LevelOne IGP-0501 Manual de usuario

User

Manual

IGP-0501

Port Indusrial PoE Gigabit Switch Manual

Package

Contents

•

IGP

0501

•

User

Manual

CE Marking Warning

CE marking is a certification mark that indicates conformity with health, safety, and

environmental protection standards for products sold within the European Economic Area

(EEA).The CE marking is also found on products sold outside the EEA that have been

manufactured to EEA standards. This makes the CE marking recognizable worldwide even to

people who are not familiar with the European Economic Area.

WEEE

WEEE is waste electrical and electronic equipment. It is end-of-life electrical and electronic

equipment and covers virtually everything with a plug or battery. ... The EC introduced the

WEEE Directive in 2002 to address the environmental impacts of unwanted electrical and

electronic equipment at end-of-life disposal.

FCC Certifications

This Equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received; including interference that may cause undesired

operation.

LevelOne 5-Port Gigabit Industrial Switch Manual

❖ Overview

The IGP-0501 is a 5-port industrial full gigabit PoE switch that supports up to

4*10/100/1000M PoE ports and 1*1000M SFP slot and a high anti-interference ability,

the supports 6KV surge protection, and 6KV contact / 8KV air ESD protection.

IGP-0501 supports wall hanging, desktop and Din-rail installation, reliable

and durable, and can be used in security network video monitoring,

network engineering and other occasions.

❖ Features

•With 4*10/100/1000M PoE ports and 1*1000M SPF slot

•Supports 6KV surge protection, 6KV contact / 8KV air ESD protection

•Supports working temperature -40℃～75℃;

•Supports wall hanging, desktop and Din-rail installation, reliable and durable, and can be used in

security network video monitoring, network engineering and other occasions.

❖ Specifications

Specifications

Power supply

Range of voltage

DC 48~57V

Consumption

Self consumption<5W

Downlink ports

Ports 1~4 10/100/1000Base-T 30W PoE RJ45(IEEE 802.3af/at)

Uplink ports

Port 5 1000Base-X SFP slot

Cable and distance

Use cat5e/6,100m max.

Standard

IEEE802.3, IEEE802.3u, IEEE802.3z

Switch fabric

10Gbps

Thoughput

7.44Mpps

Buffer

MAC address table

Indicator

Power: 2 *red;

Uplink 5: green LEDs indicate Link/Act

Downlink 1~4: On RJ45 green LEDsc/Act, yellow LEDs

indicate PoE

Protection

Surge: 6KV, standard: IEC61000-4-5

ESD: 6KV: contact / 8KV: air, standard:IEC61000-4-2

Working temperature

-40℃~75℃

Storage temperature

-40℃~85℃

Humidity

0~95%(No condensation)

Dimension(L×W×H)

99 mm×65 mm×50mm

Material

Aluminium

Color

Black

Weight

350g

LevelOne 5-Port Gigabit Industrial Switch Manual

❖ Panel diagram

❖ Application

Technical Support

Please contact LevelOne Technical

Support through our website.

http://www.level1.com

LevelOne 5-Port Gigabit Industrial Switch Manual

❖ Dimensions

❖ Order information

Model

Description

IGP-0501

5-Port Gigabit Industrial Switch, DIN-Rail, -40°C to 75°C
