Keychron K5 Manual de usuario

K5 Bluetooth Mechanical

Keyboard

User Manual • Uživatelský manuál •

Užívateľský manuál • Használati utasítás •

Benutzerhandbuch

English

3 –15

Čeština

16 –28

Slovenčina

29 –41

Magyar

42 –55

Deutsch

56 –69

Dear customer,

Thank you for purchasing our product. Please read the following instructions carefully

before first use and keep this user manual for future reference. Pay particular attention

to the safety instructions. If you have any questions or comments about the device,

please contact the customer line.

✉www.alza.co.uk/kontakt

✆+44 (0)203 514 4411

Importer

Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Prague 7, www.alza.cz

In The Box:

•Keychron K5 Bluetooth Mechanical Keyboard x 1

•Type-C Cable * 1

•Manual * 1

•Quick Start Guide * 1

•Extra Keycaps Set * 1

Mac / Windows

1. Connect Bluetooth

Press fn + 1 (for 4 seconds) and pair with device named Keychron K5

Switch toggle to Bluetooth

2. Connect Cable

3. Change Light Effect

Press light effect key

Switch toggle to Bluetooth

For RGB version –Press fn + right arrow / left arrow to change color

4. Switch between function and multimedia keys (F1-

F12)

For Windows: Press fn + X + L (For 4 seconds) to switch

Multimedia keys

Function keys

For Mac: Go to system settings > Keyboard > and enable the function keys.

*For F5 & F6 as function keys press fn + K + C (for 4 seconds) and use same shortcut to

switch.

Settings

Keyboard

Enable the function keys

5. Disable Auto Sleep Mode

The keyboard goes to Auto Sleep Mode in 10 minutes of sitting idle to save battery.

Press fn + S + O (for 4 seconds) to disable the Auto Sleep Mode.

(If you want to go back to the Auto Sleep mode, press fn + S + O for 4 seconds again)

6. Activate Siti / Cortana

For Siri on Mac: Go to System preferences > Siri > select “Press Fn (Function) Space”

option.

*Siri key only works on MacOS and does not work in iOS.

Siri

Settings

Press Fn (Function) Space

For Cortana on Windows: Select Start > Settings > Cortana and select the shortcut by

pressing Windows key + C key.

*Windows Cortana is only available for Windows 10 and above OS. Cortana is only

available in certain countries / regions and might and not work everywhere.

K5 Bluetooth Mechanical Keyboard Specifications

Number of keys

104 key

Switch type

Mechanical

Battery

2000mAh

Working time

Around 35 hours with the backlight on.

Charging time

Around 3 hours

Charging port

USB Type-C

Mode

Bluetooth/Wired

Bluetooth operating distance

Within 10 meters (open space)

Name of Bluetooth device

Keychron K5

Operating Environment

-10 to 50°C

Technical specifications can be subjected to change without notice we apologize for any

inconvenience caused.

K5 Bluetooth Mechanical Keyboard 104 key overview

1. Caps Lock Indicator

2. Battery Indicator

3. Type-C Port

4. Bluetooth OFF Cable (Mode Toggle Switch)

5. Win/Android Mac/iOS (OS Toggle Switch)

LED Status Overview

LED Location

Function

Status

Battery indicator

Charging

Low battery –Blinking Red

Charging –Static Red

Fully charged –Static

Green

Bluetooth indicator

Bluetooth

Pairing –Fast Blinking

Paired –Light Off

Switching –Slow Blinking

Function Description:

Charging

Plug the cable into a USB port and plug the other end into the keyboard port. Charging

indicator: When battery is below 15%, a red battery blinking indicator will be triggered. A

red light will stay on while charging; Fully charged in around 3 hours, a green battery

indicator will appear.

*The Keychron keyboard is compatible with all USB ports. Please use a 5V 1A adapter or

USB 3.0 for the best performance. The Keychron K5 can be charged in Bluetooth/on/off

mode.

**This product supports up to 5V charging voltage and 1A charging current. We are not

responsible for any problems caused by improper charging.

Bluetooth/Wired Mode (Toggle Switch)

Wired Mode

1. Switch the toggle switch to Cable option (it only works when USB cable is plugged

in).

2. Connect our cable with your PC and keyboard.

3. Backlit will be turned on.

*Under Wired Mode, keyboard will not enter into Battery Saver Mode.

Bluetooth Mode

1. Switch the keyboard to Bluetooth option.

2. Backlit will be turned on.

3. Hold “Fn+1” key for 4 seconds to activate Bluetooth pairing (the Bluetooth

indicator fast flashes for 3 minutes to detect pairing.)

4. Search for the Bluetooth device “Keychron K5” on your device and connect it (the

Bluetooth indicator goes off after successful pairing.)

Note: This keyboard supports pairing up to 3 devices simultaneously via combination

key “fn” + “1” / “fn” + “2” / “fn” + “3”.

*The Bluetooth indicator will continue to flash for 3 minutes.

** Slow or failed connections may exist due to different Bluetooth versions, please make

sure all the settings are correct.
