Linksys SD2005 Manual de usuario

BUSINESS SERIES

USER GUIDE

5-Port and 8-Port

10/100/1000

Gigabit Switches

Model: SD2005 and SD2008

Model: SD2005

Model: SD2008

5-Port and 8-Port 10/100/1000 Gigabit Switches

Table of Contents

About This Guide 1

Icon Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Online Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Chapter 1: Product Overview 3

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Side Panels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Placement Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chapter 2: Connect the Switch 7

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Connection Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Appendix A: Specifications 9

Appendix B: Warranty and Regulatory Information 10

Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Industry Canada (Canada) . . . . . . . . . . . . . . . . . . . . . . . . . 13

IC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Règlement d’Industry Canada . . . . . . . . . . . . . . . . . . . . . . 13

EC Declaration of Conformity (Europe) . . . . . . . . . . . . . . . . . 13

Appendix C: Contact Information 22

Need to contact Linksys? . . . . . . . . . . . . . . . . . . . . . . . . . . 22

ii 5-Port and 8-Port 10/100/1000 Gigabit Switches

Table of Contents

5-Port and 8-Port 10/100/1000 Gigabit Switches

About This User Guide

Icon Descriptions

While reading through the User Guide, you may encounter various icons

designed to call attention to a specific item. Below are descriptions of

these icons:

NOTE: This check mark indicates that there is a note of interest

and is something that you should pay special attention to

while using the product.

WARNING: This exclamation point indicates that there is a

caution or warning and it is something that could damage

your property or product.

WEB: This globe icon indicates a noteworthy website address

or e-mail address.

Online Resources

Most web browsers allow you to enter the web address without adding

the http:// in front of the address. This User Guide will refer to websites

without including http:// in front of the address. Some older web

browsers may require you to add it.

Resource Website

Linksys www.linksys.com

Linksys International www.linksys.com/international

Glossary www.linksys.com/glossary

25-Port and 8-Port 10/100/1000 Gigabit Switches

About This User Guide

Specificationsaresubjecttochangewithoutnotice.Linksysis aregistered

trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the

registered trademarks of their respective holders.

5-Port and 8-Port 10/100/1000 Gigabit Switches

Chapter 1: Product Overview

Chapter 1:

Product Overview

Introduction

Thank you for choosing the Linksys 5-Port or 8-Port 10/100/1000 Gigabit

Switch.The Switch provides non-blocking, wire speed switching for your

10, 100, and 1000 Mbps network clients.

The 5-Port and 8-Port 10/100/1000 Gigabit Switches differ in number of

LEDs and ports. Pictured here is the 5-Port Switch; however, the 8-Port

Switch is similar in form.

Front Panel

The LEDs are located on the front panel of the Switch.

Front Panel of the 5-Port Switch

System (Green) This LED lights up and remains lit when the Switch is

powered on.

1-5 or 1-8 (Green) Each LED lights up when a connection is made

through its corresponding port. It flashes when the corresponding port

is active.

45-Port and 8-Port 10/100/1000 Gigabit Switches

Chapter 1: Product Overview

Back Panel

The Ethernet network ports are located on the back panel of

the Switch. All ports are auto-negotiating and have automatic

MDI/MDI-X crossover detection.

Back Panel of the 5-Port Switch

1-4 These ports (1, 2, 3, 4) connect the Switch to network

devices, such as computers.

Side Panels

The power port and security slot are located on the side panels of the

Switch.

Side Panel with Power Port

(power) The power port is where you will connect the power

adapter.

5-Port and 8-Port 10/100/1000 Gigabit Switches

Chapter 1: Product Overview

Side Panel with Security Slot

(security slot) The security slot is where you can attach a lock

to protect the Switch from theft.

Placement Options

Set the Switch on its four rubber feet, or mount the Switch on a wall.

The Switch offers two wall-mount slots, which are the two crisscross

slots on the bottom panel. The measurement between the two slots is

2.52 inches (64 mm).

2.52 in

(64 mm)

Bottom Panel of the 5-Port Switch

65-Port and 8-Port 10/100/1000 Gigabit Switches

Chapter 1: Product Overview

To use the wall-mount option, follow these instructions:

Attach two screws to the wall, 2.52 inches (64 mm) apart, so that the

Switch’s wall-mount slots can line up with the two screws.

Maneuver the Switch to insert the screws into the two slots.
