Logitech ZONE VIBE 130 Manual de usuario

ZONE VIBE 130

Setup Guide

Guide d'installation

CONTENTS

English . . . . . . . . . . . . . . . . .3

Français . . . . . . . . . . . . . . . 12

Español . . . . . . . . . . . . . . . . 21

Português . . . . . . . . . . . . . . 30

KNOW YOUR PRODUCT

Front view:

Back view:

Microphone

boom

Music control button

(play/ pause/

nexttrack)

USB-A

adapter

USB-C

receiver

Call button

(answer/ end/

reject calls)

Volume up / down

3English

Bottom view:

3-position switch (power /

Bluetooth®pairing)

Mute button

USB-C port

LED light

4English

USB-C USB-C USB-AUSB-C

BOX CONTENT

1. Zone Vibe 130 wireless headphones

2. Charging cable

3. USB-C receiver

4. USB-A adapter

5. Travel bag

6. User documentation

POWER ON / OFF

1. Slide the switch in the arrow’s direction to

the middle to power on the headphones.

2. Once powered on, the LED light will slightly

turn white.

3. There will be a voice prompt that tells you

the battery status.

5English

CONNECT YOUR HEADPHONES

a. Connect via USB-C receiver

1. Insert the receiver into the computer

USB-C port. Or insert the USB-C receiver

with the USB-A adapter to the USB-A port.

2. Zone Vibe 130 is already paired to the

receiver it ships with.

3. Once successfully paired, the LED light on

the receiver will turn solid white then dim.

b. Connect via BLUETOOTH®

1. Slide the switch to the bottom in the arrow’s

direction for 2 seconds to initiate pairing.

2. The LED light will ash white rapidly.

3. Open Bluetooth®settings on your device.

4. Select Logi Zone Vibe 130 in discoverable

devices.

5. Once successfully paired, the LED light will

turn solid white.

LOGI Zone

Vibe 130

2 sec.

USB-C

USB-A

ADJUSTING HEADPHONES

1. Adjust the headphones by sliding earcups

up and down the extended part of the

headband.

2. It may be easier to adjust the headphones

on your head. Slide the earcups up

and down the headband until they sit

comfortably on your ears.

6English

HEADPHONES CONTROLS

Note:

- Media control functionality depends on the type of application.

- Call activities are always the rst priority. When two devices are connected, the Bluetooth®connection will be prioritized

over the receiver. When two Bluetooth®devices are connected, the last active device will override the other.

Tip: Music EQ controls available on Logi Tune.

UC version:

Usage Button Action

Call controls Answer / End call Call button Short press

Reject call 1.5 sec. press

Music controls Play / Pause Music control button Short press

Track forward Double press

Volume Volume up "+" Short press

Volume down "-"

Connectivity Bluetooth®pairing 3-position button 2 sec. press

Voice notications indicate

when the microphone is on /

o mute.

L L L

Mute

"Mute on"

"Mute o"

MUTE

There are 2 ways to mute your microphone.

Press the button to mute. Flip up or down the mic

boom to mute or unmute.

7English

HEADPHONES LIGHT INDICATOR

Note:

- User-triggered behaviors, such as Bluetooth®pairing, will be prioritized then revert back to its previous status once

thebehavior is completed.

Category Status Light

White

Power

Power ON Turn solid white and then dim

Battery charging Breathing

Battery fully charged Solid and then o

Connectivity Bluetooth®pairing Fast blinking

Bluetooth®/ receiver connected Turn solid white and then dim

Calls Active call Solid

Incoming call Slow blinking

Red Calls Mute Solid

Power Low battery (< 10%) Slow blinking

Factory reset Fast blink from red to white for

three times then LED turn o

RECEIVER LIGHT INDICATOR

UC version

Category Status Light

White

Connectivity

Receiver connecting Fast blinking

Receiver connected Turn solid white and then dim

Receiver disconnected O

Calls

Active call Turn solid white and then dim

Incoming call Repeat "fast blinking 3 times then

LED o"

Red Calls Mute Solid

Blue Connectivity New device pairing Fast blinking

New device paired Solid blue then dim white

Connecting mode

Connected

Incoming call

Mute on

Pairing mode

Paired

8English

CHARGING

To conserve battery life, headphones

automatically power o aer 30 minutes

without usage.

Sleep timer can be adjusted in Logi Tune.

The LED light on the headphones will

blinkslowly in RED when the battery is lower

than 10%.

Charging via USB cable

1. Plug one end of the cable to the USB-C port

on the bottom of the earcup and the other

end into the USB-C charging port on your

computer.

2. The LED light will start breathing white when

charging.

3. The LED light will turn solid white when fully

charged.

– 2 hours will fully charge the battery.

– 5 minutes will give you 1 hour of playback.

Note:

Battery life may vary based on user, environment,

andcomputing conditions.

4. The headphones can be used with the receiver

and Bluetooth®paired while charging.

LOGI TUNE

Logi Tune helps boost your headphones

performance with periodic soware

andrmwareupdates.

It is recommended to update both your

headphones and receiver. To do so, download

LogiTune from www.logitech.com/tune

www.logitech.com/tune

Logi Tune

9English

ADJUSTING SIDETONE

Sidetone lets you hear your own voice during conversations

so you are aware of how loud you are talking. In Logi Tune,

select the sidetone feature, and adjust the dial accordingly.

 A higher number means you hear more external sound.

 A lower number means you hear less external sound.

AUTO SLEEP TIMER

By default, your headphones will automatically power o

when not in use for 30 minutes. Adjust the sleep timer in

Logi Tune. To wake up your headphones, try sliding o/on

the power switch again.

RESET YOUR HEADPHONES

1. Power the headphones on.

2. Press and hold the call button and volume ’–’ button

for5seconds.

3. The LED light will quickly blink from red to white for 3 times

and then turns o when your headphones are successfully

reset.

4. The headphones will turn o aer reset.

10 English
