Logitech UE9000 Manual de usuario
9000
WIRELESS
HEADPHONES
USER
GUIDE
无线耳机
用户指南
ENGLISH . . . . . . . . . . . . . . . . . . 4
简体中文 . . . . . . . . . . . . . . . . . . . 16
POWER
UP. SYNC
UP. PRESS
PLAY.
Turn on the UE 9000
Wireless Headphones.
Turn on your Ultimate Ears 9000
Wireless Headphones.
The Bluetooth® LED should blink blue rapidly,
indicating that the headphones are discoverable.
Pair your headphones with your Bluetooth-enabled device.
Apple iOS®
Go to Settings > General > Bluetooth.
Turn on Bluetooth.
Select “UE 9000” from “Devices.”
Optional: Pair additional Bluetooth-enabled devices.
You can pair your headphones with up to eight devices. To do so:
1. Move the slider to the “Bluetooth” position and hold it there until the Bluetooth LED
blinks rapidly blue, indicating that the headphones are discoverable.
2. Complete pairing according to the instructions on the previous page.
3. Press play on the device you’ve just paired.
When you’ve successfully paired a device, the Bluetooth LED will turn solid blue.
If pairing times out (the LED will blink slowly), move the slider to the “Bluetooth”
position and hold it there until the LED starts rapidly blinking again.
Press play on your media device.
GET TO KNOW YOUR
UE 9000 WIRELESS
HEADPHONES.
UE 9000 Wireless Headphones
Molded travel case
Optional audio cable with on-cord mic and controls
USB charging cable
AC adapter
¼-inch (6.35 mm) adapter
Microfiber polishing cloth
WHAT’S IN
THE BOX:
Volume up
Play/Pause
Call answer/hang up
Next track
Previous track
Volume down
Listen Through button
Micro USB charging port
3.5 mm input (Interrupts Bluetooth connection when connected)
On/O/Bluetooth connection slider
Bluetooth LED
Battery level LED
Click, or press and hold
Single click
Single click to answer/
press and hold to hang up
Double click
Triple click
Click, or press and hold
Music/Calling
On-ear controls On-cord controls
FEATURES:
LED BEHAVIOR.
Bluetooth LED Battery Level LED
O
Headphones o or connected to
an audio source via the 3.5 mm jack
Blue (blinking rapidly):
Discoverable/pairing mode
Blue (blinking slowly): Connecting
Blue (solid): Connected
O
Headphone o
Green (pulsing slowly): Charging
Green (solid): Power on; fully charged
Red: Low battery
When in wireless mode, all LEDs turn o automatically. However, the LEDs will illuminate
when there is a pairing change or a control is activated.
To use the “listen through” feature, press the Listen Through button once. Your music will be
muted and environmental sounds will be amplified into your headphones. To resume listening
to music, simply press the Listen Through button again.
The “listen through” feature is only available in wireless mode while listening to music.
Itisnot available in wired mode or during phone calls.
FEATURES:
CHARGING.
Typically a three-hour charge through an AC outlet provides up to 10 hours of power,
andyoucan use your headphones while they’re charging.
When the battery level LED turns red, you should recharge your headphones. To do so:
1. Charge the headphones via the supplied AC adapter or USB. The battery level LED
will pulse green.
2. When your headphones are fully charged, the battery level LED will glow
solid green.
or
Micro USB charging port USB charging cable
Computer USB port
AC power adapter
ENGLISH - 9
FEATURES:
TRAVEL STORAGE.
To safely store your headphones while you’re on the go:
1. Swivel the ear cups until they “click”.
2. Place the headphones flat in their case.
3. Place the AC adapter in the top pocket.
4. Place all cables and accessories in the bottom pocket.
PRODUCT CENTRAL.
There’s more information and support available for your product online.
Visit Product Central, where you can:
• Browseonlinearticlesandtutorials.
• Findtipsaboutusageandinformationaboutadditionalfeatures.
• Gethelptroubleshootingaproblem.
• Downloadthelatestsoftwareforyourproduct.
• Findonlinedocumentationandwarrantyinformation.
• ConnectwithotherusersinourCommunityForumstogetadvice,
askquestionsandshare solutions.
• Orderspareparts(whenavailable).
Go to www.logitech.com/support/ue9000
ENGLISH - 11
TROUBLESHOOTING.
If your headphones are not working or pairing/connecting properly, try the following:
•Move closer. The range of the Bluetooth wireless connection is up to 10 meters
or30feet.
•Recharge, particularly if the battery level LED is red. See “Charging.”
• Tryincreasingthevolumeontheheadphones,onyourdeviceor
inyourmediaapplication. And if you’re connected to a computer,
checkthevolumesettings for your operating system.
• EnableBluetoothonyourdevice,andthenselect“UE9000”
fromtheBluetoothdevice list.
• ToxaBluetoothconnectionbyrepairing:
1. On your device: Delete “UE 9000” from the Bluetooth device list
2. On the headphones: Move the slider to “Bluetooth” and hold until
theBluetoothLED blinks blue
3. On your device: Select “UE 9000” from the Bluetooth device list
4.FromthemediaplayeronyourBluetoothdevice:Select“UE9000”
• Forcomputers,youmayneedtospecifytheheadphoneastheinput/output
device for your operating system.
Forhelp,gotowww.logitech.com/support/ue9000
WHAT DO YOU THINK?
PRODUCT SUPPORT.
Please take a minute to tell us.
www.logitech.com/ithink
www.logitech.com/support/ue9000
ENGLISH - 13
BATTERY REMOVAL
AND RECYCLING
1. Peel and remove the ear pad from the left ear cup.
2. Remove screws to disassemble the speaker chamber.
3. Unplug the old battery.
4. Dispose of old battery at an authorized
battery recycling center.
HEADPHONE
DISASSEMBLY
Remove screws
LEFT EAR CUP
Peel and remove
earpad
Unplug battery
ENGLISH - 15
打开电源 设备配对 按下播放
开启 UE 9000
无线耳机。
开启您的 Ultimate Ears 9000
无线耳机。
蓝牙® LED 指示灯应快速闪烁蓝灯，
表示耳机处于可被搜索状态。
将您的耳机与蓝牙设备配对。
苹果iOS®设备
转到“设置”>“通用”>“蓝牙”。
开启蓝牙。
从“设备”选择“UE 9000”。
可选： 与更多支持蓝牙的设备配对
这款耳机最多可与八个设备配对。 要进行此操作：
1. 将滑动开关推至蓝牙指示灯位置并维持直至蓝牙 LED 指示灯快速闪烁再松开，表示耳机处于
可被搜索状态。
2. 按照上一页的说明完成配对。
3. 在刚完成配对的设备上按下播放键。
当您已成功配对设备时，蓝牙 LED 指示灯将变为稳定的蓝灯。
如果配对超时（LED 指示灯将缓慢闪烁），将滑动开关移动到蓝牙指示灯位置，按住开关直至 LED 指
示灯再次开始快速闪烁。
按下媒体设备上的播放键。
单击或按住
单击
单击以接听电话/
按住以挂断电话
双击
单击三下
单击或按住
线控装置
了解您的 UE 9000 无
线耳机。
UE 9000 无线耳机
旅行收纳盒
带有内置麦克风和线控功能的音频连接线
USB 充电连接线
交流电源适配器
¼ 英寸（6.35 毫米）适配器
超细纤维擦拭布
包装
内容：
调高音量
播放/暂停
接听电话/挂断电话
下一曲目
上一曲目
调低音量
Listen Through (静音) 按钮
微型 USB 充电端口
3.5 毫米输入插孔（连通时将中断蓝牙连接）
开启/关闭/蓝牙连接滑动开关
蓝牙 LED 指示灯
电池电量 LED 指示灯
单击或按住
单击
单击以接听电话/
按住以挂断电话
双击
单击三下
单击或按住
音乐/通话
一体式控制 线控装置
