Keychron K1 Max Manual de usuario

K1 Max Wireless Mechanical Keyboard

Keychron K1 Max Wireless Mechanical Keyboard x 1

Type-C Cable x 1

Manual x 1

Quick Start Guide x 1

Extra Keycaps Set x 1

Type-A to Type-C Adapter x 1

Type-A 2.4GHz Receiver x 1

QUICK START GUIDE

If you are a Windows user, please find the appropriate keycaps in the box, then follow theinstructions

below to find and replace the followingkeycaps.

Mac / Windows

Connect 2.4GHz Receiver

Press fn + 1 (for 4 seconds) and pair with

device named Keychron K1 Max.

Connect Bluetooth

G / Cable / BT

G = 2.4GHz

G / Cable / BT

Switch toggle to 2.4GHz mode

Connect the 2.4GHz receiver to

the device USB port.

Note: For the best wireless experience, we recommend using the

extension adapter for receiver and putting the 2.4GHz receiver

somewhere on your desk close to your keyboard for a low rate

of latency and fewer signal interferences.

Type-C

Cable Extension Adapter

For Receiver

2.4GHz

Receiver

fn + 1

Connect Cable

Please make sure the system toggle on

the top left corner has been switched

to the same system as your computer's

operating system.

G / Cable / BT

Switch To The Right System

Mac Win

The Layers

There are four layers of key settings on the

keyboard. The layer 0 and layer 1 are for the

Mac system. The layer 2 and layer 3 are for

the Windows system.

If your system toggle is switched

to Mac, then the layer 0 will be

activated.

If your system toggle is switched to Windows, then

the layer 2 will be activated. Remember that if you

are using it in Windows mode, please make changes

to the layer 2 instead of the top layer (the layer 0).

This is a common mistake people are making.

The VIA Key Remapping Software

Please visit usevia.app to use the online

VIA software to remap the keys.

If the VIA cannot recognize your keyboard,

please reach our support to get the instruction.

Your keyboard’s best friend

*The online VIA software can only run on the latest version of Chrome, Edge, and Opera browsers yet.

*VIA only works when the keyboard is connected by wire to the computer.

Adjust The Backlight Brightness

Press fn + W to increase the backlight brightness Press fn + S to decrease the backlight brightness

7The Backlight

Press fn + Q to change the lighting effect Press fn + tab to turn the backlight on/off

fn + Q

fn + W

fn + S

fn + tab

The keyboard is highly customizable and easy to be rebuilt.

If anything goes wrong with any of the keyboard components

of keyboard during the warranty period, we will only replace

the defective parts of the keyboard, not the whole keyboard.

Warranty

Press fn + T to increase the light effect speed Press fn + G to decrease the light effect speed

Adjust The Backlight Speed

fn + T

fn + G

Factory Reset

1. Download the right firmware and QMK Toolbox from our website.

2. Unplug the power cable and switch the keyboard to Cable mode.

3. Remove the space bar keycap to find the reset button on the PCB.

4. Hold the reset key first, then plug the power cable into the keyboard.

Release the reset key after 2 seconds, and the keyboard will now enter

DFU mode.

5. Flash the firmware with the QMK Toolbox.

6. Factory reset the keyboard by pressing fn + J + Z (for 4 seconds).

Troubleshooting? Don’t know what’s going on with the keyboard?

*Step by step guide can be found on our website.

K1 MAX WIRELESS MECHANICAL KEYBOARD SPECIFICATIONS

Number of keys: 87

Switch type: Mechanical

Baery: 2000mAh

Charging me: Around 3 hours

Charging port: USB Type-C

Mode: Bluetooth / Wired / 2.4GHz

Bluetooth operang distance: Within 10 meters (open space)

Name of Bluetooth device: Keychron K1 Max

Low Power - Red Light Blinking

Charging - Stac Red

Full charged - Stac Green

Switching - Fast Blinking

Paired - Light Oﬀ

Pairing - Slow Blinking

Funcon LED Locaon

Charging Baery Indicator

Bluetooth Bluetooth Indicator

Reconnecng-Fast Blinking

Paired - Light Oﬀ

Paring - Slow Blinking

2.4G 2.4G Indicator

Status
