Logitech G435 Manual de usuario

G435

SETUP GUIDE |GUIDE D’INSTALLATION

ENGLISH . . . . . . . . . . . . . . . . . . . . . . . . 3

FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . 12

ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . 21

PORTUGUÊS . . . . . . . . . . . . . . . . . . . . . . 30

3ENGLISH

LIGHTSPEED CONNECTION

Connect to your PC, Mac, PlayStation 5 or 4 with

LIGHTSPEEDWireless Technology

–Insert receiver into the USB port of your device.

–Press the Power button for minimum 1.5 sec.

–The LED turns cyan once connected.

1.5 sec.

4ENGLISH

BLUETOOTH CONNECTION

–Press 3 seconds or longer of the Power

andMutebutton.

–LED will ash blue as it enters pairing mode.

3 sec.

–Connect to your preferred device.

–G435 can connect to a single bluetooth device

atatime.

5ENGLISH

5 sec.

–Press 3 seconds or longer of the Mute button.

–Switch to LIGHTSPEED, LED will light cyan

for5seconds.

–Switch to Bluetooth, LED will light blue

for5seconds.

3 sec.

SWITCH BETWEEN LIGHTSPEED

ANDBLUETOOTH

6ENGLISH

Power ON

–Press the Power button for 1.5 seconds

whentheheadset is OFF.

Power OFF

–Press the Power button for 3 seconds

whentheheadset is ON.

Auto Shuto

–After 30 minutes of inactivity.

1.5 sec.

3 sec.

POWER ON AND OFF

7ENGLISH

MUTE / UNMUTE microphone

–Short press on the Mute button.

Set Max Volume

–Set to 100 dB

–Press 3 seconds or longer Mute button

+VolumeUP.

–LED will ash orange 3 times.

–Set to 85 dB

–Press 3 seconds or longer Mute button

+VolumeDOWN.

–LED will turn solid orange for

5 seconds.

5 sec.

3 sec.

MUTE / UNMUTE AND MAX VOLUME

8ENGLISH

–Single press Power button, when headset is ON

–Battery 31% to 100% the LED will show green

for5 seconds.

BATTERY CHECK

–Battery 15% to 30% the LED will show red

for5seconds.

–Battery <15% the LED will ash red

for5seconds.

5 sec.

9ENGLISH

–Enable Sidetone

–Double press the Mute button and

theLEDwillash twice in orange.

Sidetone lets you hear your voice while communicating

with other people. It mirrors the experience of talking

on a phone and allows you to adjust your speaking

volume to a proper level.

SIDETONE

–Disable Sidetone

–Double press the Mute button and

theLEDwillash once in orange.

10 ENGLISH

–Adjust Sidetone

–UP = Single press Mute button + Volume UP.

–DOWN = Single press Mute button + Volume DOWN.
