OWNER’S MANUAL

CINEMA 3D MONITOR

D237IPS

D2770P

Please read this manual carefully before operating

your set and retain it for future reference.

CINEMA 3D MONITOR MODEL

ENGLISH

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 ASSEMBLINGANDPREPAR-

ING

3 Unpacking

4 Partsandbuttons

6 LiftingandmovingtheMonitorset

6 SettinguptheMonitor

6 - AttachingtheStandBase

6 - DetachingtheStandBaseandBody

7 - Mountingonatable

9 - Mountingonawall

11 USINGTHEMONITORSET

11 ConnectingtoaPC

11 - D-SUBconnection

12 - DVI-Dconnection

12 - HDMIconnection

14 CUSTOMIZINGSETTINGS

14 AccessingTheMainMenus

15 CustomizingSettings

15 - MenuSettings

16 - Thingsyouneedtocheckbeforeinstall-

ingTriDef3D

16 - 3DSettings(Onlywhilein3Dmode)

17 - VolumeSettings(Onlysupportedin

HDMI)

18 - SUPERENERGYSAVINGSettings

19 TROUBLESHOOTING

21 TROUBLESHOOTINGWHEN

USING3DMODE

22 SPECIFICATIONS

24 PresetModes(Resolution)

24 HDMI3DTIMING

24 HDMIVIDEOTIMING

24 Indicator

25 SAFETYPRECAUTIONS

25 - Precautionstotakewhenviewing3D

images

25 - Whenusing3DGlasses

26 PROPERPOSTURE

26 ProperpostureforusingtheMonitorset.

26 Precautionstotakewhenviewing3Dim-

ages

27 LICENSES

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

 Usershoulduseshieldedsignalinterfacecables(RGBcable/DVI-Dcable)withferritecoresto

maintainstandardcompliancefortheproduct.

CAUTION

NOTE

StandBase

PowerCord

CD(Owner'sManual)/

Card

TriDef3DsoftwareProgramCD/

QuickInstallationGuide

D-SUBCable

(Thissignalcablemaybeattached

tothisproductbeforeshippingout.)

DVI-DCable

(Thiscableisnotincludedinall

countries.)

3DGlasses

(Normaltype)

3DGlasses

(Clip-ontype)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

HDMID-SUB

AC-IN/ DVI-D

HDMID-SUB

AC-IN DVI-D

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.11)

Button(Seep.14)

(PowerButton)

AUTOBRIGHT

sensor(Seep.16)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Button Description

MENU Accessesthemainmenus.(Seep.15)

OSDLOCKED/

UNLOCKED

Thisfunctionallowsyoutolockthecurrentcontrolsettings,so

thattheycannotbeinadvertentlychanged.

PressandholdtheMENUbuttonforseveralseconds.

Themessage"OSDLOCKED"shouldappear.

YoucanunlocktheOSDcontrolsatanytimebypushing

theMENUbuttonforseveralseconds.Themessage"OSD

UNLOCKED"shouldappear.

3D 3Ddisplaysettings.(Seep.16)

AUTO Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR

SETUPOSD.(OnlysupportedinAnalogMode)

Thebestdisplaymode 1920x1080

VOLUME(OnlyHDMImode) AdjustthevolumeoftheMonitorset.(Seep.17)

INPUT Youcanchoosetheinputsignal.



Whentwoinputsignalsareatleastconnected,youcanselecttheinputsignal

(D-SUB/DVI/HDMI)youwant.



Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsetting

isD-SUB.

EXIT ExittheOSD(OnScreenDisplay).

(PowerButton) Turnsthepoweronoroff.

PowerIndicator ThepowerindicatorstaysRedifthedisplayisrunning

properly(OnMode).IfthedisplayisinSleepMode,thepower

indicatorblinksRed.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Liftingandmovingthe

Monitorset

WhenmovingorliftingtheMonitor,readthe

followingtopreventtheMonitorfrombeing

scratchedordamagedandforsafetransportation

regardlessofitstypeandsize.

Avoidtouchingthescreenatalltimes,asthis

mayresultindamagetothescreenorsome

ofthepixelsusedtocreateimages.

CAUTION

 ItisrecommendedtomovetheMonitorsetin

theboxorpackingmaterialthattheMonitor

setoriginallycamein.

 BeforemovingorliftingtheMonitorset,

disconnectthepowercordandallcables.

 HoldthetopandbottomoftheMonitor

setframefirmly.Makesurenottoholdthe

transparentpartarea.

 WhenholdingtheMonitorset,thescreen

shouldfaceawayfromyoutopreventthe

screenfromscratches.



 WhentransportingtheMonitorset,donot

exposetheMonitorsettojoltsorexcessive

vibration.

 WhentransportingtheMonitorset,keepthe

Monitorsetupright,neverturntheMonitor

setonitsside,ortilttowardstheleftorright.

SettinguptheMonitor

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION

DetachingtheStandBaseandBody

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

2 Turnthescrewtotheleft,andthenpulloutthe

StandBasefromtheStandBody.

2 AttachtheStandBasetothesetbyturningthe

screwtotherightwithaCoin.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

2 ConnectthePowerCordtoawalloutlet.

3 Press (Power)buttonontheMonitorsetto

turnthepoweron.

10 cm

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

3Loosen2or4screwsandremovethestand

bodyfromthemonitor.

D2770P

D237IPS

ENG

ENGLISH

ASSEMBLING AND PREPARING

UsingtheKensingtonsecuritysystem

TheKensingtonsecuritysystemconnectoris

locatedatthebackoftheMonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweentheMonitorsetandatable.

TheKensingtonsecuritysystemisoptional.

Youcanobtainitfrommostelectronicsstores.

NOTE

Theangleofthescreencanbeadjusted

forwardsorbackwardsfrom-5°to18°fora

comfortableviewingexperience.

NOTE

Front Rear

18- 5

Whenyouadjusttheangle,donotholdthe

bottomoftheMonitorsetframeasshownon

thefollowingillustration,asmayinjureyour

fingers.

Donottouchorpressthescreenwhen

adjustingtheangleofthemonitor.

WARNING

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mounting on a wall

For proper ventilation, allow a clearance of 10 cm

on each side and from the wall. Detailed

instructions are available from your dealer, see the

optional Tilt Wall Mounting Bracket Installation and

Setup Guide.

If you intend to mount the Monitor set to a wall,

attach Wall mounting interface (optional parts) to

the back of the set.

When you install the Monitor set using the wall

mounting interface (optional parts), attach it

carefully so it will not drop.

1 Please, Use the screw and wall mount interface

in accordance with VESA Standards.

2 If you use screw longer than standard, the

monitor might be damaged internally.

3 If you use improper screw, the product might be

damaged and drop from mounted position. In this

case, LG Electronics is not responsible for it.

4 VESA compatible only with respect to screw

mounting interface dimensions and mounting

screw specifications.

10 cm

Model D237IPS D2770P

VESA (A x B) 100 x 100 200 x 100

Standard screw M4 M4

Number of

screws

4 4

Wall mount

bracket

(optional)

RW120 RW240

5 Please use VESA standard as below.

 784.8 mm (30.9 inch) and under

* Wall Mount Pad Thickness : 2.6 mm

* Screw : Φ 4.0 mm x Pitch 0.7 mm x

Length 10 mm

 787.4 mm (31.0 inch) and above

* Please use VESA standard wall mount pad

and screws.

 VESA (A x B)

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Disconnectthepowercordfirst,andthen

moveorinstalltheMonitorset.Otherwise

electricshockmayoccur.

 IfyouinstalltheMonitorsetonaceilingor

slantedwall,itmayfallandresultinsevere

injury.

 UseonlyanauthorizedLGwallmount

andcontactthelocaldealerorqualified

personnel.

 Donotovertightenthescrewsasthismay

causedamagetotheMonitorsetandvoid

yourwarranty.

 Useonlyscrewsandwallmountsthat

meettheVESAstandard.Anydamages

orinjuriesbymisuseorusinganimproper

accessoryarenotcoveredbythewarranty.

CAUTION

 UsethescrewsthatarelistedontheVESA

standardscrewspecifications.

 Thewallmountkitwillincludeaninstallation

manualandnecessaryparts.

 Thewallmountbracketisoptional.Youcan

obtainadditionalaccessoriesfromyourlocal

dealer.

 Thelengthofscrewsmaydifferdepending

onthewallmount.Besuretousetheproper

length.

 Formoreinformation,refertothe

instructionssuppliedwiththewallmount.

NOTE
