Kohler Underscore K-5716-GCR Manual de usuario

Features

•122 airjets release thousands of bubbles that surround, support,

and massage the body.

•Variable-speed blower lets you adjust massage intensity to 18

levels.

•Zones of Control™feature allows you to target airjet massage

to back, midsection, or feet.

•Chromatherapy lighting allows you to select a preferred color

scheme to suit your mood.

•Lighted keypad.

•Molded lumbar support offers extra comfort while bathing.

•Oval-shaped basin offers a graceful and spacious bathing

experience.

•Slotted overflow allows for deep soaking.

•Immediate and manual purge cycles remove residual water

from air channels after use.

•Requires K-7271 or K-7272 Clearflo slotted overflow bath drain

(sold separately). Codes/Standards

ASME A112.19.7/CSA B45.10

•Center drain.

CSA B45.5/IAPMO Z124

Material ASTM E162

•Acrylic ASTM E662

Hydrotherapy UL 1795

CSA C22.2 No. 218.2

•BubbleMassage Greenguard UL 2818 - Gold

•Chromatherapy

Installation KOHLER®Plastic Baths and Receptors

Lifetime Limited Warranty

•Drop-in or under-mount.

Additional Hydrotherapy Options KOHLER®Hydrotherapy Components

Five-Year Limited Warranty

•Soaking Bath - 5715-0

See website for detailed warranty information.

•Soaking Bath + Bask heated surface - 5715-W1

•BubbleMassage air bath - 5716-G

Available Colors/Finishes

•BubbleMassage air bath + chromatherapy - 5716-GCR

•VibrAcoustic + BubbleMassage air bath - 5716-GVB

Color tiles intended for reference only.

•VibrAcoustic + BubbleMassage air bath + Bask heated surface

+ chromatherapy - 5716-GVBCW DescriptionCodeColor

•BubbleMassage air bath + Bask heated surface - 5716-GW White0

•Whirlpool + heater - 5716-H2 Biscuit96

•VibrAcoustic - 5716-VB

Almond47

•VibrAcoustic + chromatherapy - 5716-VBC

DuneNY

•VibrAcoustic + chromatherapy + Bask heated surface -

5716-VBCW Ice™Grey95

•VibrAcoustic + Bask heated surface - 5716-VBW SandbarG9

•Whirlpool + BubbleMassage air bath - 5716-XH2G Mexican Sand™33

Required Products/Accessories

K-7271 Brass Slotted Overflow Bath Drain

CashmereK4

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

5-25-2019 09:00 - US

Underscore®Oval

5.5' BubbleMassage™Bath

K-5716-GCR

Lumbar

Notes

Required Electrical Service Measure your actual product for rough-in details.

One dedicated circuit required, protected with Class A

Ground-Fault Circuit-Interrupter (GFCI). Outside North America,

this device may be known as a Residual Current Device (RCD).

Install this product according to the installation

instructions.

The hot water supply should be 70% of the

capacity of the bath or greater. Installations will

vary.

240 V, 15 A, 50/60 HzBlower:

Technical Information

All product dimensions are nominal. If installing a rim-mount faucet, make sure there

is no interference above or below the deck before

drilling any holes.

Drop-in, Under-mountInstallation:

CenterDrain location:

47" x 26-1/4" (1193 mm x 666 mm)Basin area, bottom:

61-3/16" x 28-3/8" (1554 mm x 721 mm)Basin area, top:

120 lbs (54.4 kg)Weight:

53.6 lbs/ft²(261.7 kg/m²)Minimum floor load:

17-9/16" (446 mm)Water depth:

85.5 gal (323.7 L)Water capacity:

Drop-in, 1268439-7, required, includedTemplate:

Blower: 240 V, 5 A, 50/60 HzElectrical component

rating:

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

5-25-2019 09:00 - US

Underscore®Oval

5.5' BubbleMassage™Bath

K-5716-GCR
