IOGear GUWIP204 Manual de usuario

GUWIP204

Part No. M1172-a

Installation

Installation Guide

Wireless 4-Port USB Sharing Station

IOGEAR, the IOGEAR logo, MiniView, VSE are trademarks or registered trademarks of IOGEAR. Microsoft and Windows

are registered trademarks of Microsoft Corporation. IBM is a registered trademark of International Business Machines, Inc.

Macintosh, G3/G4 and iMac are registered trademarks of Apple Computer, Inc. IOGEAR makes no warranty of any kind with

regards to the information presented in this document. All information furnished here is for informational purposes only and

is subject to change without notice. IOGEAR assumes no responsibility for any inaccuracies or errors that may appear in this

document.

Table of Contents

Package Contents 4

System Requirements 5

Product Overview 6

Hardware Installation 7

Windows Software Installation 10

Mac Software Installation 11

Conguration 14

General Settings 17

WirelessConguration-WEP 18

WirelessConguration-WPA/WPA2 20

AdministratorConguration 21

Maintenance 23

ConnecttoanattachedUSBdevice 24

RequesttoConnect 25

DisconnectingaUSBdevice 27

Auto-ConnectPrinter 28

Network Scanner 31

Firmware Upgrade 35

Troubleshooting 38

Limited Warranty 46

Federal Communications Commission (FCC)

Statement 47

CE Statement 48

Contact 49

Package Contents

1xWireless4-portUSBSharingStation

1 x Installation Manual

1 x Installation CD

1 x Warranty / Registration card

1 x Power Adapter

System Requirements

Computer:

CPU of 1.7GHz and above•

Minimum512MBRAM•

Windows XP/Vista /7•

Mac OSX 10.6 and up•

Availablewirelessrouterinhome/ofcenetwork•

Supported Devices:

PrinterorMulti-functionprinterwithUSBconnection*•

External USB hard drive•

USBwebcam*•

USBashdrive•

USB memory card reader•

USB printer•

USB scanner•

*SomeUSBdevicesrequireadirectconnectiontothecomputerforoptimumperformance

USB connection LED1.

USB port located on the front2.

On/Off Switch3.

Power adapter connector4.

Product Overview

127

3 4 5

Reset button5.

Network port6.

USB ports located on the back7.

Antenna8.

NOTE: Before you connect your USB device to the GUWIP204, please refer to the user manual

and install the driver on your computer rst, for example the driver for your printer. When the

installation is completed, safely disconnect your USB devices from your computer. Disconnect

the power source from USB devices.

Connect your USB device to any one of the USB ports on the USB Sharing Station1.

Hardware Installation

USB device (not included)

ConnecttheGUWIP204totherouterorswitchwiththeincludedEthernetcable.2.

router (not included)

ConnectthepoweradaptertotheGUWIP204andturnitonusingtheon/offswitch.TheUSBconnectionLEDwill3.

turn on indicating that unit is correctly connected to the network. Turn on your USB device.

Windows Software Installation

Please insert the driver CD into your

Windows based PC. The CD should auto

play and bring up the software installer.

Ifyouhavedisabledtheauto-play

function, please browse the CD and

install the driver program manually.

Follow the instructions of the wizard to

complete the installation process. Once

the installation is complete, click “Finish”

to launch the application.
