Lilin IPC0522 Manual de usuario

IPC0522

1080P HD Door Station IP Camera

66-IPC0522CSM

Quick Installation Guide

CAUTION

Do not drop or strike this equipment

Do not install the equipment near any naked flames or heat

sources

Do not expose this unit to rain, moisture, smoke or dust

environment

Do not cover the openin of the cabinet with cloth and plastic

or to install this unit in poor ventilated places. Allow 10cm

between this unit and its surroundin s

Do not continue to operate the unit under abnormal conditions

such as detection of smoke, stran e smell or no display on

screen while power is turned on

Do not touch the power connection with wet hands

Do not dama e the power cord or leave it under pressure

Do not operate this unit near ma net, speaker system, etc., to

avoid unnecessary ma netic interference

Connection cables should be rounded properly

The ITE is to be connected only to PoE networks without

routing to the outside plant.

L’ITE ne doit être connecté que sur un réseau PoE sans

routage vers l’ali entation extérieure.

-1-

English

Product Overview

①

Front cover

②

Main body

③ Rear housin

④ Lens

⑤ IR LED

⑥ Microphone

⑦ Li ht sensor

⑧ PIR

⑨ White LED

⑩ Speaker

⑪

Doorbell button

Unit: mm

-2-

English

Installation

1. Loosen the screws and open the front metal cover with a torx

wrench (FIG.1). Then, detach the main plastic body from the rear

housin usin a Philips screwdriver (FIG.2).

2. Drill holes on the wall accordin to the mountin position sticker

(FIG.3).

Note: a 6.3mm (1/4”) drill bit is recommended.

3. Insert an RJ-45 network cable and a DC12V power cable throu h

the rear housin (FIG.4). Secure the rear housin to any desired

position by ti htenin 4 screws on the rear bracket of the

housin (FIG.5).

-3-

English

4. Connect the RJ-45 network connector and DC12V power input

terminal separately (FIG.6). Then ensure the main plastic body

and the rear housin are ali ned and assembled properly before

securin the screws (FIG.7).

5. Close the front metal cover, and ti hten the two screws to secure

the device (FIG.8).

-4-

English

System Overview

Descriptions of input/output devices

①

Micro SD Card Slot

②

Reset Key

③

Wi-Fi Setup Button (Wi-Fi Model Only)

1.Press and hold the button for 2–5 seconds to enter the QR

Scan Mode.

2.Press and hold the button for more than 6 seconds to enable

the AP mode.

④

Wi-Fi Antenna Plu (Wi-Fi Model Only)

⑤

Video Output Connector

⑥

Alarm In/Out and RS-485 Terminal

⑦

DC12V Power Input terminal (DC12V±10%)

⑧

RJ-45 Network Connector

⑨

Tamper Alarm Switch

-5-

English

System Architectures

To connect the HD Door Station to the network, please deploy one

of the followin system architectures:

(1). Use a DC12V power adapter and a network switch to connect to

the network.

(2). Use a PoE network switch to connect to the network.

(3). Use a PoE power injector and a network switch to connect to

the network.

HD Door Station

-6-

English

Emergency Factory Default

To restore the hardware to factory default settin s, please follow

these steps:

1.Press and hold “RESET Key” for 10 seconds and release.

2.Wait for about 40 seconds, and the network LED li ht should turn

off, and o back on a ain.

3.The camera is now restored to factory default settin s, and will

reboot automatically.

4.Search for the IP device usin the IPScan software.

5.Start the IP device via an Internet browser.

6.Enter the default username “admin” and password “pass” to

operate.

NOTE: For your convenience, the IP address will revert to the default

settin of 192.168.0.200.

Before Accessing IP Cameras

Before accessin the IP camera, make sure that the camera’s RJ-45

network, audio, and power cables are properly connected. To set the

IP address, consult your network administrator for an available IP

address. The default IP address for each IP camera is 192.168.0.200.

Users can use the default IP address for verifyin the camera’s

network connection.

Software Requirements

Merit LILIN Universal ActiveX software components are required for

web interface display of JPEG or H.264 Full HD video. When you

lo in to the IP camera by Internet Explorer, the security warnin

dialo box will prompt the installation of the LILIN Universal ActiveX.

Click Install to download it.

-7-

English

Configuring IP Addresses with IPScan Software

To confi ure an IP address usin the IP scan tool, you can copy the

IPScan software from the installation CD, and paste to your

computer. Alternatively, you can execute the IPScan software from

the installation CD, or download the software from the Merit LILIN

website (www.meritlilin.com). To chan e the settin s of the IP

address, subnet mask, ateway, or HTTP port, you can follow the

steps below:

1. Run the IPScan software.

2. Click Refresh. All available devices should be listed in the device

list.

3. Select your device from the list provided.

4. Chan e the IP address, subnet mask, ateway, or HTTP port for

the IP camera.

5. Click Apply to submit the settin s.

6. Click Refresh to verify the settin s.

-8-

English

Configuring IP Addresses via Web Interface

To chan e an IP address via web interface, type the default IP

address (192.168.0.200) in the Internet browser and follow the steps

below:

1. Lo in to the H.264 Full HD IP camera by the default username

“admin” and default password “pass”

2. Click Basic Mode confi uration hyperlink.

3. Click Network->General hyperlink.

4. Chan e the IP address, subnet mask, ateway, or HTTP port for

the IP camera.

5. Click Sub it to verify the settin s.

Internet Browser Settings & Application Required

Make sure your Internet browser allows the si ned ActiveX plu -in

to work on your computer. Set “Download Si ned ActiveX plu -in

controls” to “Prompt” and “Run ActiveX control and plu -in” to

“Enable”. You can set this option via Internet Explorer-> Tools->

Options-> Security Settin s.
