99903278: IM-9/63: PAGE 4:
DANGER
Maintain safe clearance from electrical lines.
Allow for boom,electrical line, and loadline swaying.
This crane does not provide protection from contact
with or proximity to an electrically charged conductor.
Maintain a clearance of at least 10 feet between
any part of the crane, loadline or load and any electrical
line carrying up to 50,000 volts (50 kV). If electrical
line voltage is unknown, assume maximum voltage
and maintain a clearance of at least 45 feet.
NOMINAL VOLTAGE, kV MINIMUM REQUIRED
(Phase to Phase) DISTANCE
to 50_____________10 feet
Over 50 to 200_____________15 feet
Over 200 to 350_____________20 feet
Over 350 to 500_____________25 feet
Over 500 to 750_____________35 feet
Over 750 to 1000_____________45 feet
ELECTROCUTION HAZARD
THIS CRANE IS NOT INSULATED
WILL RESULT FROM CONTACT
OR INADEQUATE CLEARANCE
DEATH OR SERIOUS INJURY
20010507
FIGURE 2:
DECAL DANGER,
ELECTROCUTION
General Rules for Powerlines or Power Supply Stations
When working in proximity to power supply stations or overhead wires, follow these general rules:
1. Be careful in planning, instructing, and executing work to prevent any risk or danger to persons, equipment or
goods.
2. onsider any power supply plant, installation or wire live until proven otherwise.
3. Follow any and all directions or guidelines from the responsible power supply authorities .
Any person or company directly responsible for the implementation of work in the proximity of overhead wires or
electric power stations must make sure that all personnel involved in the execution of such work is familiar with any
laws, rules or safety regulations.
3.0 Loader Operation
3.1 Start-up Preparation
I. Switch the hydraulic change-over valve to the loader position.
II. Engage the PTO at low revolutions. The engine revolution speed is regulated
via the hand accelerator to ensure that the oil flow from the hydraulic pump
corresponds to the recommended pump flow for the loader. If starting the loader
in cold weather, the oil should circulate for a few minutes before operation
starts.
III. Apply the vehicle parking brake.
IV. R L System - Prior to setting the outriggers or starting loader operations,
the R L (rated-capacity limitation) system must be activated. To activate the
R L system, pull out the emergency stop button(s). Push the green button
once. The RUN diode on the R L system control panel (Figure 3) is lit and
the R L safety system is activated.
FIGURE 3: RCL 5100 CONTROL
PANEL
