Lilin CMR7082N/P3.6 Manual de usuario

MERIT LILIN ENT. CO., LTD

http://www.meritlilin.com

INSTRUCTION MANUAL

CMR7082/7084/7088 N/P 3.6/6

66-CMR708CSE

D/N ATR 700TVL IR CAMERA

CMR7082X3.6 N/P

D/N ATR 700TVL VARI-FOCAL IR CAMERA

IMPORTANT SAFEGUARDS

GRAPHIC SYMBOL EXPLANATION

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of

uninsulated "dangerous voltage" within the product's enclosure

that may be of sufficient magnitude to constitute a risk of electric

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature

shock to persons.

accompanying the unit.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION：

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED

BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS

CAUTION

Do not drop or strike this equipment.

Do not install the equipment near any naked flames or heat

sources.

Do not expose this unit to rain or excessive moisture, avoid

smoke and dust.

Do not cover cloth or to install this unit in poorly ventilated

places.

Do not continue to operate if there appears to be fault.

Do not touch the power connection with wet hands.

Do not damage the power cord or leave it under pressure.

Sensitive electronics inside are vulnerable to excessive shock.

Excessive heat could damage this unit.

Please the camera in an environmental housing for protection.

If the camera gets wet, unplug it and have it checked by

qualified service personnel.

This may lead to overheating.

If the unit ceases to function, contact qualified service

personnel for help.

Risk of short circuit or electric shock.

Risk of fire or shock circuit.

CONGRATULATIONS

Thank you for purchasing this D/N ATR 700TVL (Vari-Focal)IR

Camera. You now own one of the many fine CCTV products we

manufactured. This product has been carefully inspected under

rigid quality control and should reach you in perfect condition.

With reasonable care, it will provide years of reliable performance.

We recommend that you read this installation and operation

manual thoroughly before installing and operation your new

system.

Here you will find all the information you need to set up and use

the system. If any questions are not answered in the manual,

please contact your dealer.

Before proceeding, please read and observe all instructions and

warnings contained in this manual. Retain this manual with the

original bill of sale for future reference and, if necessary, warranty

service.

When unpacking your new camera, check for missing or damaged

items. If any item is missing, or if damage is evident,

I . Contact your dealer for

assistance.

DO NOT

NSTALL OR OPERATE THIS PRODUCT

WARRANTY INFORMATION

Please complete the following product purchase information. The

factory will requests this information when contacted for technical

support, or warranty repair. It is also valuable in case of loss or

theft.

Purchase Date

Serial Number

Model Number

：

TABLE OF CONTENTS

PART DESCRIPTION & DIMENSION

INSTALLATION

CONFIGURATION OF THE MENU

SETTING MENU AND FUNCTION

To Open and Exit the Menu screen

Setting of shutter speed of AUTO IRIS mode

Notes

SPECIFICATIONS

TOP COVER

BOTTOM CHASSIS

BRACKET

PAN ADJUSTMENT SCREW

TILT ADJUSTMENT SCREW

WINDOW

VIDEO OUTPUT JACK (CMR7082)

DC POWER INPUT JACK (DC12V 10%,

CMR7082)

Unit: mm

154

101

72.5

PART DESCRIPTION & DIMENSION

DC power input

Video output

INSTALLATION

FIG. 1 FIG. 2

1. CMR7082

1-1. Take out the camera from the inner box first. Plug the video cable and

power cable to video output jack and DC power input jack of the camera

(FIG.1). Then fix bracket to the wall(FIG.2).

1-2. Loosen the screws of top cover with screw driver(FIG.3).

FIG. 3

2. CMR7084/8

2-1. Take out the camera from the inner box first. Loosen the pan adjustment

screw with hexagon screw driver. Then, separated the bracket from the

camera body(FIG.4). Put the power cable and video cable through the

bracket and then fix it to the wall(FIG.5&FIG.6).

FIG. 4

FIG. 6

FIG. 5

2-2. Open the top cover with screw driver(FIG.7).

FIG. 7

2-3. Next, Put the power cable and video cable through the bottom chassis and

rubble(FIG.8) and then fix the camera body on the bracket(FIG.9).

Video Output Video Cable

FIG. 9

FIG. 8

2-4. Plug and fix the power cable to the terminal and plug the video cable to

video output of the camera(FIG.10). For the safety reason, when plug

video cable to video output please use the cable tubing to cover the bare

part to avoid danger of electric shock or electric leakage(FIG.10&FIG.11).

FIG. 11

FIG. 10

Live

Earth

Neutral

Note : When using two-cord

power cable, please

connect them to

"Live" and "Neutral".

3. Loosen the pan and tilt adjustment screw on the bracket to turn the camera body

to the desired angle and then tighten the screws(FIG.12).

4-1. USER OSD SETTING

Setting switches and Functions.

A. (UP)

B. (LEFT)

FIG. 12

: Press to move the cursor upwards or to select

items.

: Press to move the cursor to the left and to select

or adjust the parameters of the selected item.

The parameters changes each time this button is

pressed.

FIG. 13

ZOOM

FOCUS

RIGHTLEFT

DOWN

SET

4. First, adjust the lens on focus and zoom to form the optimal video image after

that tighten the screws(FIG.13). Then adjust the OSD menu to form the

optimal image. Please refer to page7~10.
