Lantech

IPES-2208CA

8 10/100TX with PoE injector + 2 10/100/1000T/Dual Speed

SFP Combo Managed Industrial Switch

User Manual

V2.02

Mar. 2014

Recommendation for Shielded network cables

STP cables have additional shielding material that is used to reduce external interference. The

shield also reduces the emission at any point in the path of the cable. Our recommendation is

to deploy an STP network cable in demanding electrical environments. Examples of

demanding indoor environments are where the network cable is located in parallel with

electrical mains supply cables or where large inductive loads such as motors or contactors are

in close vicinity to the camera or its cable. It is also mandatory to use an STP cable where the

power device (like IP camera) is used outdoors or where the network cable is routed outdoors.

Table of Content

Chapter 1 Introduction ........................................... 1

1.1 Hardware Features....................................... 1

1.2 Software Features......................................... 4

1.3 Package Contents......................................... 7

Chapter 2 Hardware Description............................ 8

2.1 Physical Dimension....................................... 8

2.2 Front Panel................................................... 8

2.3 Bottom View.................................................. 9

2.4 LED Indicators .............................................10

Chapter 3 Hardware Installation .......................... 12

3.1 Installation Steps..........................................12

3.2 DIN-Rail Mounting........................................13

3.3 Wall Mount Plate Mounting ..........................15

3.4 Wiring the Power Inputs...............................16

3.5 Wiring the Fault Alarm Contact ....................17

3.6 Cabling ........................................................18

Chapter 4 Network Application............................ 22

4.1 Pro-Ring2s Application.................................24

Chapter 5 Console Management.......................... 25

5.1 Connecting to the Console Port....................25

5.2 Pin Assignment............................................25

5.3 Login in the Console Interface......................26

5.4 CLI Management .........................................27

Chapter 6 Web-Based Management.................... 28

6.1 About Web-based Management...................28

6.2 Preparing for Web Management ..................28

6.3 System Login...............................................29

6.4 System.........................................................30

6.5 Time - SNTP................................................33

6.6 Account - Admin...........................................36

6.7 IP Addressing –IPV4...................................37

6.8 Syslog..........................................................39

Syslog Configuration...................................................... 39

6.9 SNMP Configuration....................................40

SNMP - Agent................................................................ 40

6.20.1 SNMP Trap Configuration............................. 42

6.10 System Alert - Relay Alarm..........................43

6.8.1 System Alert - SMTP....................................... 43

6.8.2 System Alert - Event ....................................... 45

6.11 DHCP Server...............................................47

6.6.1 DHCP Server - Server configuration............... 47

6.6.2 Client Table ..................................................... 48

6.6.3 IP Bindings ...................................................... 48

6.12 Port - Configuration......................................50

6.13 Port Status...................................................51

6.14 Port Statistics...............................................52

6.15 Port –Port Alert ...........................................54

6.16 Rate Control –Rate Limit..............................55

6.17 Aggregation - Configuration .........................57

6.17.1 Configuration................................................. 58

6.17.2 Aggregator –Status ...................................... 60

6.18 Spanning Tree.............................................61

6.18.1 RSTP Setting................................................. 61

6.18.2 RSTP Information............................................... 63

6.19 Pro-Ring II S................................................64

6.20 Multicast Support.........................................66

6.21 LLDP ...........................................................69

6.22.1 LLDP Neighbors .........................................70

6.23 Filtering Database........................................71

6.24 VLAN...........................................................73

6.24.1. VLAN Configuration...................................... 73

6.24.2 Switch Status................................................. 76

6.25 QoS.............................................................77

6.25.1 Global Settings.............................................. 77

6.25.2 Port Priority................................................. 78

6.25.3 COS Mapping to Queue................................ 79

6.25.4 DSCP mapping to queue .............................. 80

6.26. Power over Ethernet..................................82

6.27. Port Mirroring ............................................87

6.28. Security.....................................................88

6.26.1 IP Source Guard - Configuration................... 88

6.26.2 IP Source Guard –Static Table .................... 89

6.26.3 802.1X/Radius............................................... 90

6.26.4 MAC Filtering...................................................... 93

6.26.5 Port Security.................................................. 94

You can block the un-authorized MAC by oer port in

this function...............................................................94

6.29. Maintenance..............................................95

6.27.1 Save Configuration .....................................95

Troubles shooting................................................ 100

Appendix A—RJ-45 Pin Assignment................... 101

RJ-45 Pin Assignments .......................................101

RJ-45 Pin Assignment of PoE..............................104

Appendix B—Command Sets.............................. 106

Switch Setting Commands Set.................................... 106

Admin Password Commands Set................................ 107

IP Setting Commands Set ........................................... 107

SNTP Commands Set ................................................. 108

LLDP Commands Set.................................................. 109

Backup & Restore Commands Set.............................. 110

Upgrade Firmware Commands Set............................. 110

DHCP Server Commands Set..................................... 110

Port Control Commands Set........................................ 112

Port Status Commands Set......................................... 114

Rate Limit Commands Set........................................... 114

Trunk Commands Set.................................................. 115

PRO-RING IIS Commands Set ................................... 117

RSTP Commands Set ................................................. 117

VLAN Commands Set ................................................. 119

SNMP Commands Set ................................................ 122

Traffic Prioritization Commands Set............................ 123

IGMP Commands Set.................................................. 124

Multicast Static Filtering Table Commands Set .......... 125

IP Security Commands Set ......................................... 126

Port Security Commands Set...................................... 127

MAC Blacklist Commands Set..................................... 127

802.1x Commands Set................................................ 128

Fault Alarm Commands Set ........................................ 130

System Warning Commands Set ................................ 130

Mac Address Table Commands Set............................ 133

Port Statistics Commands Set..................................... 134

Port Monitoring Commands Set .................................. 134

System Event Log Commands Set ............................. 135

Ping Commands Set.................................................... 135

SFP Monitor Commands Set....................................... 135

Loading Average Commands Set ............................... 135

Save Configuration Commands Set............................ 138

Factory Default Commands Set .................................. 138

System Reboot Commands Set.................................. 138

Logout Commands Set................................................ 138

FCC Warning

This Equipment has been tested and found to comply with the limits for a

Class-A digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy. It may cause harmful interference to radio

communications if the equipment is not installed and used in accordance

with the instructions. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class-A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

Chapter 1 Introduction

The 8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo w/ 8-PoE-Injector 802.3af

Managed Industrial Switch is a cost-effective solution and meets the high reliability

requirements demanded by industrial applications. Using fiber port can extend the

connection distance that increases the network elasticity and performance.

1.1 Hardware Features

Standard

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX/ FX

IEEE802.3ab 1000Base-T

IEEE802.3z Gigabit fiber

IEEE802.3x Flow Control and Back Pressure

IEEE802.3ad Port trunk with LACP

IEEE802.1d Spanning Tree/ IEEE802.1w Rapid Spanning

Tree

IEEE802.1p Class of Service

IEEE802.1Q VLAN Tag

IEEE 802.1x User Authentication (Radius)

IEEE802.1ab LLDP

Switch

Architecture

Back-plane (Switching Fabric): 7.4Gbps

Packet throughput ability(Full-Duplex): 8.3Mpps @64bytes

Transfer Rate

14,880pps for Ethernet port

148,800pps for Fast Ethernet port

1,488,000pps for Gigabit Fiber Ethernet port

Packet Buffer

1Mbits

MAC Address

8K MAC address table

Flash ROM

4Mbytes

DRAM

32Mbytes

Connector

10/100TX: 8 x ports RJ-45 with Auto MDI/MDI-X function

10/100/1000T/SFP Combo port: 2 x RJ-45 + 2 x 100/1000

SFP socket with DDM

RS-232 connector: RJ-45 type

Network Cable

10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E cable

EIA/TIA-568 100-ohm (100m)

100Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable

EIA/TIA-568 100-ohm (100m)

1000Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable

EIA/TIA-568 100-ohm (100m)

Optical Fiber

Distance:

Multi mode:

0 to 5 km, 1300 nm (50/125 μm, 800 MHz*km)

0 to 4 km, 1300 nm (62.5/125 μm, 500 MHz*km)

Single mode:

0 to 40 km, 1310 nm (9/125 μm, 3.5 PS/(nm*km))

0 to 80 km, 1550 nm (9/125 μm, 19 PS/(nm*km))

Min. TX Output:

Multi mode: -20 dBm

Single mode: 0 to 40 km, -5 dBm; 0 to 80 km, -5 dBm

Max. TX Output:

Multi mode: -14 dBm

Single mode: 0 to 40 km, 0 dBm; 0 to 80 km, 0 dBm

Sensitivity:

-36 to -32 dBm (Single mode); -34 to -30 dBm (Multi mode)

PoE pin

assignment

RJ-45 port # 1~# 8 support IEEE 802.3af End-point,

Alternative A mode. Per port provides up to 25W@48V;

15.6W@24V (PD must embedded TI TPS-2376-H chip)

Positive (VCC+): RJ-45 pin 1,2.

Negative (VCC-): RJ-45 pin 3,6.

Tabla de contenidos

Otros manuales de Cambiar de Lantech

Lantech

Lantech IPES-0008A Series Manual de usuario

Lantech

Lantech 2204F Series Manual de usuario

Lantech

Lantech IGS-0016 Manual de usuario

Lantech

Lantech IPES-0208CA-12V Manual de usuario

Lantech

Lantech IES-2208CA Manual de usuario

Lantech

Lantech IES-2208CA-DNV Manual de usuario

Lantech

Lantech LGS-2404 Manual de usuario

Lantech

Lantech IPES/IES-5416T Series Manual de usuario

Lantech

Lantech IGS-0208GSFP Manual de usuario

Lantech

Lantech LGS-2816C-RPS Manual de usuario

Lantech

Lantech GE-800 Manual de usuario

Lantech

Lantech IPGS-5008T Series Manual de usuario

Lantech

Lantech IGS-3208MGSFP Manual de usuario

Lantech

Lantech LPES-2208CA Manual de usuario

Lantech

Lantech IPES-3424DSFP-2P-PT Manual de usuario

Lantech

Lantech IPES-0005B Series Manual de usuario

Lantech

Lantech 5 10/100TX w/ 4 PoE Injector Industrial... Manual de usuario

Lantech

Lantech IPGS-5424 Manual de usuario

Lantech

Lantech IES-2008B-DNV Manual de usuario

Lantech

Lantech IPES-5408T-X-IGN Series Manual de usuario

Lantech

Lantech LPES-2224C Manual de usuario

Lantech

Lantech IPES-0008B Series Manual de usuario

Lantech

Lantech LES-2400-RPS Manual de usuario

Lantech

Lantech LGS-1104 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
