom rotates 270 degrees. Wear it on either

left or right side. Audio channel will switchautomatically,

depending on the direction you are wearing

themicrophone.

2. Flexible microphone boom — adjust boom location

tocapture voice better.

OFF/ON

www.logitech.com/

support/unifying

Advanced Next

5English

“ANC on”

“ANC o”

ACTIVE NOISE CANCELLATION ANC

ANC blocks out the noise around you to help you

concentrate on the task at hand.

1. Press the ANC button on the side of the earcup.

2. There will be voice notications when turning ANC on

ando. These can be turned o in the Logi Tune app.

MUTE

Mute

Move mic boom

uptomute

Voice notications

indicatewhen

themicrophone is on/

omute

“Mute on”

“Mute o”

Move mic boom

downto unmute

HEADSET CONTROLS

Usage Button Behavior

Call

Answer / End Multi-function 1 second press

Reject Multi-function 2 second press

Music*

Play / Pause Multi-function 1 second press

Track forward Multi-function

and “+” 1 second press

Track backward Multi-function

and “–”1 second press

Headset

status

Check connectivity

andbattery life “+”and “–”1 second press

Voice assistant

(Siri,GoogleAssistant) Multi-function 2 second press

* Functionality depends on types of application. Music controls may not be functional

withweb-based applications. When two devices are connected, connection via Bluetooth will be

prioritized over dongle.

* Tip: Headset Sidetone and Music EQ controls available on Logi Tune app.

Multi-function

6English

Red light indicates

microphone is on mute

Headset indicator light

HEADSET INDICATOR LIGHT

RECEIVER INDICATOR LIGHT

Light Status

Fast ashing WHITE Pairing mode

Solid WHITE Paired

Repeat ashing on and o

in WHITE Incoming call

Solid RED Mute on

Light Status

Solid WHITE Powered on or fully charged

Breathing WHITE Battery charging

Fast pulsing WHITE Bluetooth pairing mode

Slow pulsing WHITE No paired device

Solid RED Low battery

Fast pulsing RED Bluetooth pairing mode while

low battery

Slow pulsing RED No paired device while

lowbattery

* Receiver light indicates headset status only.

7English

Greg’s

Headphones

CHARGING

Mic Mute

Noise Cancellation

Music EQ

Talk Settings

Sound

Notications

GREG’S IPHONE 8

80%

100%4:20 PM

Equalizer

Swipe to change the equalizer preset. To

personalize, simply move the fadersup and

down to taste.

BASS MIDS

SAVE ASCANCEL

TREBLE

Custom

100%4:20 PM

Greg’s

Headphones

CHARGING

Mic Mute

Active Noise

Cancellation

Equalizer

Talk Settings

Voice Prompts

45%

Greg’s iPhone 8

Home iPhone

100%4:20 PM

STANDARD

Side Tone

Put your headset on and start talking. Then

drag your nger to increase or decrease the

volume of your own voice until its just right.

100%4:20 PM

Greg’s

Headphones

Mic Mute

Active Noise

Cancellation

Equalizer

Sidetone

Voice Prompts

45%

MACBOOK PRO

100%4:20 PM

LOGI TUNE APP

Install application

1. Download Logi Tune App from the Apple App Store®

orGoogle Play™ stores by searching for “Logi Tune”.

2. Review the product carousel to learn more about

yourheadset and the app controls.

– Press GET STARTED to enter Bluetooth pairing mode.

3. To continue, follow instructions on the app.

Power

Nearby devices

Charging via Qi wireless charger

1. Fold headset with the wireless charging icon

ontheearcupto the outside.

2. Place earcup with wireless charging icon on top

ofanyQiwireless charging base.*

3. Indicator light will be a breathing, white light

whencharging.

4. Indicator light will be solid white when fully charged.

2hours of charging fully charges the battery.

* Qi wireless charging base is not included.

Headset indicator light

CHARGING

Headset automatically powers o when left idle.

Sleeptimer can be changed in the Logi Tune App.

Headset indicator light will turn RED when battery is low.

Charging via USB cable

1. Plug the micro USB cable end into the micro USB port

onthe bottom of the earcup.

2. Plug the USB-A end into the USB-A charging port

onyourcomputer or AC adapter.

3. Indicator light will be a breathing white light

for charging.

4. Indicator light will be solid white when fully charged.

2hours will fully charge the battery.

5 minutes will give you 1 hour of talk time.

5. Headset can be used with receiver and Bluetooth paired

while charging.

8English

Greg’s

Headphones

CHARGING

Mic Mute

Noise Cancellation

Music EQ

Talk Settings

Sound

Notications

GREG’S IPHONE 8

80%

100%4:20 PM

Equalizer

Swipe to change the equalizer preset. To

personalize, simply move the fadersup and

down to taste.

BASS MIDS

SAVE ASCANCEL

TREBLE

Custom

100%4:20 PM

Greg’s

Headphones

CHARGING

Mic Mute

Active Noise

Cancellation

Equalizer

Talk Settings

Voice Prompts

45%

Greg’s iPhone 8

Home iPhone

100%4:20 PM

STANDARD

Side Tone

Put your headset on and start talking. Then

drag your nger to increase or decrease the

volume of your own voice until its just right.

100%4:20 PM

Greg’s

Headphones

Mic Mute

Active Noise

Cancellation

Equalizer

Sidetone

Voice Prompts

45%

MACBOOK PRO

100%4:20 PM

Greg’s

Headphones

CHARGING

Mic Mute

Noise Cancellation

Music EQ

Talk Settings

Sound

Notications

GREG’S IPHONE 8

80%

100%4:20 PM

Equalizer

Swipe to change the equalizer preset. To

personalize, simply move the fadersup and

down to taste.

BASS MIDS

SAVE ASCANCEL

TREBLE

Custom

100%4:20 PM

Greg’s

Headphones

CHARGING

Mic Mute

Active Noise

Cancellation

Equalizer

Talk Settings

Voice Prompts

45%

Greg’s iPhone 8

Home iPhone

100%4:20 PM

STANDARD

Side Tone

Put your headset on and start talking. Then

drag your nger to increase or decrease the

volume of your own voice until its just right.

100%4:20 PM

Greg’s

Headphones

Mic Mute

Active Noise

Cancellation

Equalizer

Sidetone

Voice Prompts

45%

MACBOOK PRO

100%4:20 PM

NAVIGATE APPLICATION

1. Settings: Control your headset languages and adjust

whenheadset goes into sleep mode.

- Sleep Settings: Adjust when your headset turns o/on.

- Language Settings: Select your headset language.

2. Status notications: Check battery level and charging

notications

3. Mic Mute: Mute or unmute your microphone.

4. Active Noise Cancellation: Turn on/o active noise

cancellation.

5. Voice Prompts: Turn on/o voice notications.

6. Equalizer: Move the faders up and down to create personal

EQ settings. Name and save up to three personal EQ settings.

7. Sidetone: Increase or decrease the volume of your own voice.

8. Device status: Know your active devices connected

toyourheadset and streaming.

9English

Greg’s

Headphones

CHARGING

Mic Mute

Noise Cancellation

Music EQ

Talk Settings

Sound

Notications

GREG’S IPHONE 8

80%

100%4:20 PM

Equalizer

Swipe to change the equalizer preset. To

personalize, simply move the fadersup and

down to taste.

BASS MIDS

SAVE ASCANCEL

TREBLE

Custom

100%4:20 PM

Greg’s

Headphones

CHARGING

Mic Mute

Active Noise

Cancellation

Equalizer

Talk Settings

Voice Prompts

45%

Greg’s iPhone 8

Home iPhone

100%4:20 PM

STANDARD

Side Tone

Put your headset on and start talking. Then

drag your nger to increase or decrease the

volume of your own voice until its just right.

100%4:20 PM

Greg’s

Headphones

Mic Mute

Active Noise

Cancellation

Equalizer

Sidetone

Voice Prompts

45%

MACBOOK PRO

100%4:20 PM

ADJUSTING SIDETONE

Sidetone lets you hear your own voice during

conversationsso you are aware of how loud you are

talking. In the Logi Tune app, select the sidetone feature,

andadjust the dial accordingly.

- A higher number means you hear more external sound.

- A lower number means you hear less external sound.

AUTO SLEEP TIMER

By default, your headset will automatically power o

whennot in use for one hour. Adjust the sleep timer in

theLogi Tune App.

RESET YOUR HEADSET

To reset your headset back to its original state,

powerheadset on, press and hold the ANC button and

volume ’–’ button for 5 seconds. The headset is successfully

reset when it powers o and indicator light turns o.

UPDATE YOUR HEADSET

1. It is recommended to update both your headset

andreceiver. To do so, download the Logi Tune Desktop and

follow the steps. Link found at

www.logitech.com/support/zonewirelessplus/downloads

2. To update only your headset, use the Logi Tune app.

Goto‘About’ and click UPDATE. You must be powered on

and paired with your mobile device.

Logitech Europe S.A. and/or its aliates in the U.S. and other countries. Logitech assumes

noresponsibility for any errors that may appear in this manual. Information contained herein

issubject to change without notice.

10 English

Otros manuales para ZONE WIRELESS PLUS

Tabla de contenidos

Idiomas:

Otros manuales de Auriculares de Logitech

Logitech

Logitech 981-000068 - ClearChat PC Wireless Manual de usuario

Logitech

Logitech BH320 Manual de usuario

Logitech

Logitech 980228-0403 - Mobile Freedom - Headset Manual de usuario

Logitech

Logitech Premium Notebook Headset Manual de usuario

Logitech

Logitech G231 PRODIGY Manual de usuario

Logitech

Logitech Wireless Headset H600 Manual de usuario

Logitech

Logitech Premium USB Headset 350 Manual de usuario

Logitech

Logitech G933 Artemis Spectrum Manual de usuario

Logitech

Logitech Zone Wired Manual de usuario

Logitech

Logitech G233 PRODIGY Manual de usuario

Logitech

Logitech H130 Manual de usuario

Logitech

Logitech Ultimate Ears 350vi Manual de usuario

Logitech

Logitech H151 Manual de usuario

Logitech

Logitech ZONE WIRELESS Manual de usuario

Logitech

Logitech Wireless Headset Manual de usuario

Logitech

Logitech Stereo H650e Manual de usuario

Logitech

Logitech PRO X Manual de usuario

Logitech

Logitech H760 Manual de usuario

Logitech

Logitech H111 Instrucciones de montaje

Logitech

Logitech 980158-0403 - Internet Chat Headset Instrucciones de funcionamiento y seguridad

Logitech

Logitech G35 Manual de usuario

Logitech

Logitech ZONE VIBE 100 Manual de usuario

Logitech

Logitech G935 Manual de usuario

Logitech

Logitech Digital Precision PC Gaming Headset Manual de usuario

Manuales populares de Auriculares de otras marcas

Sena

Sena SMH10 Manual de usuario

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manual de usuario

Sennheiser

Sennheiser EPOS ADAPT 230 Manual de usuario

Doro

Doro Flexus HS2005 Manual de usuario

GE 98971 Manual de usuario

Hama

Hama 00184070 Manual de usuario

Plantronics

Plantronics Blackwire 3200 Series Manual de usuario

Blue Tiger

Blue Tiger Advantage PLUS Manual de usuario

Jawbone

Jawbone Icon Manual de usuario

Jabra

Jabra FR 20 Manual de usuario

Roxcore

Roxcore Flow A+ Manual de usuario

Turtle Beach

Turtle Beach XP 510 Manual de usuario

Philips

Philips SHB6101 Manual de usuario

Jabra

Jabra PRO 9460 Duo Manual de usuario

HyperX

HyperX HyperX Cloud Flight Manual de usuario

Bose

Bose MIE2 Mobile Manual de usuario

Jabra

Jabra Steel Manual de usuario

HyperX

HyperX cloud ii Manual de usuario
