OWNER’S MANUAL

AD BOX FOR

TRANSPARENT DISPLAY

TSP500

Please read this manual carefully before operating your set and retain it

for future reference.

AD BOX FOR TRANSPARENT DISPLAY MODELS

ENG

ENGLISH

ENG

ENGLISH

TABLE OF CONTENTS

3LICENSES

4ASSEMBLING AND

PREPARING

4 Accessories

5 Parts and Buttons

6 Installing the Guide Brackets

7REMOTE CONTROL

9USING THE TSP500 SET

9 Connecting to a PC

9 - RGB Connection

10 - DVI Connection

10 - HDMI Connection

11 Adjusting the Screen

11 - Selecting an Image Mode

11 - Customizing Image Options

12 - Customizing PC Display Options

12 Adjusting the Sound

12 - Selecting an Sound Mode

13 - Customizing Sound Options

13 Using Additional Options

13 - Adjusting Aspect Ratio

15 - Using the Input List

16 ENTERTAINMENT

16 - Connecting to a Wired Network

17 - Network Status

18 - Connecting USB Storage Devices

19 - Browsing Files

21 - Viewing Movies

24 - Viewing Photos

27 - Listening to Music

29 - Viewing the Contents List

30 - DivX® VOD Guide

31 - Using PIP/PBP

32 CUSTOMIZING SETTINGS

32 Accessing the Main Menus

33 - PICTURE Settings

36 - Power Sequence

37 - AUDIO Settings

38 - TIME Settings

39 - OPTION Settings

44 Picture ID

45 - NETWORK Settings

46 MAKING CONNECTIONS

47 Connecting to a HD Receiver, DVD

Player, Camcorder, Camera, Gaming

Device or VCR

47 - DVI Connection

47 - HDMI Connection

48 - Component Connection

48 - AV(CVBS) Connection

49 Connecting to the LAN

49 Connecting to a USB

50 TROUBLESHOOTING

53 SPECIFICATIONS

55 IR CODES

56 CONTROLLING THE MULTIPLE

PRODUCT

56 Command Reference List

58 Transmission / Receiving Protocol

ENGLISH

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the

HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in

the United States and other countries.

ABOUT DIVX VIDEO: DivX is a digital video format created by DivX, LLC, a

subsidiary of Rovi Corporation. This is an official DivX Certified device that

plays DivX video. Visit divx.com for more information and software tools to

convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified device must be

registered in order to play purchased DivX Video-on-Demand (VOD) movies.

To obtain your registration code, locate the DivX VOD section in your device

setup menu. Go to vod.divx.com for more information on how to complete

your registration.

DivX Certified to play DivX video up to HD 1080p, including premium

content.

DivX , DivX Certified and associated logos are trademarks of Rovi

Corporation or its subsidiaries and are used under license.

Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668;

7,515,710; 7,519,274

Manufactured under license from Dolby Laboratories. Dolby and the double-D

symbol are trademarks of Dolby Laboratories.

yThe warranty will not cover any damages caused by using the product in an excessively dusty

environment.

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

Accessories

Check your product box for the following items. If there are any missing accessories, contact the local

dealer where you purchased your product. The illustrations in this manual may differ from the actual product

and accessories.

yDo not use any pirated items to ensure the safety and product life span.

yAny damages or injuries by using pirated items are not covered by the warranty.

yRisk of explosion if battery is replaced by an incorrect type.

yDispose of used batteries according to the instructions.

CAUTION

yThe accessories supplied with your product may vary depending on the model.

yProduct specifications or contents in this manual may be changed without prior notice due to upgrade

of product functions.

NOTE

Remote Control

and Batteries

Power Cord

CD (Owner's Manual,

SuperSign Elite-w,

SuperSign Elite-c

Program/SuperSign

Manual) / Cards

INPUT

ENERGY

SAVING

MARK

ARC

OFF



., !



ABC



DEF



GHI



JKL



MNO



PQRS



TUV



1/a/A



-* #

WXYZ

CLEAR

MONITOR

PSM

AUTO

MUTE

BRIGHT

NESS

POWER

S.MENU

BACK TILE

ON OFF

EXIT

RGB Cable IR Receiver

Screws

(For Guide Bracket)

Adaptor

Guide Bracket LVDS Cable

for FHD

LVDS Cable

for HD

ENG

ENGLISH

ASSEMBLING AND PREPARING

Parts and Buttons

Screen Marks Description

/ I Turns the power on or off.

AUTO/SET Displays the current signal and mode.

Press this button to adjust the screen automatically (available only in RGB mode)

Adjusts the volume level.

Adjusts the up and down.

MENU Accesses the main menus, or saves your input and exits the menus.

INPUT Changes the input source.

IR Receiver This is where the unit receives signals from the remote control.

Power Indicator Turns red when the TSP500 set is turned on; blinks amber when it is in Energy Saving

mode.

yYou can set the Power indicator to on or off by selecting OPTION in the main menu.

NOTE

2#L DXWR2VHW# PHQX LQSXW

OYGV#RXW GF#LQ#+4<#Y####,

Connection Panel

Buttons

Power Indicator

yLED On(Red) : Power is on.

yLED On(Amber) : DPM

yLED Off : Power is off.

IR Receiver

ENG

ENGLISH

ASSEMBLING AND PREPARING

Installing the Guide Brackets

1 Install the guide brackets to the set using the screws supplied as accessories.

2Fix the set with the guide brackets installed using the screws supplied as accessories.

2#L

DXWR2VHW#

PHQX LQSXW

Back of the Product

224.2 mm

Guide Bracket

Screws (For Guide Bracket)

2#L

DXWR2VHW#

PHQX LQSXW

Front of the Product

Guide Bracket

ENG

ENGLISH

REMOTE CONTROL

INPUT

ENERGY

SAVING

MARK

ARC

OFF

., !

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

1/a/A

-* #

WXYZ

CLEAR

S.MENU

MONITOR

PSM

AUTO

MUTE

BRIGHT

NESS

BACK TILE

ON OFF

EXIT

POWER

INPUT

ENER

SAVING

MARK

ARC

ABC

1/a/A

-* #

WXYZ

LEA

MONITOR

PSM

BRI

NESS

The descriptions in this manual are based on the buttons of the remote control. Please read this manual

carefully and use the TSP500 set correctly.

To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the

label inside the compartment, and close the battery cover.

To remove the batteries, perform the installation actions in reverse.

yDo not mix old and new batteries, as this

may damage the remote control.

yMake sure to point the remote control to the

remote control sensor on the TSP500 set.

CAUTION

INPUT

ENERGY

SAVING

MARK

ARC

OFF



. , !



ABC



DEF



GHI



JKL



MNO



PQRS



TUV



1/a/A



- * #

WXYZ

CLEAR

S.MENU

MONITOR

PSM

AUTO

MUTE

BRIGHT

NESS

BACK TILE

ON OFF

EXIT

POWER

(POWER)

Turns the TSP500 set on or off.

Monitor On / Off

Turn off the TSP500 and then

turn it back on.

1/a/A Button

Toggles between numerical

and alphabetical.

ENERGY SAVING( )

Adjusts the brightness of

the screen to reduce energy

consumption.

INPUT

Selects the input mode.

Number and Alphabet Buttons

Enters numerical or alphabetical

characters depending on the

setting.

CLEAR

Deletes the entered numerical

or alphabetical character.

PSM

Selects the Picture Status

Mode.

MUTE

Mutes all sounds.

ARC

Selects the Aspect Ratio

Mode.

MARK

Selects a specific file in the

USB mode.

Volume Up / Down

Adjusts the volume level. Brightness Key

Adjust the brightness by

pressing the Up and Down

buttons on the remote control.

In USB mode, the OSD menu

has the Page function to

move to the next file list.

ENG

ENGLISH

REMOTE CONTROL

INPUT

ENERGY

SAVING

MARK

ARC

OFF



. , !



ABC



DEF



GHI



JKL



MNO



PQRS



TUV



1/a/A



- * #

WXYZ

CLEAR

S.MENU

MONITOR

PSM

AUTO

MUTE

BRIGHT

NESS

BACK TILE

ON OFF

EXIT

POWER

S.MENU

(SuperSign Menu Key)

This button selection is not

applicable.

EXIT

Clears all on-screen displays

and returns to the TSP500

set viewing from any menu.

TILE

Selects the TILE Mode.

Accesses the main menus

or saves your input and exit

menus.

Navigation Buttons

Scrolls through menus or

options.

Selects menus or options and

confirms your input.

BACK

Allows the user to move back

one step in user interaction

function.

USB Menu Control Buttons

Controls media playback.

ID ON/OFF

When the number of Picture

ID is equal to Set ID you can

control the TSP500 which

you want in the multi TSP500

condition.

AUTO

Automatically adjusts picture

position and minimizes image

instability.(RGB input only)

INPUT

ENERGY

SAVING

MARK

ARC

OFF

., !

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

1/a/A

-* #

WXYZ

CLEAR

S.MENU

MONITOR

PSM

AUTO

MUTE

BRIGHT

NESS

BACK TILE

ON OFF

EXIT

POWER

.MEN

MEN

XIT

ENG

ENGLISH

USING THE TSP500 SET

Connecting to a PC

The TSP500 does not include the monitor. You

can connect TSP500 to a transparent open frame

(model: 26TS30MF, 47TS30MF, 47TS50MF) to

view the picture on it.

Your TSP500 set supports the Plug & Play* feature.

* Plug & Play: A PC will have a built-in driver for

TSP500, no extra software is needed.

RGB Connection

Transmits the analog video signal from your PC

to TSP500. Connect the PC and TSP500 with

a 15 pin signal cable as shown the following

illustrations.

Select RGB input.

NOTE

yIt is recommended to use the TSP500 set

with an HDMI connection for the best image

quality.

yTo comply with the specifications of the

product, use a shielded interface cable

with ferrite core, such as the D-sub 15 pin

cable and DVI/HDMI cable provided with the

product.

yIf you turn the TSP500 set on when the

TSP500 is cold, the screen may flicker. This

is normal.

ySome red, green, or blue spots may appear

on the screen. This is normal.

yConnect the signal

input cable and tighten

it by turning the screws

clockwise.

yDo not press the screen with your finger for

a long time as this may result in temporary

distortion on the screen.

yAvoid displaying a fixed image on the screen

for a long period of time to prevent image

burn. Use a screensaver if possible.

CAUTION

yApple computers may require an adapter

to connect to this TSP500. Call or visit their

web site for more information.

yUse the standard Macintosh

adapter since an incompatible

adapter is available in the

market. (Different signaling

system)

NOTE

RGB OUT AUDIO OUT

Side of the Product

Macintosh

Adapter

(not included)

(not

included)

PC/MAC PC

ENG

ENGLISH

USING THE TSP500 SET

HDMI Connection

Transmits digital video and audio signals from your

PC to the TSP500 set. Connect the PC and the

TSP500 set with an HDMI cable as shown in the

following illustrations.

Select HDMI input.

yUse a High Speed HDMI™ Cable.

yPlease check the PC environment if you

cannot hear the sound in HDMI mode. Some

PCs require you to manually change the

default audio output to HDMI.

yIf you want to use HDMI-PC mode, you must

set the input label to PC mode.

yWhen HDMI PC is used, a compatibility

problem could occur.

NOTE

Side of the Product

(not included)

HDMI

DVI Connection

Transmits a digtal video signal from your PC to

the TSP500 set. Connect the PC and the TSP500

set with a DVI cable as shown the following

illustrations.

Select DVI input.

DVI OUT AUDIO OUT

Side of the Product

(not

included)

(not included)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de LG

LG Flatron W2600V Manual de usuario

LG 24CK550W Manual de usuario

LG T530SS.ADA Manual de usuario

LG 49WL950G-BE Manual de usuario

LG IPS224T Manual de usuario

LG MultiVision 60PT100N Manual de usuario

LG 55EJ5C Guía de inicio rápido

LG FLATRON L1780U Manual de usuario

LG 24BN650Y Manual de usuario

LG Flatron W1943CM Manual de usuario

LG FLATRON L1721B Manual de usuario

LG Cloud Device 24CK560N-3A.AEU Manual de usuario

LG 34WQ60C Manual de usuario

LG L2000C - - 20.1" LCD Monitor Manual de usuario

LG 20MP38A Manual de usuario

LG 27GK75B Manual de usuario

LG W1954SV Manual de usuario

LG FLATRON T910BJ Manual de usuario

LG Flatron W2753V Manual de usuario

LG 42WT30MS Manual de usuario

LG Flatron L1742T Manual de usuario

LG W2254V-PF Manual de usuario

LG Flatron L206WD Manual de usuario

LG Flatron L1511S Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

Sceptre

Sceptre D40 Manual de usuario
