MOBILE INTERNET – HUAWEI E220 3G USB MODEM

With this modem you can easily:

•Access the internet

•Send or receive text messages

•Manage contacts

The E220 package box contains the following items:

•One E220 HSDPA USB Modem (including a PDF User Manual and a setup program)

•TwoUSBcables(youonlyneedtousethedouble-endedcableifasingleoneofyourUSBports

does not supply enough power)

•A Quickstart guide

To use the modem your PC is required to have:

•CPU: Pentium 4, 1 Ghz or above

•Memory: 128 MB RAM or above

•Hard disk: 50MB or above

•Operating system: Windows XP, Windows 2000 or Windows Vista

•USB modem interface: USB 2.0 full speed

•Display resolution: 800x600 or above, 1024x768 is recommended

Note: Make sure that the configuration of your PC meets the requirements. Otherwise, improper

configuration may degrade the performance of your PC.

Indicator status:

Indicator status (LED light)

Description

Off

Modem is powered off

Blinking green twice every 2.7 seconds

Modem is searching for a network or no network

is available

Blinking green once every 2.9 seconds

GPRS network is normal

Blinking blue once every 2.9 seconds

3G network is normal

On (green)

GPRS data service is established

On (cyan/blue)

3G data service is established

Getting started

TopreparethemodemforusetakeouttheSIMcardslotfromthe side of the modem. Then insert the

SIM card into the slot. Make sure that the SIM card if fully inserted and then insert the slot back into the

modem.

The installation procedures may vary slightly with the operating system. The following uses the Windows

XP operating system as an example.

Note: Before connecting E220 to the PC, power on the PC. Otherwise, the installation may be affected.

UsetheUSBcabletoconnectthemodemtothePCbypluggingoneendintotheUSBinterface of the modem

and the other end into the USB port of your PC or laptop.

Eitherofthecablesprovidedcanbeusedasthedoubleendedcableonlyprovidesandauxiliaryplugtoprovide

more USB power to your modem.

WindowsXPautodetectsandrecognizesthemodemanddisplaysthe icon on the lower right corner

indicating that the modem is connected successfully.

The setup program auto runs. Then the modem installation interface appears:

Note: If the auto-runprogramdoesnotstart,gotoMyComputer,openthemodemiconanddouble-click the

AutoRun.exe file in the drive to run it.

Once you have chosen your language, follow the instructions on the screens below:

Once you have completed the installation, the shortcut icon forMobileConnectwillappearonyour

desk top.

IfyouwishtodisconnectthemodemexittheMobileConnectprogram,thenstopitthroughthehardware

removing function of windows.

If you wish to uninstall the modem use the Add or Remove Programs function in the Windows Control Panel.

TolaunchMobileConnectconnectthemodemtothecomputerforautolaunchordoubleclickontheMobile

Connect icon. If you are required to enter the PIN code, enter the correct one and click

OK. Ifyou enter the wrong PIN code three times consecutively, your SIM card will be blocked. In this case use the

PUKcodetounblockit.IfyouenterthewrongPUKcodetentimesconsecutively,yourSIMcard will be disabled

and you will need to contact your service provider.

After Mobile Connect is launched, the home screen is displayed as follows:

Once this is open you need to create a Gibtelecom profile.

To do this select Settings>Network Connection Settings, click New and enter the following information

Then click Save.

Also click Settings>Choose Connection Type and select 3G preferred

YoucanaccesstheInternetthrougha3GorGPRSconnection.OnceyouhavecheckedthatunderNetwork

Connection Settings the Gibtelecom profile is selected then click to establish the connection. After a

prompt is displayed indicating that the connection is established, click orlaunchthebrowserofthe

operating system to access the internet. Click Disconnect to close the connection.

For information on the rest of the modem functions see the User Manual.

If you would like more information or have any questions on Gibtelecom’s Mobile Internet bundles or data

usage rates please contact Customer Services on 20052200.
