Kohler K-1800X Instrucciones de montaje

Installation and Care Guide

Lithocast Freestanding Bath





K-1800X

1149955-X2-A 2 Kohler Co.



Important Information

Thank you for choosing Kohler Company

We appreciate your commitment to Kohler quality. Please take a few minutes

to review this manual before you start installation. If you encounter any

installation or performance problems, please call 0-2204-6222 for Call Center

(Thailand). Thank you again for choosing Kohler Company.

Please read these instructions carefully to familiarize yourself with the required

tools, materials, and installation sequences. Follow the sections that pertain

to your particular installation. This will help you avoid costly mistakes.

In addition to proper installation, read all operating and safety instructions.

All information in this manual is based upon the latest product information

available at the time of publication. At Kohler, we constantly strive to improve

the quality of our products. We reserve the right to make changes in product

characteristics, packaging or availability at any time without notice.

NOTE: The bathtub pictured in the installation steps may dier from the

model being installed.

IMPORTANT NOTICE TO INSTALLERS!: Please leave these instructions for

the consumer. They contain important information.

In addition to installation procedures, this manual contains important care and

cleaning. Please retain for future reference.

¨Please provide adequate available space for the bath unit in accordance with

roughing-in. Arrange the location of drain in advance.

¨ Bath can be installed aer the wall is completed. Bath drain supplies

should be arranged preliminarily according to the selected bath.

  







Kohler Co. 3 1149955-X2-A



  



 



  





 



 





¨



¨ 

 

Product Requirement

A. Summary Of Key Requirements

¨Observe all local plumbing codes.

¨Install the unit to a level suboor.

¨LITHOCAST bath is heavy. Please make sure the oor provides adequate

support for the bath. With its weight and water consumption marked

in the roughing-in, the bath is supported with four 70 x 70 mm squared

feet. Please evaluate with the data above if your oor provides adequate

support for the weight of the bath, water and the user.

B.PlumbingSpecications

Conrm adequate mounting, connection space for the faucet specied for your

installation.

C. Product Inspection

Unpack and inspect bath for damage. All Kohler’s baths have been manufactured

with sophisticated crasmanship. However, please inspect for any possible

1149955-X2-A 4 Kohler Co.





¨

¨

¨ 

 







 



  

  



damage that may have occurred in transit. Leave all materials in the crate

during construction to prevent damage.

NOTE: Damage occurred during transit shall not be covered by warranty.

D. New or Replacement Installation Requirements

For replacement: Remove the old bath, and remove enough old wall material

and oor covering from the area to allow for installation. Remove any old

plumbing that does not conform to the roughing-in requirements.

For new installation: Position the plumbing according to the roughing-in

dimensions.

E. Clearance Requirements

¨Check the roughing-in and room dimensions to provide adequate available

space for the bath unit.

¨ Make sure the ooring oers adequate support for your bath, and verify

that the suboor is at and level.

Product Requirement (Continue)

Kohler Co. 5 1149955-X2-A

Tool and Material

A. Tools Required

• Adjustable pipe wrench

• Tape measure

• Level

• Safety shoes/Safety glasses

• Square

• Screwdriver

• Pliers

• Utility knife

• Adjustable wrench

B. Materials Required

• Plumbers puy

• Tile (as necessary)

• Silicone sealant

• Gypsum cement (optional)

• Construction adhesive (optional)

• Protective covering for bathtub

• Nails





• 

• 

• 

• 

• 

• 

• 

• 

• 



• 

• 

• 

• 

• 

• 

• 



 







¨ 



¨ 

 



1149955-X2-A 6 Kohler Co.

Prepare the Site

Before You Begin

NOTICE: Adequate oor support must be provided. Consult the roughing-in

sheet packed with your bath for specic oor loading requirements.

¨ Ensure the suboor oers adequate support for your bath.

¨ Ensure the suboor is level.

IMPORTANT! To ensure a successful installation, it is critical that bath be

installed on a perfectly level nished oor.

¨ Ensure the nished oor is perfectly level before proceeding with the bath

installation.

NOTICE: Protect the Bath Unit

Position a clean drop cloth or similar material in the boom of the bath. Be

careful not to scratch the bath surface.

WARNING: Risk of personal injury. The bath weighs 238 kg. Use proper

liing technique when handling the bath.





 



¨

¨

 



¨

  



 



Kohler Co. 7 1149955-X2-A

1. 

2. 

¨

¨

 



¨





 

¨



1. Install the Plumbing

2. Secure the bath in the proposed position

¨The drain has been installed onto the bath before it leaves factory.

¨Fill the bath with water before the bath is securely positioned so as to

check the supply connections for leaks. Kohler Co. shall not be liable under

its warranty or otherwise for damage caused by negligence.

NOTE: Carefully li the bath on the oor.

¨ Li the stone bath by about 30 cm from the oor. You can support the bath

with 30 cm-height-blocks beneath its boom.

IMPORTANT: The bath must be installed level on all top edges. Floor should

be at, level and free of any bumps or protrusions.

¨The drain of the bath is instructed to the bath beforehand. Please insert the

drain hose to the oor drain, and seal the connection of hose and the oor

drain with silica gel. Please set apart some spare length of the hose, in case

of future bath maintainance.

¨ Place the bath on the oor. Put the spirit level to the upper level of the bath

to measure the levelness. If the bath is not level, please put sheet metal under

the bath to raise it up. You might need to li the bath several times.

1149955-X2-A 8 Kohler Co.



Cleaning Your LITHOCAST Bath





• 



•   



• 



• 

• 



For best results, keep the following in mind when caring for your KOHLER

product:

• Use a mild detergent such as liquid dishwashing soap and warm water for

cleaning. Do not use abrasive cleaners that may scratch or dull the surface.

• Carefully read the cleaner product label to ensure the cleaner is safe for use

on the material.

• Always test your cleaning solution on an inconspicuous area before applying

to the entire surface.

• Do not allow cleaners to sit or soak on the surface.

• Wipe surfaces clean and rinse completely with water immediately aer

cleaner application. Rinse and dry any overspray that lands on nearby

surfaces.

• Use a so, dampened sponge or cloth. Never use an abrasive material such

as a brush or scouring pad to clean surfaces.





¨





Kohler Co. 9 1149955-X2-A



User’s Guide

1. Do not put objects with high temperature on the bathtub directly or for

a long time.

¨Although LITHOCAST bathtub is heat-resisting, its surface will still be

damaged under too high a temperature. Keles containing boiling water

or other objects with too high a temperature are likely to cause damage to

the surface of the bathtub.

¨Please control water temperature of the water in the bathtub or the water

being poured into the bathtub under 50 °C.

CAUTION: Do not pour water with too high temperature directly into the

bathtub.

2. Spots caused by scratching, common chemicals, burning and slight knocks.

¨Spots caused by nicks, scratching and burning are unavoidable for

frequently used LITHOCAST bathtub. However, since LITHOCAST

is solid from inside to outside, the spots can be removed by using the

following methods:

¨Spots caused by scratching, common chemicals, burning and slight knocks

can all be removed by using Scotch brand cleaning pad. Slight sanding

is necessary for severer damages, and the following steps are needed:

2.1 Wash the surface with clean water to ensure it is dustless.

2.2 Use 600 # waterproof abrasive paper to sand the surface, and then

use 1200 # abrasive paper to polish the surface.

2.3 Wipe away the water with a piece of dry cloth.

CAUTION: Must keep the surface wet while sanding it.

3. Keep the surface dry.

Water contains large amounts of bleaching agents and incrustation. Therefore,

it will aect the color and appearance of the bathtub if it stays on the surface

for a long time.

• 





1149955-X2-A 10 Kohler Co.





¨



¨

 



 ¨    





 ¨  



   

       



   

4. Keep the surface away from strong chemicals.

 ¨LITHOCAST is damage-resisting, but strong chemicals are not allowed to

contact its surface. Paint-removing detergents, metal cleaning detergents,

stove cleaning detergents, methylene chloride, acetone (like nail enamel

remover) and strong acid detergents shall be avoided.

¨If the surface contacts the above-mentioned detergents, please immediately

wash it with soap water.

¨If the surface is spoed by nail enamel, please clean it with acetone free

detergents and then wash it with water.

5. Protect the surface from being knocked by overweight or sharp-ended

objects.

6. Product renovation

In case the bathtub surface is scratched or tarnished due to long time of use,

please ask professionals to polish the surface, which will restore its original

look.

User’s Guide (Continue)
