Linksys SR2024C Manual de operación

Wire-speed switching and Linksys reliability in a 24-port Gigabit

switch

Product Data

Model SR2024C

Wired

24-Port 10/100/1000 Gigabit

Switch

The 24-Port 10/100/1000 Gigabit Switch provides non-blocking, wire

speed switching for your 10, 100, and 1000 megabit network clients.

Drop this switch in place of your current workgroup hub or switch,

and you can upgrade your high-requirement workstations to full

Gigabit speeds as necessary, while continuing to service other clients

at their current speeds. Or build your network from the ground up,

with appropriate link speeds for each user's requirements. Either

way, it's perfect for graphics, multimedia, and other applications that

have to move large files across the network quickly. And when you

need to expand your network even further, the two Mini-GBIC ports

let you add fiber-optic capability easily and cost effectively.

With the 24-Port 10/100/1000 Gigabit Switch, you can connect your

existing 10/100 Ethernet network to a Gigabit server backbone

without any additional equipment. All ports have automatic MDI/

MDI-X crossover detection, so you don't have to worry about the

cable type. Each port independently and automatically negotiates for

best speed and whether to run in half- or full-duplex mode. Address

learning and aging is supported, as well as 802.3x flow control with

head-of-line blocking prevention to keep your high-speed clients

from bogging down in lower-speed traffic. Fast store-and-forward

switching prevents damaged packets from being passed on into the

network.

World famous Linksys reliability and the limited lifetime warranty give

you peace of mind and the rackmount form factor integrates

smoothly into your network infrastructure. Let the Linksys 24-Port

10/100/1000 Gigabit Switch kick your network into high gear.

Twenty-four 10/100/1000Mbps,

half/full duplex, switched ports, and

two Mini-GBIC expansion ports.

Forwards packets at non-blocking,

full wire speed.

All ports have auto speed

negotiation and auto MDI/MDI-X

crossover detection.

Linksys reliability and limited

lifetime warranty.

24-Port 10/100/1000 Gigabit Switch

Wired

Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or trademark of

trademarks or registered trademarks of their respective holders.

Model SR2024C

SR2024C-DS-60425NC RR

Features

• 24 RJ-45 ports for 10BASE-T/

100BASE-TX/1000BASE-TX connections

• Supports half duplex and full duplex modes

auto-negotiation for all ports.

• Auto MDI/MDI-X support on all ports for

easy cable detection

• Efficient MAC Address learning engine

supports up to 8K MAC Addresses

• Provides store-and-forward forwarding

scheme.

• Standard width and mounting kit (included)

make it easy to be installed into a rack

• Two mini-GBIC ports for easy expansion to

other mini-GBIC equipped switches

• Integrated 256K packet buffer memory

• Supports Jumbo frame of 9K bytes

• Supports IEEE802.3x full duplex operation

• RoHS Compliant

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

[email protected]m

Web: http://www.linksys.com

Linksys products are available in more than

50 countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit our

Worldwide Web Site at www.linksys.com.

Minimum Requirements Package Contents

• Cat5 Ethernet Network Cable

• TCI/IP Protocol installed on each computer within the

network

• Network Adapter installed in each computer

• Network Operating System (e.g. Windows®, Linux, MacOS

• 24-Port 10/100/1000 Gigabit Switch

•ACPowerCord

• User Guide with On-line Registration Card

• Set of Rack Mounting brackets

Specifications

Model SR2024C

Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab

Ports 24 RJ-45 10/100/1000 + 2 Mini-GBIC ports

Cabling Type Category 5e or better

LEDs System, 1 through 24

Environmental

Dimensions 10.98" x 1.75" x 9.45"

(W x H x D) (279 mm x 44.45 mm x 240 mm)

Weight 4.78 lbs (2.17 kg.)

Power 110-120VAC, 100W

Certification FCC Class A, CE

Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp. -40ºC to 70ºC (-40ºF to 158ºF)

Operating Humidity 20% to 95% relative humidity

Storage Humidity 5% to 95% Non-Condensing
