HyperX cloud ii Manual de usuario
User Manual
HyperX Cloud II Wireless
Find the language and latest documentation for your HyperX Cloud II Wireless here.
HyperX Cloud II Wireless Installation Guide
Simplied Chinese .....简体中文说明书
............For instructions in English
. . . . . . . . . . . . . . . . . . Para instrucciones en Español
.........Für Anleitungen in Deutsch
. . . . . . . . . . . . . . . . . . Pour des instructions en Français
. . . . . . . . . . . . . . . . . . Per le istruzioni in Italiano
............Por as instruções em Português
. . . . . . . . . . . . . . . . . . Instrukcje w jezyku Polskim
. . . . . . . . . . . . . . . . . . Для инструкции на Pусском
. . . . . . . . . . . . . . . . . . Turkce talimatlar icin
. . . . . . . . . . . . . . . . . .日本語マニュアル用
. . . . . . . . . . . . . . . . . .한국어 안내
. . . . . . . . . . . . . . . . . . คำ�แนะนำ�ภ�ษ�ไทย
. . . . . . . . . . . . . . . . . . Để xem hướng dẫn bằng tiếng Việt
Traditional Chinese ....繁體中文說明
ﻰﺑرﻋ. . . . . . . . . . . . .ﺔﯾﺑرﻌﻟا ﺔﻐﻠﻟﺎﺑ تﺎﻣﯾﻠﻌﺗﻟا ﻰﻠﻋ لوﺻﺣﻠﻟ
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 1 of 13
HyperX Cloud II Wireless
Part Numbers
HHSC2X-BA-RD/G
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 2 of 13
TABLE OF CONTENTS
Overview .................................................................................................................................... 3!
Specifications............................................................................................................................ 4!
Setting up with PC .................................................................................................................... 5!
Setting up with PlayStation 4 ................................................................................................... 9!
Controls ................................................................................................................................... 10!
Mic mute / mic monitoring button ........................................................................................................................ 10!
Power button / 7.1 Surround Sound button ........................................................................................................ 10!
Volume wheel ........................................................................................................................................................ 11!
Status LED ............................................................................................................................................................. 10!
Charging the Headset ............................................................................................................. 12!
Wired charging ...................................................................................................................................................... 12!
HyperX NGENUITY Software .................................................................................................. 12!
Manually Pairing the Headset and USB Adapter ................................................................. 13!
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 3 of 13
Overview
A. Mic mute / mic monitoring button
B. USB charge port
C. Microphone port
D. Status LED
E. Power / 7.1 Surround Sound button
F. Volume wheel
G. Detachable microphone
H. Microphone mute LED
I. USB adapter
J. Wireless pairing pin hole
K. Wireless status LED
L. USB charge cable
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 4 of 13
Specifications
Headphone
Driver: Dynamic, 53mm with neodymium magnets
Type: Circumaural, Closed back
Frequency response: 15Hz–20kHz
Impedance: 60 Ω
Sound pressure level: 104dBSPL/mW at 1kHz
T.H.D.: ≤ 1%
Weight: 300g
Weight with mic: 309g
Cable length and type: USB charge cable (0.5m)
Microphone
Element: Electret condenser microphone
Polar pattern: Bi-directional, Noise-cancelling
Frequency response: 50Hz-6.8kHz
Sensitivity: -20dBV (1V/Pa at 1kHz)
Battery life*
30 hours
Wireless Range**
2.4 GHz
Up to 20 meters
*Tested at 50% headphone volume. Battery life varies depending upon the usage.
**Wireless range may vary due to environmental conditions.
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 5 of 13
Setting up with PC
1. Connect the wireless USB adapter to the PC.
2. Power on the headset.
3. Right click speaker icon > Select Open Sound settings > Select Sound Control Panel
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 6 of 13
4. Under the Playback tab, click on “HyperX Cloud II Wireless” and click on the Set Default
button.
5. Right click on “HyperX Cloud II Wireless” and click on Configure Speakers.
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 7 of 13
6. Select 7.1 Surround as the speaker configuration and click next.
7. Under the Recording tab, click on “HyperX Cloud II Wireless” and click on the Set Default
button.
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 8 of 13
8. Under the Playback tab, verify that “HyperX Cloud II Wireless” is set as Default Device and
Default Communication Device. Under the Recording tab, verify that “HyperX Cloud II
Wireless” is set as Default Device.
Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 9 of 13
Setting up with PlayStation 4
1. Set Input Device to USB Headset (HyperX Cloud II Wireless)
2. Set Output Device to USB Headset (HyperX Cloud II Wireless)
3. Set Output to Headphones to All Audio
4. Set Volume Control (Headphones) to maximum.
