IOGear M1672 Manual de usuario

www.iogear.com

User Manual

4Kx2K 4-Port HD Switch

GWKIT4K

PART NO. M1672

registered trademarks of Aten Technology, Inc. HDMI and related logo are trademarks or

registered trademarks of HDMI Licensing Administrator, Inc. (or afﬁliate) in the United States

and other countries. Windows is either a registered trademark or trademark of Microsoft

Corporation in the United States and/or other countries. MacOS is a trademark of Apple Inc.,

registered in the U.S. and other countries. Android is a trademark of Google LLC. All other

trademarks, names, logos and brands are the properties of their respective owners. Reproduc-

tion in whole or in part without permission is prohibited. Tested to comply with FCC and CE

Standards. FOR HOME OR OFFICE USE. Speciﬁcations subject to change without notice.

Table of Contents

Introduction 4

Features 4

Package Contents 5

Requirements 6

Overview 7

Installation 8

Overview 9

Hardware Installation 9

Operation 13

Advanced Operation 19

Trouble Shooting 20

Compliance Information 21

Limited Warranty 22

Contact 22

Introduction

Features

IOGEAR’s Wireless HD TV Connection Kit allows you to enjoy

contents from your PC or any HDMI source (Media server, DVD,

Satellite box or Bluray player) to your TV at up to 4K@ 30 Hz

resolution with great image clarity and sound.

*Some Bluray player may need to be manually congured to

play at 24 Hz when playing a UHD disc.

• Wirelessly send your favorite apps, games, videos, photos,

music and Internet content from your Tablet, Laptop Bluray

or any source with HDMI output to your HDTV, HD Projector

or HD Display.

• Creates its own dedicated wireless connection for better

performance.

• Send video and audio wirelessly up to 100ft (30 m) – Line

of sight.

• Full HD 2160p video resolution playback support.

• Capable of screen sharing from your mobile device.

• Supports WPA encryptions for secure data transmission.

• Ideal solution for sharing PC content wirelessly at Home, at

the O󰀩ce and in a Classroom.

Package Contents

1 x Transmitter

1 x Receiver

1 x Transmitter Antenna

2 x HDMI Cables

1 x Power Adapter

1 x USB Power Cable

1 x Quick Start Guide

1 x Warranty Card

Requirements

There are 2 ways that the GWKIT4K can be used:

1. As a one-to-one kit using both the transmitter and the

receiver.

2. As a screen sharing device where you will be using just

the receiver and your source will be your computer or

your phone to stream your content to a TV screen or

projector.

GWKIT4K as a one-to-one kit (using both the transmitter

and receiver):

Source

Any source with HDMI output

Display

• HDTV or Projector with HDMI input port

Using the GWKIT4K as a screen sharing kit (using just the

receiver):

Source

• Windows 10 or later.

• Mac OS 10.14 and later with computer using

Metal support graphics adapter.

• iPad IOS 10 and later.

• iPhone IOS 10 and later.

• Android Smart phones version 10 (Quince Tart)

and later.

• Google Chromebook

Display

• HDTV or Projector with HDMI port.

Overview

Wireless UHD TV Connection Kit:

Transmitter and receiver kit enabling video to be mirrored or

extended to a larger display. The kit is completely plug-n-play

and need no software to be installed.

OverviewInstallation

Overview

Hardware Installation

Part 1: Plug-n-Play installation

This part is for simple mirroring the contents from your device

(Blu-ray player, Set top box, media player, computer with HDMI

output) to a display screen.

1. Connect the antenna into the transmitter of the GWKIT4K.

2. Connect the HDMI cable from the transmitter to the HDMI

output connection of your source.

3. Connect the USB-A to Micro USB cable from the transmitter

to the USB-A port of your source.

4. Power on your display and the GWKIT4K receiver making

sure the On/O󰀨 switch in the back of the unit is turned

on (push button switch is depressed), you will see a

IOGEARCast splash screen.

5. Power on the GWKIT4K transmitter using the included

USB-A to Micro USB cable, connecting the USB-A to your

power source (USB-A port on your laptop) and the Micro

USB to the power port on the transmitter, if you don’t have

USB-A port on your computer you will need to use a 5V/1A

power adapter with Micro USB connector (not supplied).

Once the wireless connection is established the splash

screen should change to mirror your source content*.
