Linksys SR216 Manual de operación

PRODUCT DATA

BUSINESS SERIES

16-Port 10/100 Switch

Model: SR216

High-speed 10/100 Switching for

Rack-mount or Desktop Installations

With its advanced switching technology, the Linksys 16-Port 10/100 Switch will boost

your network performance with much more than just full duplex data transfer and

dedicated bandwidth. It features non-blocking, wire-speed switching that forwards

packets as fast as your network can deliver them. Also included are Address Learning

and Aging to prevent data transfer errors and Data Flow Control to help prevent packet

collisions.

You have several installation options. The Switch’s compact size fits onto your desktop, or

use the wall mount slots to hang it somewhere out of the way. If your network equipment

is in a rack, install it using the included rack mount brackets.

No matter how intensive your network demands, the Linksys 16-Port 10/100 Switch has

speed, flexibility, and reliability that you can count on.

16 Autosensing 10/100 full

duplex, auto MDI/MDI-X

ports

Runs at non-blocking, full

wire speeds up to 200Mbps

Address Learning and

Data Flow Control for

transmission reliability

Suitable for both desktop

or rack-mount installations

SR216

PRODUCT DATA

BUSINESS SERIES

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more

than 50 countries, supported by

12 Linksys Regional Offices throughout

the world. For a complete list of local

Linksys Sales and Technical Support

contacts, visit our Worldwide Web Site

at www.linksys.com.

Features

Ideal for Integrating Your

10BaseT and 100BaseTX

Network Hardware

16 10/100 Ports Provide

Dedicated Bandwidth in Half

or Full-Duplex Modes

Switched 10/100 Ports

Run at up to 200Mbps in

Full-Duplex Mode

Each port supports Auto

MDI/MDI-X cable detection

Compatible with All Major

Network Operating Systems

Advanced

Store-and-Forward Packet

Switching Optimizes Data

Transfers

Auto Partitioning Protects

PCs from Downed Network

Lines

Signal Regeneration Ensures

Data Transfer Integrity

Free Technical Support—24

Hours a Day, 7 Days a Week,

Toll-Free US Calls

Limited Lifetime Warranty

•

Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or

and product names are trademarks or registered trademarks of their respective holders.

Model: SR216

16-Port 10/100 Switch

Specifications

Model SR216 16-Port 10/100 Switch

Standards IEEE 802.3, IEEE 802.3u

Ports 16 10/100 RJ-45

Cabling Type Category 5 Ethernet or Better

LEDs System, 1 through 16

Range 328 feet

Security features Security Slot

Environmental

Dimensions 11" x 1.75" x 9.45"

W x H x D (279 x 45 x 240 mm)

Unit Weight 3.31 lb (1.5 kg)

Power Input 110V AC, Internal 3.3V/3A

Certification FCC Class B, CE

Operating Temperature 32 to 104ºF (0 to 40ºC)

Storage Temperature -40 to 158ºF (-40 to 70ºC)

Operating Humidity 20 to 95% noncondensing

Storage Humidity 5 to 90% noncondensing

Package Contents

SR216 16-Port 10/100 Switch

AC Power Cord

User Guide

Registration Card

•

6092720NC RR
