Larson Electronics EPL-HB-100LED-RT-UVA-20C-EPP Manual de usuario

EPL-HB-100LED-RT-UVA-20C-EPP

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

1of 2

Class 1 Division 1 Explosion Proof 100 Watt

Ultraviolet LED Light Fixture - 365NM – Exp Plug

Instruction Manual

The Larson Electronics Explosion Proof Ultraviolet light fixture provides operators with a powerful and energy efficient alternative to

traditional hazardous location luminaires.This fixture uses advanced LED light technology to produce ultraviolet light and is

T6 rated for hazardous locations where UV lamps are used in paint and adhesive curing, food inspection or for non-destructive

testing.

Lamp operates from 100-277 Volts AC, 50/60Hz. Check product for correct voltage before energizing!

100-277V AC Model

An internal, universal input, power-factor-correctedswitch-mode supplyallowsit to be used from any nominal

100-277V AC 50/60 Hzpower supplywithout any variation in light output.

WARNING

To avoidthe riskof fire,explosion or electric shock, thisproduct should be installed, inspectedand maintained by a qualified electrician

only, in accordance with all applicableelectrical codes.

Ultraviolet light can cause damage tothe human eye. Do not stare directly into the ultraviolet beam

without wearing protective gear toprotect eyes from long term damage.

To avoid electric shock:

•Be certain electrical power is OFF before and during installation and maintenance.

•Luminaire must be connected to awiring system withan equipment-grounding conductor.

To avoid explosion:

•Make sure the supply voltage is within the luminaires’voltage rating.

•Ensure the marked Trating is less than the ignition temperature of the Hazardous Atmosphere.

•Do not operate in ambient temperatures abovethose indicated on the luminaire nameplate.

•Do not operate if the lens is cracked or damaged. All fasteners shouldbe properly seated.

For supplyconnections, use wire rated for at least 110°C

Recommendedmounting height is 25-40 feet.

MOUNTING

This fixture offers an adjustable mounting system that allows this fixture tobe mounted toany flat surface including walls and

ceilings. A single ½-13 bolt isused to mount the fixture tothe surface.

Check toensure that allmounting hardware is included.

•2 Small Brackets

•1 Large Trunnion Bracket

•8 Bolts

•8 Lock-Washers

•4 Nuts

See reference images on next page.

1. Using four bolts, washers and the four nutsprovided, attach brackets “A” to both sides ofbracket “B”.

2. The LEDfixture has 9 holes for a versatile mount option. Select the holes that you would like to use.

EPA Reg. No 98409-1

EPA Est. No. 98409-TX-1

EPL-HB-100LED-RT-UVA-20C-EPP

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

2of 2

3. Brackets “A” will then be bolted to the LED fixture with the remaining bolts and washers.

4. The fixture is now ready for installation.

WIRING (see attached wiring diagram)

This unit comes preconfigured with the selected cord cap. Run cable from light and connect to matching

receptacle outputting the correct voltage. Follow all applicable local, state, and National Electrical Code for the

hazardous area!

RECEPTACLE/PLUG OPERATION

Electrical connection between receptacle and plug is accomplished after plug fully inserts into receptacle and

rotated clockwise.

1. Lift receptacle door and locate polarization on mating plug pin and receptacle face. Insert plug straight

all the way into receptacle until it cannot go further.

2. Rotate plug clockwise limit (37º), this closes internal contacts and completes circuit. This also

mechanically locks plug into receptacle so it cannot be pulled out.

3. To remove plug, push plug inward and turn to counterclockwise, pull plug straight out.

MAINTENANCE

Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool down before

performing maintenance.

Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will void

the warranty.

1. Perform visual, mechanical and electrical inspections on a regular basis. We recommend routine

checks to be made on a yearly basis. Frequency of use and environment should determine this. It is

recommended to follow an Electrical Preventive Maintenance Program as described in NFPA 70B:

Recommended practice for Electrical Equipment.

2. The lens should be cleaned periodically as needed to ensure continued photometric performance.

Clean the lens with a damp, non-abrasive, lint-free cloth. If not sufficient, use mild soap or a liquid

cleaner.

3. Inspect the cooking fins on the luminaire to ensure that they are free of any obstructions or

contamination (i.e. excessive dust build-up). Clean with a non-abrasive cloth if needed.

4. Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SALES@LARSONELECTRONICS.COM OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.

WARNING: CHECK NAMEPLATE

FOR PROPER VOLTAGE. DAMAGE

FROM IMPROPER VOLTAGE WILL

VOID WARRANTY.

Brackets “A”

Bracket “B”

Trunnion Bracket

Ultraviolet Radiation Safety

WARNING: Do not attempt operation until you are familiar with all warnings,precautions,and procedures outlinedwithin

thisinstruction sheet.

OPERATION PRECAUTIONS

•UV LIGHT WARNING: UV-C light can cause temporary or permanent loss of vision, and temporary acute

redness or ulceration (mild to severe sunburn) to exposed skin. To prevent exposure, do not operate the device

in any application that allows UV-C light to be visible during operation.

•UV LIGHT CAUTION: UV light may degrade plastic and rubber components after longterm exposure.

•Currently, there are no work place related rules and regulations that are set by OSHA (Occupational Safety and

Health Association) in regard to UVC environmental health and safety.

•NEVER LOOK DIRECTLY AT THE BULB OR DISINFECTING TARGET ZONE

OPERATION SAFETY

•People and animals are forbidden from being exposed to the light output of this light for extended periods of

time. Long term exposure will case damage to the eyes and skin.

•This product produces UV radiation. Anything in front of the unit will be exposed to UV radiation. Operators

positioning the light while not illuminated will not be exposed. Radiation is only emitted while the light is turned

on. Radiation will not linger in the environment when the lamps have been powered off. Safety equipment is only

required when the device is in-use.

•Wear eye protective gear when operating the equipment. Polycarbonate safety glasses at minimum are required

during all operations. Full frontal polycarbonate or UV-preventative face masks are recommended.

•Wear long sleeves and gloves when operating the equipment. Personal protective gear is required for long term

exposure.

These safety precautions will help ensure service personnel are protected from accidental exposure while maintaining

the effectiveness of UV-C to eradicate biological contaminants.

In the event of UV exposure, the following actions are recommended.

OPERATION SAFETY STRATEGIES

•Instruct service personnel to never look directly at UV-C light without adequate eye protection.

•Make it a policy to never enter areas being disinfected with UV lighting systems without powering the system

down first. Methods of powering down depends on the options of the device purchased and may include

unplugging the light source, operating the power switch to power the lamps off, or turning the system off via a

wireless remote control or wireless application.

•Place warning labels near all openings/entrances to areas being disinfected with UV lighting systems. When

possible, lock access doors to prevent unexpected guests from entering the area.

•Close blinds/curtains of areas being disinfected with UV lighting systems if available. If not available, block off

direct access to windows/doorways to prevent access to the area. If you cannot fully block off all access

(hallways with visible windows, etc) place exterior warnings in areas prior to the exposed windows (hall

pedestals, banners, posters) explaining what areas are being disinfected and to not look into the room.

•Educate non service personnel about the intended operations for UV disinfecting and what signage will be

posted. Instruct non service personnel to never look directly at UV-C light.

•Instruct service personnel to always wear personal protective gear (as outlined above) when they must operate in

an area that has UV-C exposure, for short or long term work.

•See an ophthalmologist if eye damage is suspected.

•Treat skin lesions immediately.

•For severe skin lesions, seek local medical treatment and follow their recommendations for treatment.

•Follow your organization’s incident reporting procedure. These often require documentation of the date and

time of the incident, persons involved, equipment involved and type of injury.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SALES@LARSONELECTRONICS.COM OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com 3of 3
