HyperX Cloud II Headset

Find the language and latest documentation for your HyperX Cloud II Headset here.

HyperX Cloud II Installation Guide

Simplied Chinese . . . . .

Traditional Chinese . . . .

. . . . . . . . . . . . For instructions in English

. . . . . . . . . . . . . . . . . . Para instrucciones en español

. . . . . . . . . Für Anleitungen in Deutsch

. . . . . . . . . . . . . . . . . . Pour des instructions en français

. . . . . . . . . . . . . . . . . . Per le istruzioni in italiano

. . . . . . . . . . . . Por as instruções em português

. . . . . . . . . . . . . . . . . . Instrukcje w jezyku polskim

. . . . . . . . . . . . . . . . . . Для инструкции на русском

. . . . . . . . . . . . . . . . . . Turkce talimatlar icin

. . . . . . . . . . . . . . . . . . Japanese

. . . . . . . . . . . . . . . . . . Thai

. . . . . . . . . . . . . . . . . . Vietnamese

. . . . . . . . . . . . . . . . . . Українська

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 1 of 11

HyperX Cloud II Headset

Part Numbers:

KHX-HSCP-GM (Gun Metal)

KHX-HSCP-PK (Pink)

KHX-HSCP-RD (Red)

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 2 of 11

Introduction

Optimized for pro-gaming, HyperX Cloud II Headset (KHX-HSCP-xx) is a high-quality communicating device that

delivers superior sound, style and comfort. It uses an adjustable, soft-padded leatherette headband and features

a closed-cup design for enhanced bass reproduction and minimal sound leakage. The HyperX Cloud II headset is

HiFi capable and delivers a durable design for the most rugged gaming environments and is compatible with

tablets and smartphones for mobile use.

What’s Included:

•1 HyperX Cloud II Headset

•1 Detachable Microphone

(attached to headset)

•1 spare set of velour ear cushions

•1 USB control box

•1 Mesh bag

" "

Package Contents

Features:

•Hi-fi capable 53mm drivers for supreme audio quality

•15-25 KHz frequency response (earphones)

•Detachable microphone (quick and easy to plug/unplug for music-only purposes)

•Solid aluminum construction for durability and stability

•Super-soft padded leatherette headband and leatherette padding on cups

•Closed cup design for enhanced bass-reproduction and sound leakage

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 3 of 11

Technical Specifications:

Headset

•Transducer type: Dynamic 53mm with Neodynium Magnets

•Operating principle: Closed

•Frequency response: 15Hz-25KHz (earphones)

•Nominal impedance: 60 ohm per system

•Nominal SPL: 98+/-3dB

•T.H.D: < 2%

•Power handling capacity: 150mW

•Sound coupling to the ear: Circumaural

•Ambient noise attenuation: approx.20 dBA

•Headband pressure: 5 N

•Weight with microphone and cable: 320g

•Cable length and type: 1m + 2m extension

•Connection: Mini stereo jack plug (3.5MM)

Microphone

•Microphone Transducer type: Condenser (back electret)

•Operating principle: Pressure gradient

•Polar Pattern: Cardioid

•Power supply: AB powering

•Supply voltage: 2V

•Current consumption: Max 0.5 mA

•Nominal impedance: ≤2.2 k ohm +/- 30%

•Open circuit voltage at f = 1 kHz 20 mV / Pa

•Frequency response: 50 - 18,000 Hz (microphone)

•T.H.D: 2% at f = 1 kHz

•Max. SPL: 105dB SPL (THD ≤1.0% at 1KHz)

•Microphone output: -39+/-3dB

•Dimensions: 6*5mm

•Length mic boom: 150MM(include gooseneck)

•Capsule diameter: 6mm

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 4 of 11

Overview

" "

A. Leatherette headband w/ HyperX

logo

B. Aluminum arm to adjust headband

C. Attached cable w/ 3.5mm input

jack

D. Detachable microphone with

adjustable arm and condenser

E. 3.5mm audio input jack

F. Extra set of ear cushions

G. Control box cable w/ USB

connector and control box (letter H)

H. USB Control box w/ volume

controls and 7.1 audio button

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 5 of 11

Usage (Direct Connect) with No Control Box

Connect your headset directly to your computer, game console, or other device (phone or

tablet) that has a 3.5mm audio jack.

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 6 of 11

Usage (with Control Box)

Connect the headset’s 3.5mm audio jack to the input jack on the USB control box. The USB

control box then connects to a computer using the USB connector on the end of the

control box.

- -

7.1

Using Control Box

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 7 of 11

To ensure that HyperX Cloud II is the default audio device, you must follow these

instructions:

For Windows:

1. Open up Control Panel and select Hardware

and Sound and then select Sound.

2. If the “HyperX 7.1 Audio” is not currently the

default audio device, right-click on the option

and select “Set as Default Device.”

3. This should place a green check mark next to

the default audio device.

Figure 1 – Control Panel

Figure 2 – Right-Click Default Audio Figure 3 – Default Sound Device

Repeat the same steps for the microphone portion

of the headset, located under the “Recording” tab

(also found in the Sound program in Control Panel.)

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 8 of 11

To ensure that HyperX Cloud II is the default audio device, you must follow these

instructions:

For Mac:

1. Click the Apple menu and select

“System Preferences” from the

drop-down menu.

2. In “System Preferences”, click on

the ‘Sound’ icon.

3. Click on the Input tab and select

“HyperX 7.1 Audio” for default sound

input.

4. Click on the Output tab and select

“HyperX 7.1 Audio” for default sound

output.

Figure 2 – System Preferences

Figure 1 – Apple Menu

Figure 3 – Sound Preferences

Document No. 480KHX-HSCP001.A01

HyperX Cloud II Headset

Page 9 of 11

Usage (PlayStation®4)

For optimal use with PlayStation®4 (PS4®), unplug the headset jack from the USB control box

and connect audio jack on the headset directly to the PS4 game controller and follow these

steps:

1. Turn on your PS4®game console.

2. Navigate to the Settings Menu and select it.

3. Highlight the ‘Devices’ menu option and select it.

4. Scroll down to ‘Audio Devices’ and select it.

5. Choose ‘Output to Headphones’ and select ‘All Audio.’

PlayStation 4

(USB Control Box not needed)

HyperX Cloud II with PS4®
