Huawei E5783B-230 Especificaciones técnicas
Product Description
HUAWEI E5783B-230 Mobile WiFi
V100R001
Version 01
Date 2018-08-30
HUAWEI TECHNOLOGIES CO., LTD.
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 2 of 21
Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.
Please feel free to contact our local office or company headquarters.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://consumer.huawei.com/en/
Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 3 of 21
About This Document
Summary
This document introduces the major functions, supported services, and system
architecture of the HUAWEI E5783B-230 Mobile WiFi.
The following table lists the contents of this document.
Chapter Details
1 Overview Supported network modes, basic services and functions, and
the appearance of the product
2 Features Major features and technical specifications
3 Services and
Applications
Supported services
4 System
Architecture
System architecture
5 Packaging Box
Items
Items contained in the product box
6 Appendix Supported LTE bandwidths
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 4 of 21
History
Version Details Date
01 First release 2018-08-30
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 5 of 21
Contents
1 Overview..........................................................................................................................6
1.1 Introduction....................................................................................................................................... 6
1.2 Optional Features............................................................................................................................. 6
2 Features...........................................................................................................................7
2.1 Main Features .................................................................................................................................. 7
2.2 Technical Specifications ................................................................................................................... 8
2.2.1 Hardware ................................................................................................................................. 8
2.2.2 Software..................................................................................................................................11
3 Services and Applications ...........................................................................................13
3.1 Data Service................................................................................................................................... 13
3.1.1 Wireless Modem.................................................................................................................... 13
3.1.2 USB Modem .......................................................................................................................... 13
3.1.3 LTE/3G/Wi-Fi Auto Offload .................................................................................................... 14
3.2 SMS................................................................................................................................................ 14
4 System Architecture .....................................................................................................15
4.1 System Architecture ....................................................................................................................... 15
4.2 Functional Modules ........................................................................................................................ 16
5 Packaging Box Items....................................................................................................17
6 Appendix........................................................................................................................18
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 6 of 21
1 Overview
1.1 Introduction
HUAWEI E5783B-230 Mobile WiFi (hereinafter referred to as the E5783B-230) is a
high-speed packet access mobile hotspot. It is a multi-mode wireless terminal for
SOHO (Small Office and Home Office) and business professionals.
It provides users with packet data services and SMS through multiple network modes.
You can connect the micro USB port on the E5783B-230 to a computer using a micro
USB data cable, or connect multiple devices to the E5783B-230 over Wi-Fi. In the
service area of the network, the E5783B-230 allows you to surf the Internet, and
send/receive messages/emails , providing you with a fast, reliable, and convenient
user experience. It also helps carriers improve their average revenue per user
(ARPU).
Figure 1-1 shows the appearance of the E5783B-230.
Figure 1-1 E5783B-230 appearance
1.2 Optional Features
Optional features refer to features that are not supported on the standard version.
These features can be customized according to carrier or customer requirements. The
E5783B-230's optional features include the following:
SIM lock
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 7 of 21
2 Features
2.1 Main Features
The E5783B-230 features:
LTE FDD Cat4 (DL) packet data service of up to 150 Mbps
LTE FDD Cat6 (DL) packet data service of up to 300 Mbps
LTE FDD Cat4 (UL) packet data service of up to 50 Mbps
LTE FDD Cat6 (UL) packet data service of up to 100 Mbps
LTE TDD Cat4 (DL) packet data service of up to 112 Mbps
LTE TDD Cat6 (DL) packet data service of up to 224 Mbps
LTE TDD (UL) packet data service of up to 10 Mbps
DC-HSPA+ (DL) packet data service of up to 42 Mbps
DC-HSPA+ (UL) packet data service of up to 5.76 Mbps
HSPA+ (DL) packet data service of up to 21 Mbps
HSPA+ (UL) packet data service of up to 5.76 Mbps
HSDPA (DL) packet data service of up to 14.4 Mbps
UMTS (UL/DL) packet data service of up to 384 Kbps
SMS based on LTE/UMTS
Built-in LTE/UMTS and Wi-Fi antenna
2.4 GHz and 5 GHz Wi-Fi
LTE/3G/Wi-Fi auto offload
Compatible with HUAWEI SmartHome app
Plug and Play
IPv4v6 dual stack
Built-in DHCP Server, DNS RELAY, and NAT
Online software upgrade
Traffic statistics
WPS
Standard Micro USB port
Compatible with Windows 7, Windows 8, Windows 8.1, Windows 10 (excluding
Windows RT), MAC OS X 10.9, 10.10, 10.11 and 10.12 with latest upgrades
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 8 of 21
2.2 Technical Specifications
2.2.1 Hardware
Table 2-1 lists the hardware specifications.
Table 2-1 Hardware specifications
Item Specifications
Technical
standard
WAN: LTE FDD/LTE TDD/DC-HSPA+/HSPA+/HSPA/UMTS
Wi-Fi/WLAN: IEEE 802.11a/b/g/n/ac
Operating
frequency
LTE FDD: B1/B3/B7/B8/B20/B28/B32
LTE TDD: B38/B40(2300~2395MHz)
LTE CA：
UL CA：Intra-Band continuous：B3+B3,B7+B7
DL CA:
Intra-Band continuous：
B1+B1, B3+B3, B7+B7, B38+B38, B40+B40
Intra-Band non-continuous：B3+B3, B7+B7
Intra-Band：
B1+B8(B1 as PCC), B1+B20, B1+B28(B1 as PCC), B3+B7, B3+
B8, B3+B20, B3+B28(B3 as PCC), B7+B8, B7+B20, B7+B28(B7
as PCC), B20+B32(B20 as PCC), B20+B38(B20 as PCC), B1+B
3
See the Appendix for the supported LTE channel bandwidths.
DC-HSPA+/HSPA+/HSPA/UMTS:
Band1(2100MHz)/Band8(900MHz)
Wi-Fi/WLAN: 2.4 GHz
Wi-Fi/WLAN: 5 GHz
Memory RAM: 256 MB DDR
ROM: 256 MB NAND Flash
Transmit power
LTE: Conforms to Power Class 3 Definition
WCDMA/HSPA/HSPA+: Conforms to Power Class 3 Definition
Wi-Fi/WLAN
2.4 GHz
802.11b: 12.5 dBm
802.11g: 12 dBm
802.11n: 11(20MHz)/11(40MHz) dBm
Wi-Fi/WLAN
5 GHz
802.11a: 11 dBm
802.11ac: 10(20MHz)/9(40MHz)/9(80MHz) dBm
802.11n: 10 dBm
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 9 of 21
Item Specifications
Note: The value above represents a typical transmit power in
Wi-Fi/WLAN mode, and may vary slightly by device.
Receiver
sensitivity
LTE: Conforms to 3GPP
WCDMA/HSPA/HSPA+: Conforms to 3GPP
Wi-Fi/WLAN
2.4 GHz
802.11b: -76dBm@11Mbps/-82dBm@1Mbps
802.11g: -65dBm@54Mbps
802.11n: -64dBm@65Mbps
Wi-Fi/WLAN
5 GHz
802.11a: -65dBm@54Mbps
802.11ac: -64dBm@65Mbps
802.11n: -64dBm@65Mbps
Wi-Fi/WLAN
speed
802.11a: Up to 54Mbps
802.11b: Up to 11 Mbps
802.11g: Up to 54 Mbps
802.11n HT20: Supports MCS0–MCS7; Up to 72.2 Mbps.
Supports MCS8–MCS15; Up to 144.4
Mbps.
HT40: Supports MCS0–MCS7; Up to 150 Mbps.
Supports MCS8–MCS15; Up to 300 Mbps.
802.11ac: Up to 867 Mbps
Power
consumption
3.5 W
Charger
(Optional)
AC: 100–240 V
DC: 5 V, 1 A
Battery Type: Rechargeable lithium battery (Removable)
Capacity: 3.8 V, 1500 mAh
Maximum working hours: 6 (depending on the network)
Maximum standby hours: 350 (depending on the network)
External ports Micro USB port
micro-SIM card slot (3FF)
Indicators LED signal, battery, and SMS indicators
Buttons Power button, RESET button
HUAWEI E5783B-230 Mobile WiFi V100R001
Product Description
Version 01 ( 2018-08-30) Secret and confidential Page 10 of 21
Item Specifications
Antenna Built-in LTE/UMTS main antenna
Built-in LTE/UMTS diversity antenna
Built-in Wi-Fi/WLAN antenna
Dimensions
(W × D × H)
Mobile WiFi 108mm x 62mm x 16mm
With package 151mm x 94 mm x 66 mm
Weight Mobile WiFi Approximately 87 g (including the battery)
With package Approximately 151g
Temperature Operating temperature: 0℃to 35℃
Storage temperature: -20℃to +70℃
Humidity 5% to 95% (non-condensing)
