Huawei EC150 Manual de usuario

HUAWEI EC150 CDMA

1X EVDO Rev.A

USB Stick

Quick Start

Thank you for choosing the Mobile Broadband

USB Stick. With your USB Stick, you can access

a wireless network at high speed.

Note:

This manual describes the appearance of the USB Stick, as well as the

procedures for preparation, installation, and removal. For operation details

about the management program, see the online help included in the

management program.

Getting to Know Your USB Stick

The following figure shows the appearance of the USB Stick. It is provided

only for your reference. The actual product may be different.

nUSB Connector

It connects the USB Stick to a PC.

oIndicator

It indicates the status of the USB Stick.

zSolid: The USB Stick is powered on.

zBlinking once every 2s: The USB Stick is searching for a network or no

network is found.

zBlinking twice every 2s: The USB Stick finds a network.

zBlinking once every 0.2s: The USB Stick is transmitting data.

pMicroSD Card Slot

It holds a microSD card.

qUIM Card Slot

It holds a User Identity Module (UIM) card.

Getting Your USB Stick Ready

1. Slide the back cover to remove it from the USB Stick.

re. e.

2. Insert the UIM card and the microSD card into the corresponding

card slots, as shown in the following figu

3. Replace the back cover and slide it into plac

Note:

zThe microSD card is an optional accessory. If it is not provided in the

package, you can buy one yourself.

zEnsure that the beveled edge of the UIM card is properly aligned with

that of the UIM card holder and the microSD card is inserted according

to the direction as labeled on the microSD card slot.

zDo not remove the microSD or UIM card when the card is in use.

Otherwise, the card as well as your USB Stick may get damaged and the

data stored on the card may be corrupted.

Installation/Removal Guide

The procedure for installing the management program depends on the

operating system (OS) installed on your PC. The following sections take

Windows XP as an example.

Connecting the USB Stick to a PC

Plug the USB Stick into the USB port of your PC.

Installing the USB Stick Management Program

1. Connect the USB Stick with the PC. d

d. nt

2. The OS automatically detects and recognizes the new hardware an

starts the installation wizard.

Note:

If the auto-run program does not respond, find the AutoRun.exe file in

the driver path. Then double-click AutoRun.exe to run the program.

3. Follow the on-screen instructions of the installation wizar

4. After the program is installed, a shortcut icon for the manageme

program appears on the desktop.

Starting the Management Program

After being installed, the management program starts automatically. Then

every time the USB Stick is connected to the PC, the management

program starts automatically.

You can also double-click the shortcut icon on the desktop to start the

management program.

Removing the USB Stick

1. Double-click in the notification area. Then the Unplug or Ejec

Hardware dialog box appears. t

p. s,

s. e

2. Select the corresponding hardware and then click Sto

3. When the message "It is safe to remove the device" appear

remove the USB Stick.

Uninstalling the Management Program

1. Choose Start > Control Panel > Add or Remove Program

2. Find the management program and click Remove to uninstall th

management program.

Note:

Exit the management program before uninstalling it.

Version: V100R001_01 Part Number: 3101****
